- Page 1 BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports index INTRODUCTION 1.1 BCD-RGD-402P-UMT INTRODUCTION 1.2 FEATURES 1.3 SPECIFICATIONS PANEL VIEWS 2.1 Front panel view DIMENSIONS (UNIT=mm) MOUNTING 4.1 DIN mounting 4.2 Wall mounting 4.3 Items for attention...
-
Page 2: Introduction
6 ports: 4 PoE+ ports, 2 optical uplink ports 1.1 Introduction The BCD-RGD-402P-UMT is an unmanaged PoE/PoE+ Industrial Ethernet switch with 4*10/100/1000 auto sensing electrical ports and 2 *1000M SFP uplink ports. This Product supports PoE/PoE+, each port outputs up to 30W. Industrial level 3 protection design and IP40 enclosure protection makes the product suitable for applications with harsh environments. -
Page 3: Specifications
BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports 1.3 specifications Ethernet 10/100/1000 Base-T 1000Base-FX SFP 2 (SFP slot) PoE standard IEEE802.3af/at Switching Performance Architecture Store and Forword Switching Capacity 12Gbps Power Redundant Input Power Dual DC inputs. -
Page 4: Front Panel View
BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports 2. Panel views 2.1 front panel view PWR status indication 45~57VDC power input PoE status indication Ground screw 10/100/1000Base-T port: #1 ~ #4 1000Base-X SFP port: # 5 ~ #6... -
Page 5: Dimensions (Unit=Mm
BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports WARNING: This product MUST be mounted to a well-grounded mounting surface such as a metal panel. Status indicator LED Color Status Description Orange Power is being supplied... -
Page 6: Mounting
BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports 4. mounting Very simple: Press the clamp, insert into rail then loosen hand. 4.2 Wall mounting Step 1 Step 2 www.bcdvideo.com... -
Page 7: Items For Attention
BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports Step 1: Remove the guide rail fastener. Step 2: Remove the DIN clamp in the rear panel. Step 3: Find the wall mounting accessory, and loosen these 4 screws in the Swtich. -
Page 8: Ethernet Cable
BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports 5. cable 5.1 ethernet cable The product uses standard Ethernet cable. Depending on the connection type, you can choose CAT3, 4, 5e, 6 UTP cable to connect to other network devices (computers, servers, switches, routers, hubs, etc.). -
Page 9: Sfp Port
BCD-RGD-402P-uMT Industrial Gigabit Ethernet Switch with PoE+ 6 ports: 4 PoE+ ports, 2 optical uplink ports This switch supports MDI / MDIX auto-flip function. The following table lists the 10/100 BAse-T MDI/MDI-X/1000 Base-T MDI/MDI-X port pin output. 10/100 Base-T MDI/MDI-X Pin Definition...
