Summary of Contents for Optoma HD39Darbee

  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SAFETY ....................4 Important Safety Instruction....................... 4 3D Safety Information ........................ 5 Copyright ........................... 6 Disclaimer ..........................6 Trademark Recognition ......................6 FCC ............................7 Declaration of Conformity for EU countries ................7 WEEE ............................7 INTRODUCTION .................. 8 Package Overview........................
  • Page 3 Image size and projection distance ..................44 Projector dimensions and ceiling mount installation ..............46 IR remote codes ........................47 Using the Information button ....................49 Troubleshooting ........................50 Warning indicators ........................51 Specifications ........................... 54 Optoma global offices ....................... 55 English...

  • Page 4: Safety

    SAFETY The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

  • Page 5: 3D Safety Information

    ‡ Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡ See projector enclosure for safety related markings.

  • Page 6: Copyright

    medical specialist: (1) altered vision; (2) light-headedness; (3) dizziness; (4) involuntary movements such as eye or muscle twitching; (5) confusion; (6) nausea; (7) loss of awareness; (8) convulsions; (9) cramps; and/ or (10) disorientation. Children and teenagers may be more likely than adults to experience these symptoms.

  • Page 7: Fcc

    This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 8: Introduction

    INTRODUCTION Package Overview Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items under optional accessories may not be available depending on the model, specification and your region of purchase. Please check with your place of purchase. Some accessories may vary from region to region. The warranty card is only supplied in some specific regions.

  • Page 9: Product Overview

    INTRODUCTION Product Overview Notee: ‡ Do not block projector inlet or outlet air vents. ‡ Keep a minimum distance of 20 cm between the “inlet” and “outlet” labels. Item Item Focus Ring Lens Cap Zoom Ring 10. Tilt-Adjustment Feet Lens Shift Ring 11.

  • Page 10: Connections

    INTRODUCTION Connections Notee: Remote mouse requires special remote control. Item Item 12V OUT Connector HDMI 2 Connector 3D SYNC OUT (5V) Connector AUDIO-OUT Connector HDMI 1 / MHL Connector USB Power Out (5V 1A) Connector MOUSE / SERVICE Connector Security Bar Power Socket English...

  • Page 11: Keypad

    INTRODUCTION Keypad Item Item Enter Power Keystone Correction On/Standby LED Information Lamp LED Re-Sync 10. Source Four Directional Select Keys 11. Menu Temp LED English...

  • Page 12: Remote Control

    INTRODUCTION Remote control User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync Menu Volume HDMI1 HDMI2 VGA1 VGA2 Video YPbPr Item Item Power On 15. User 3 User 2 16. Contrast User 1 17. Display Mode Brightness 18.

  • Page 13: Setup And Installation

    Do not operate the projector in any orientation other that table top or ceiling mount. The projector should be horizontal and not tilted either forwards/backwards or left/right. Any other orientation will invalidate the warranty and may shorten the lifetime of the projector lamp or the projector itself. For none standard installation advise please contact Optoma. English...
  • Page 14 SETUP AND INSTALLATION Projector installation notice ‡ Place the projector in a horizontal position. The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically, and may lead to other unpredictable damages.

  • Page 15: Connecting Sources To The Projector

    SETUP AND INSTALLATION Connecting sources to the projector MOLEX Item Item 3D Emitter Cable HDMI Dongle MHL Cable USB Power Cable HDMI Cable Audio Out Cable Power Cord 12V DC Jack USB Cable (mouse control) English...

  • Page 16: Adjusting The Projector Image

    SETUP AND INSTALLATION Adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Zoom, focus, and lens shift...

  • Page 17: Remote Setup

    SETUP AND INSTALLATION Remote setup Installing / replacing the batteries Two AAA size batteries are supplied for the remote control. Remove the battery cover on the back of the remote control. Insert AAA batteries in the battery compartment as illustrated. Replace back cover on remote control.
  • Page 18 SETUP AND INSTALLATION Approx. ±15° Approx. ±15° English...

  • Page 19: Using The Projector

    USING THE PROJECTOR Powering on / off the projector User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Menu Mute Sleep Timer Volume Volume Source Re-sync Menu Volume...

  • Page 20: Selecting An Input Source

    USING THE PROJECTOR Selecting an input source User2 User1 User3 Contrast Brightness Mode Turn on the connected source that you want to display on the screen, such as computer, notebook, video player, etc. The projector will automatically detect the source. If multiple sources are connected, push the source button on Aspect ratio Keystone the projector keypad or the remote control to select the desired input.

  • Page 21: Menu Navigation And Features

    USING THE PROJECTOR Menu navigation and features The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. To open the OSD menu, press the key on the projector keypad or the “Menu”...

  • Page 22: Osd Menu Tree

    USING THE PROJECTOR OSD Menu tree Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Cinema Vivid Game Reference Bright Display Mode [Video] USER ISF Day ISF Night ISF 3D Off [Default] Blackboard Light Yellow Wall Color [Data] Light Green Light Blue...
  • Page 23 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu R [Default] Color Color Matching Hue or R -50~50 [Default: 0] Saturation or G -50~50 [Default: 0] Gain or B -50~50 [Default: 0] Cancel [Default] Reset Color Settings...
  • Page 24 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu 3D [Default] 3D - 2D Auto [Default] 3D Format Top and Bottom Frame Sequential 3D sync invert Off [Default] 16:9 LBX [except SVGA / XGA models] Aspect Ratio Superwide [Video] Native...
  • Page 25 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Filter Usage (read only) Hours Optional Filter Installed 300hr Filter Settings Filter Reminder 500hr [Default] 800hr 1000hr Cancel [Default] Filter Reset Off [Default] Direct Power On Off [Default] Signal Power...
  • Page 26 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Green Grid Magenta Grid Test Pattern Test Pattern White Grid White IR Function HDMI 2 Test Pattern Brightness Contrast Sleep Timer Color Matching Color Temperature User1 Gamma...
  • Page 27 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu HDMI 2 Test Pattern Brightness Contrast Sleep Timer [Default] Color Matching Remote Settings Color Temperature User3 Gamma [depends on remote] Projection Lamp Settings Zoom Freeze Darbee...
  • Page 28 USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Top Left Top Right Menu Location Center [Default] Bottom Left Menu Settings Bottom Right Menu Timer 5sec 10sec [Default] Off [Default] Auto Source HDMI2 Input Source HDMI1/MHL...

  • Page 29: Display Image Settings Menu

    USING THE PROJECTOR Main Sub Menu Sub Menu 2 Sub Menu 3 Sub Menu 4 Values Menu Regulatory Serial Number Source Resolution 00x00 Refresh Rate 0.00Hz Display Mode Bright 0 hr Information Eco. 0 hr Lamp Hours Dynamic 0 hr Total Filter Hours Brightness...
  • Page 30 USING THE PROJECTOR Brightness Adjust the brightness of the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. Sharpness Adjust the sharpness of the image. Color Adjust a video image from black and white to fully saturated color. Tint Adjust the color balance of red and green.

  • Page 31: Display Enhanced Gaming Menu

    USING THE PROJECTOR RGB Gain/Biase: This settings allows to configure the brightness (gain) and contrast (bias) of an ‡ image. ± Reset: Return the factory default settings for RGB gain/bias. ± Exit: Exit the “RGB Gain/Bias” menu. ‡ Color Space (HDMI input only): Select an appropriate color matrix type from the following: Auto, (0-255), and (16-235).

  • Page 32: Display 3D Menu

    USING THE PROJECTOR Display 3D menu Use this option to disable the 3D function or select the appropriate the 3D function. ‡ Off: Select “Off” to turn off 3D mode. ‡ DLP-Link: Select to use optimized settings for DLP 3D Glasses. ‡...

  • Page 33: Display Edge Mask Menu

    USING THE PROJECTOR ± If you use an external anamorphic lens, this LBX mode also allows you to watch a 2.35:1 content (include Anamorphic DVD and HDTV film source) that supports anamorphic wide is enhanced for 16x9 Display in a wide 2.35:1 image. In this case, there are no black bars. Lamp power and vertical resolution are fully utilized.

  • Page 34: Audio Mute Menu

    USING THE PROJECTOR Audio menu Audio mute menu Mute Use this option to temporarily turn off the sound. ‡ One: Choose the “On” to turn mute on. ‡ Offe: Choose the “Off” to turn mute off. Notee: “Mute” function affects both internal and external speaker volume. Audio volume menu Volume Adjust the volume level.

  • Page 35: Setup Power Settings Menu

    USING THE PROJECTOR Setup power settings menu Direct Power On Choose “On” to activate Direct Power mode. The projector will automatically power on when AC power is supplied, without pressing the “Power” key on the projector keypad or on the remote control. Signal Power On Choose “On”...

  • Page 36: Setup Hdmi Link Settings Menu

    USING THE PROJECTOR Setup HDMI link settings menu Notee: ‡ When you connect HDMI CEC-compatible devices to the projector with HDMI cables, you can control them on the same power on or power off status using the HDMI Link control feature in the projector’s OSD.

  • Page 37: Setup 12V Trigger Menu

    USING THE PROJECTOR User2: HDMI 2, test pattern, brightness, contrast, sleep timer, color matching, color temperature, ‡ gamma, source lock, projection, lamp settings, zoom, freeze, MHL, and Darbee. ‡ User3: HDMI 2, test pattern, brightness, contrast, sleep timer, color matching, color temperature, gamma, projection, lamp settings, zoom, freeze, MHL, and Darbee.

  • Page 38: Setup Reset Osd Menu

    USING THE PROJECTOR Logo Use this function to set the desired startup screen. If changes are made, they will take effect the next time the projector is powered on. ‡ Defaulte: The default startup screen. ‡ Neutrale: Logo is not displayed on startup screen. Logo Capture Use to capture an image of the picture currently displayed on the screen.

  • Page 39: 3D Setup

    USING THE PROJECTOR 3D Setup Turn on your projector. Connect your 3D source. For example, 3D Blu ray, Games console, PC, Set top box, etc. Ensure you have inserted 3D content or selected the 3D channel. Turn on your 3D glasses. Please refer to the 3D glasses user manual on how to operate the 3D glasses.

  • Page 40: Maintenance

    MAINTENANCE Replacing the lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, a warning message will appear on the screen. Warning Lamp Warning Lamp life exceeded. When you see this message, please contact your local reseller or service center to change the lamp as soon as possible.

  • Page 41: Replacing The Lamp (Continued)

    MAINTENANCE Replacing the lamp (continued) Procedure: Switch off the power to the projector by pressing the " " button on the remote control or the projector keypad. Allow the projector to cool down for at least 30 minutes. Disconnect the power cord. Unscrew the screw on the cover.
  • Page 42 MAINTENANCE Notee: ‡ The screw on the lamp cover and the lamp cannot be removed. ‡ The projector cannot be turned on if the lamp cover has not been placed back on the projector. ‡ Do not touch the glass area of the lamp. Hand oil can cause the lamp shatter. Use a dry cloth to clean the lamp module if it was accidentally touched.

  • Page 43: Additional Information

    If 3D input is 1080p@24hz, the DMD should replay with integral multiple with 3D mode. ‡ Support NVIDIA 3DTV Play if there is no patent fee from Optoma. 1080i@25hz and 720p@50hz will run in 100 hz; other 3D timing will run in 120hz.

  • Page 44: Image Size And Projection Distance

    ADDITIONAL INFORMATION Image size and projection distance (C16_1080P) Desired Image Size Projection Distance (C) Diagonal Width Height Wide Tele inch inch inch feet feet 0.91 0.80 31.38 0.45 17.65 3.61 5.91 1.02 0.89 34.86 19.6 3.94 6.56 1.27 1.11 43.58 0.62 24.5 4.92...
  • Page 45 ADDITIONAL INFORMATION 5.4 cm 1. Center of projector lens. 2. Projection image while lens shift at the highest postion 3. Vertical shift range : 10% V English...

  • Page 46: Projector Dimensions And Ceiling Mount Installation

    ADDITIONAL INFORMATION Projector dimensions and ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...

  • Page 47: Ir Remote Codes

    ADDITIONAL INFORMATION IR remote codes User2 User1 User3 Contrast Brightness Mode Aspect ratio Keystone Mute Sleep Timer Volume Source Re-sync Menu Volume HDMI1 HDMI2 VGA1 VGA2 Video YPbPr Data Custom code Printing-key code Description definition Byte 1 Byte 2 Byte 3 Power on Press to turn on the projector.
  • Page 48 ADDITIONAL INFORMATION Data Custom code Printing-key code Description definition Byte 1 Byte 2 Byte 3 Mute Mute Momentarily turns off / on the audio. Automatically adjusts the picture brightness (Dynamic Black) to give optimum contrast performance. Sleep timer Sleep Timer Sets the countdown timer interval.

  • Page 49: Using The Information Button

    ADDITIONAL INFORMATION Using the Information button The Information function ensures easy setup and operation. Press the button on the keypad to open the Information menu. English...

  • Page 50: Troubleshooting

    ADDITIONAL INFORMATION Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”...

  • Page 51: Warning Indicators

    ADDITIONAL INFORMATION Two images, side-by-side format ‡ Press “3D” button and switch to “SBS” for input signal is HDMI 1.3 2D 1080i side-by-side. Image does not display in 3D ‡ Check if the battery of 3D glasses is drained. ‡ Check if the 3D glasses is turned on.
  • Page 52 ADDITIONAL INFORMATION LED lightning messages Power LED Power LED Temp-LED Lamp-LED Message (Red) (Green or Blue) (Red) (Red) Standby state Steady light (Input power cord) Flashing Power on (Warming) (0.5 sec off / 0.5 sec on) Power on and Lamp Steady light lighting Flashing...
  • Page 53 ‡ Fan failed: Warning FAN LOCKED The projector will switch off automatically Please contact a service center for repair. ‡ Out of display range: HDMI Out Of Range ‡ Power down warning: Power Down Power Down Timer Active Power down in sec.

  • Page 54: Specifications

    ADDITIONAL INFORMATION Specifications Optical Description Digital signal resolution is up to: Maximum resolution - UXGA@60Hz (1600x1200) - WUXGA@60Hz for WXGA 16:10 (1920x1200; supports RB only) Native resolution 1080p (1920x1080) Lens Digital zoom and manual focus Image size (diagonal) 1080p: 26.2”~301.1” Projection distance 1080p: 1.3m~9.4m (optimized at 1.87m) Electrical...

  • Page 55: Optoma Global Offices

    ADDITIONAL INFORMATION Optoma global offices For service or support, please contact your local office. Japan 3178 Laurelview Ct. 888-289-6786 東京都足立区綾瀬3-25-18 Fremont, CA 94538, USA 510-897-8601 info@os-worldwide.com 株式会社オーエス www.optomausa.com services@optoma.com 0120-380-495 www.os-worldwide.com コンタクトセンター: Canada Taiwan 3178 Laurelview Ct. 888-289-6786 12F., No.213, Sec. 3, Beixin Rd.,...
  • Page 56 www.optoma.com...
