BCDVideo BCD-RGD-804P-MT Installation Manual

Industrial, with poe plus 12 ports: 8 poe plus ports, 4 optical uplink ports
Hide thumbs Also See for BCD-RGD-804P-MT:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
BCD-RGD-804P-MT
index
1
INTRODUCTION
1.1
1.2
1.3
2
SPECIFICATION
3
SWITCH INSTALLATION
3.1
3.2
3.3
4
HARDWARE DESCRIPTION
4.1
4.2
5
CABLE
5.1
5.2
5.3
BCD-RGD-804P-MT Industrial Ethernet Switch
Software Features
Hardware Features
Install Switch on DIN rail
Wall-mounted
Equipment Ground Protection
Front Panel
Indicator Description
Ethernet Cable
SFP Port
Console Cable
Industrial Gigabit Ethernet Switch with PoE+
12 ports: 8 PoE+ ports, 4 optical uplink ports
2
2
2
3
4-5
6
6
7-8
8
9
9
10
10
10-11
12
12
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BCD-RGD-804P-MT and is the answer not in the manual?

Questions and answers

Related Manuals for BCDVideo BCD-RGD-804P-MT

Summary of Contents for BCDVideo BCD-RGD-804P-MT

  • Page 1 BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports index INTRODUCTION BCD-RGD-804P-MT Industrial Ethernet Switch Software Features Hardware Features SPECIFICATION SWITCH INSTALLATION Install Switch on DIN rail Wall-mounted Equipment Ground Protection HARDWARE DESCRIPTION...

  • Page 2: Software Features

    1 Introduction bcd-rgd-804p-mt industrial ethernet switch The BCD-RGD-804P-MT is a managed industrial Ethernet switch with 8*10/100/1000M auto sensing electrical ports and 4*1000M SFP ports. It supports PoE/PoE+ with a variety of management: WEB, Telnet, Console (CLI), SSH, etc., as well as proprietary network management software for centralized management, centralized monitoring, centralized configuration.

  • Page 3: Hardware Feature

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports 1.3 hardware feature − 8*10/100/1000M auto sensing electrical ports − 4*1000M SFP ports − Support PoE/PoE+ − Console Port: USB＜(115200-8-N-1) − Support dual DC power input −...

  • Page 4: Specification

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports 2. specification 10/100/1000 Base-T (X) Ports 8 RJ45Auto MDI/MDIX 1000Base-FX SFP 4 (SFP slot) PoE Type End Span MAC Table 8192 MAC Addresses Priority Queues...

  • Page 5: Industrial Gigabit Ethernet Switch With Poe

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports DDM Function Voltage/Current/Temperature Console Port USB (115200-8-N-1) Alarm Output Relays Relays output error alarm: 1A@30VDC Power Redundant Input Power DC45~57V Power Consumption (Typ.) 10 W (No PoE)

  • Page 6: Switch Installation

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports 3. switch installation 3.1 install switch on din rail Each switch has a rail button on the rear panel. Rail buckle allows the switch mounted on the rail.

  • Page 7: Wall-Mounted

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports 3.2 wall-mounted Step 1 Remove Din rail buckle. Turn off the screws 1, 2 on buckle Remove the buckle Step 2 Remove 4 screws (spec: M2 .5 x 8) on the back panel and fix the installation suspension loop on the back panel.

  • Page 8: Equipment Ground Protection

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports Step 3 Install the Switch on the wall vertically by using self-tapping screws. 3.3 equipment ground protection In order to use this equiment safely and ensure the protection of EMC, grounding terminals must be connected to the ground.

  • Page 9: Hardware Description

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports 4. hardware description 4.1 front panel Port Description 10/100/1000 RJ-45 10/100/1000BAse-T(X) RJ-45 fast Ethernet ports support Auto-negotiation. Ethernet ports SFP port 100Base-X on SFP port...

  • Page 10: Indicator Description

    Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports CONNECT & LOGIN TO BCD-RGD-804P-MT switch Connecting PC to BCD-RGD-804P-MT Ethernet port (RJ45 Ethernet port). Factory default IP: 192.168.0.240 Login with default account and password.

  • Page 11: Cable

    BCD-RGD-804P-MT Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports Cable Type Max Length Connector 10BASE-T Cat. 3, 4, 5, 100-ohm UTP 100m (328 ft) RJ-45 10BASE-TX Cat. 5 100-ohm UTP UTP 100m (328 ft)

  • Page 12: Console Cable

    Industrial Gigabit Ethernet Switch with PoE+ 12 ports: 8 PoE+ ports, 4 optical uplink ports BCD-RGD-804P-MT switches support MDI / MDIX auto-flip function. The following table lists the10/100 Base-T MDI/ MDI-X/ 1000 Base-T MDI/MDI-X port pin output. 10/100 Base-T MDI/MDI-X Pin Definition...
