Page 1: Installation Manual
Installation manual Daikin Altherma – Low temperature split ERGA04DAV3 Installation manual ERGA06DAV3(A) English Daikin Altherma – Low temperature split ERGA08DAV3(A) - Page 2 2P491692-1...
- Page 3 2P491692-1...
-
Page 4: Table Of Contents
4.2.2 To install the outdoor unit..........4.2.3 To provide drainage ............ ▪ The full set of latest technical data is available on the Daikin 4.2.4 To prevent the outdoor unit from falling over ....extranet (authentication required). Connecting the refrigerant piping .......... -
Page 5: To Remove The Accessories From The Outdoor Unit
3.1.1 Installation site requirements of the outdoor unit Mind the following spacing guidelines: Snow cover or shed Pedestal Prevailing wind direction Air outlet EKFT008D option kit ERGA04~08DAV3 Installation manual Daikin Altherma – Low temperature split 4P489913-1B – 2017.10... -
Page 6: Installation
Maximum snowfall height Option 2: On plastic mounting feet In this case, you can use the bolts, nuts, washers and spring washers delivered with the unit as accessories. Installation manual ERGA04~08DAV3 Daikin Altherma – Low temperature split 4P489913-1B – 2017.10... -
Page 7: To Install The Outdoor Unit
▪ (1) Put the unit into position (using the sling to the left and Drain pan the handle to the right). U-beams ▪ (2) Remove the sling (by pulling 1 side of the sling). ▪ (3) Fix the unit. ERGA04~08DAV3 Installation manual Daikin Altherma – Low temperature split 4P489913-1B – 2017.10... -
Page 8: To Prevent The Outdoor Unit From Falling Over
There is no moisture in the outdoor unit system. This procedure is finished. 1 Connect the liquid refrigerant connection from the indoor unit to the liquid stop valve of the outdoor unit. Installation manual ERGA04~08DAV3 Daikin Altherma – Low temperature split 4P489913-1B – 2017.10... -
Page 9: Charging Refrigerant
To connect the electrical wiring on the label outdoor unit 1 Fill in the label as follows: 1 Remove the switch box cover. Contains fluorinated greenhouse gases RXXX GWP: XXX GWP × kg 1000 ERGA04~08DAV3 Installation manual Daikin Altherma – Low temperature split 4P489913-1B – 2017.10... -
Page 10: Finishing The Outdoor Unit Installation
12 3 Technical data A subset of the latest technical data is available on the regional Daikin website (publicly accessible). The full set of latest technical data is available on the Daikin extranet (authentication required). Installation manual ERGA04~08DAV3 Daikin Altherma –... -
Page 11: Piping Diagram: Outdoor Unit
Compressor accumulator Muffler Compressor Thermistor (outdoor air) Thermistor (heat exchanger) Thermistor (compressor discharge) S1PH High pressure switch (automatic reset) Electronic expansion valve Solenoid valve (4‑way valve)(ON: cooling) Heating Cooling ERGA04~08DAV3 Installation manual Daikin Altherma – Low temperature split 4P489913-1B – 2017.10... -
Page 12: Wiring Diagram: Outdoor Unit
Printed circuit board (main) PCB2 Printed circuit board (service) Switching power supply Thermal protector Q1DI # Earth leakage circuit breaker Insulated gate bipolar transistor (IGBT) Thermistor (air) Thermistor (heat exchanger) Installation manual ERGA04~08DAV3 Daikin Altherma – Low temperature split 4P489913-1B – 2017.10... - Page 16 4P489913-1B 2017.10...
