Dmx Chart

2CH
5CH
8CH
NEO MINI PANEL
ENGLISH VERSION
Function
1
Strobe Speed
2 Dimmer
Function
1
Dimmer
2 Strobe Speed
3 Strobe Duration time
4 Special effects
5
Pixel control macros
Function
1 Strobe 1
2 Strobe 2
3 Strobe 3
Value Percent/Setting
000-001 No Function
002-249 Strobe slow to fast
250-255 Full on
000-255 0-100%
Value Percent/Setting
000-005 No Function
006-255 0~100%
000-005 No Function
006-255 Strobe slow to fast
000-005 No function
006-255 15-90ms
000-005 No Function
006-042 Ramp up
043-085 Ramp down
086-128 Ramp up-down
129-171 Random
172-214 Lightning
215-255 Spikes
000-005 No Function
Macro 1(slow to
006-042
fast)
Macro 2 (slow to
043-085
fast)
Macro 3(slow to
086-128
fast)
Macro 4 (slow to
129-171
fast)
Macro 5 (slow to
172-214
fast)
Macro 6 (slow to
215-255
fast)
Value Percent/Setting
000-005 No Function
006-249 Strobe slow to fast
250-255 Full on
000-005 No Function
006-249 Strobe slow to fast
250-255 Full on
000-005 No Function
006-249 Strobe slow to fast
250-255 Full on
Remark
000-005
Remark
Remark
