installationguide
ScreenBeam
Catalog# SBWD60KIT02
ScreenBeam Mini 2 Model# SBWD60A
ScreenBeam USB Transmitter 2 Model# SBT200DI
This Installation Guide provides step-by-step instructions on how to
set up your ScreenBeam Mini 2 Kit. We'll show you how to:
A. Install the application software
B. Set up the ScreenBeam Mini 2 receiver
C. Pair the ScreenBeam USB Transmitter 2
and ScreenBeam Mini 2 receiver
D. Set wireless display preferences
Mini 2 Kit
™
. . . . . . . . . 1
. . . 3
. . . . . . . . 4
. . . . . . . . 6
screenbeam.com
Advertisement
Related Manuals for ActionTec ScreenBeam Mini 2 Kit
Summary of Contents for ActionTec ScreenBeam Mini 2 Kit
- Page 1 ScreenBeam USB Transmitter 2 Model# SBT200DI This Installation Guide provides step-by-step instructions on how to set up your ScreenBeam Mini 2 Kit. We’ll show you how to: A. Install the application software ..1 B.
-
Page 2: Install The Application Software
A. Install the application software Download the ScreenBeam Wireless Display software to your PC or laptop from www.actiontec.com/products/sbupdate.php. Click on ScreenBeam_setup.exe. Follow the onscreen instructions, and complete the installation. screenbeam.com | 1... - Page 3 B. Set up the ScreenBeam Mini 2 receiver Remove the receiver, power adapter, USB cable, and HDMI extension cable from the box. Plug the small male connector of the USB cable to the receiver’s micro USB port labeled Power. Plug the receiver into an available HDMI port on your HDTV. Note: If the receiver cannot reach the HDMI port on your TV, use the provided HDMI extension cable to connect the receiver.
- Page 4 C. Pair the transmitter and receiver Plug the ScreenBeam USB Transmitter 2 into a USB port on your PC or laptop. Launch the ScreenBeam Wireless Display software by clicking the shortcut on the Windows desktop. Click Add a Receiver on the control panel of the software, and find your receiver name.
- Page 5 A Personal Identification Number (PIN) appears on the screen. Enter the PIN in the software, and click Next to pair your transmitter and receiver. screenbeam.com | 5...
- Page 6 D. Setting the wireless display preferences Right-click on the ScreenBeam icon from the system tray of the laptop/ PC’s desktop. When the options menu appears, select Preferences. Change the setting with your preferences. A. Language Select the language of the application software.
- Page 7 C. Display Content This allows ScreenBeam to be configured for an optimal viewing experience. Select Video Playback for better video display. Select Presentation/Slideshow for a better still image display. D. Adjust Screen Size Use the slider to adjust the size of the picture on the HDTV monitor.
- Page 8 D. Setting wireless display preferences, cont. E. Enable Push Button pairing Selecting this option allows devices or laptops to connect to your ScreenBeam receiver without having to enter a PIN. F. Enable Low Resolution mode Selecting this option transmits a lower resolution picture to the monitor, providing a smoother viewing experience.
- Page 9 P/N 0530-0816-000 © 2017 All rights reserved. Actiontec and the Actiontec logo are registered trademarks, and ScreenBeam is a trademark of Actiontec Electronics, Inc. All other names are properties of their respective owners. Specifications subject to change without notice. 072617...
