- Page 1 NOKTON 40mm F1.2 Aspherical E-mount INSTRUCTION MANUAL COSINA CO., LTD. Oct 2017, Ver 1.0...
- Page 2 Voigtländer E-mount lenses are designed for use on E-mount camera body. The lenses cover the full frame format. They are manually controlled lenses so the user sets focus and aperture - the built-in CPU will transmit the information to the camera body to give the user Exif-data, and depending on the specification of the camera Auto-lens-correction, 5 axis-Image Stabilization as well as Manual-Focus Assist.
- Page 3 Tips for lens care and safety These tips are to protect the user from injury or damaging the lens. If the user ignores this warning sign and uses the equipment the wrong way serious injuries and even death might be the WARNING result.
- Page 4 Description of Parts ① Lens Hood ① ② Filter Ring ③ Aperture Control Ring ④ Aperture Ring ② ⑤ Focus Ring ③ ⑨ ⑩ ⑥ Distance Scale ④ ⑦ Mount Index ⑧ Mount ⑤ ⑨ Aperture Index ⑩ Aperture Scale ⑥...
- Page 5 ● How to attach/detach the lens Please refer to the instruction manual for your camera for how to attach/detach the lens. * Please make sure to set the power of the camera to “OFF”. Please hold Depth of Field Ring ⑬ to attach/detach the lens. To attach/detach the lens while holding other parts of the lens barrel can damage the lens.
- Page 6 ● Selective Aperture Control System You can choose two modes – with or without Click Stops - on the Aperture Control Ring. 1. Push the Aperture Control Ring ③ towards the Aperture Ring ④ . 2. Turn the Aperture Control Ring ③ 180 degrees. 3.
- Page 7 1. Exif Data Picture can store the Exif data of lens. (For example, if you use Voigtländer 40mm F1.2 E-mount) Lens E 40mm F1.2 or Voigtlander NOKTON 40mm F1.2 Aspherical * Description may be changed depending on firmware version or other factors.
- Page 8 3. Manual Focus Assist Magnified Live View Image will be seen on the camera‘s LCD screen when the camera detects the Focus Ring rotation. You can choose duration of the mode by MENU of camera body. Please refer to the instruction manual of your camera.
- Page 9 ● Specifications Product Name NOKTON 40mm F1.2 Aspherical Focal Length 40mm Maximum Aperture F1.2 Minimum Aperture Lens Construction 6 groups 8 elements Angle of View 55° Aperture Blade Minimum Focus 0.35m Macro Ratio 1:6.2 Filter Size Ø58mm Maximum Diameter Approx. Ø70.1mm Length Approx.
- Page 10 ● Specifications 5-Axis Image Stabilization Possible * only on camera body with 5-Axis Image Stabilization Other Selective Aperture Control System Supplied Accessory Front Cap, Rear Cap, Lens Hood * Specification and information is subject to change without prior notice.
