Vehicle installation A
Installation A instructions (Rear power source)
1. Connect the reverse (red) and ground (black) wires on the master cable to the
same color wires on the included vehicle charger cord. If the included master
cable contains a spare blue wire for custom installation, please properly insulate
it - this wire will not be required for standard installation.
2. Plug the vehicle charger into the rear power source.
3. Plug the round end of the master cable into the camera cord.
4. Open the app. The camera displays.
5. If necessary, adjust the camera angle downward to achieve the best view.
NOTE: If using this installation option with OverDryve
•
Within the Wireless Backup Cam app, MENU > SETTINGS > TYPE of INSTALL > "Continuous Power Source"
10
™ , remember to change the application settings as follows:
Installation B instructions (Reverse lights)
Professional installation recommended. Not applicable when used with
smartphones.
1. Access the vehicle's rear light wiring system.
2. Connect the reverse (red) and ground (black) wires on the master cable to the
vehicle wires using the T-Tap connectors. If the included master cable contains a
spare blue wire for custom installation, please properly insulate it − this wire will
not be required for standard installations.
3. Plug the round end of the master cable into the camera cord.
4. Shift the vehicle into reverse to display the camera.
5. If necessary, adjust the camera angle downward to achieve the best view.
Vehicle installation B
11
