Box contents

Camera with license plate bracket
1
Wi-Fi transmitter with antenna
2
3-ft master cable
3
Car charger
4
4 t-tap connectors
5
4 zip ties
6
5
2 rubber grommets
7
4
2
1
7
4
6
IMPORTANT: Before installing the backup camera in the vehicle, establish a
connection between the camera and the display device.
1. Screw the antenna onto the transmitter.
2. Plug the white connector at the end of the master cable into the transmitter
until it clicks.
3. Plug the black and red connectors on the master cable into the matching wires
on the vehicle charger.
3 4. Plug the round end of the master cable into the camera cord.
5. Plug the charger into the vehicle's power source. A red light on the transmitter
indicates power is supplied. When connected, the camera will broadcast a
Wi-Fi signal.
6. Turn on the compatible display device, such as the smartphone or an OverDryve
7. Open the app. (For download instructions, see page 3.)

Connect the camera

.
™
5
