- Page 1 INSTRUCTION MANUAL Jig Saw M4302 DOUBLE INSULATION Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model M4302 Length of stroke 26 mm Max. cutting capacities Wood 55 mm Steel 6 mm Strokes per minute (min 0 - 3,100 Overall length 219 mm Net weight 2.5 kg Safety class • Due to our continuing program of research and development, the speciications herein are subject to change without notice. • Speciications may differ from country to country. - Page 3 12. Use personal protective equipment. Always 26. Follow instruction for lubricating and chang- wear eye protection. Protective equipment such ing accessories. as dust mask, non-skid safety shoes, hard hat, or 27. Keep handles dry, clean and free from oil and hearing protection used for appropriate conditions grease.
-
Page 4: Functional Description
Installing or removing saw blade FUNCTIONAL DESCRIPTION CAUTION: • Always clean out all chips or foreign matter adhering to the blade and/or blade holder. CAUTION: Failure to do so may cause insuficient tighten- • Always be sure that the tool is switched off and ing of the blade, resulting in serious personal unplugged before adjusting or checking func- injury. tions on the tool. • Do not touch the blade or the workpiece imme- diately after operation as they may be extremely Switch action hot and could cause burn injury. -
Page 5: Bevel Cutting
► 1 . Roller 2. Saw blade Turn the tool on without the blade making any contact and wait until the blade attains full speed. Then rest Loosen the hex bolt on the back of the base with the base lat on the workpiece and gently move the tool the hex wrench. Move the retainer so that the roller forward along the previously marked cutting line. - Page 6 For internal cutouts without a lead-in cut from an edge, pre-drill a starting hole 12 mm or more in diameter. Insert the blade into this hole to start your cut. B) Plunge cutting ► 1 . Edge of housing 2. Graduation Tilt the base until the desired bevel angle is obtained.
-
Page 7: Maintenance
Take out the worn carbon brushes, insert the new ones and secure the brush holder caps. ► 1 . Screwdriver 2. Brush holder cap To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be per- formed by Makita Authorized Service Centers, always using Makita replacement parts. 7 ENGLISH... - Page 8 Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885589-932 20170323 www.makita.com...
