NavePoint 6U Instructions

Pro Series
Thank you for purchasing a NavePoint product. NavePoint intends this manual to guide you through
a smooth installation of the product. NavePoint assumes that you are qualified in the servicing of
computer equipment and trained in recognizing any hazards that may occur in the installation of this
product. If you have any questions regarding the installation or use of your product, please call us at
888.505.1363.
Examine the package for any damaged or loose parts. If
anything is damaged or missing, contact NavePoint for
assistance. Do not attempt to install or use cabinet if it has
been damaged.
The information contained in this document is subject to change
without notice.
NavePoint makes no warranty of any kind with regard to this
material, including, but not limited to the implied warranties of
merchantability and fitness for a particular purpose.
NavePoint shall not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
NavePoint assumes no responsibility for the use, application, or
reliability of the software or hardware that you install into the
product. Always install the heaviest equipment in the bottom.
It is highly recommended that installation of this product be
performed by a qualified and experienced installer. Improper
installation of this product could result in damage to the
product, other equipment, or personal injury. NavePoint cannot
be held responsible for damage to equipment or personal
injury resulting from improper use, installation or the misuse of
information presented in this document.
Hardware:
Cabinet
Size
M6 Screw
M6 Nut
M5 Screw
M3.5 Screw 10
Tools needed: allen wrench (wrench included) and phillips screw driver.
M6 Screw
H-1
6U 9U
28 28
4 4
18 18
10
M5 Screw
H-2
Important information-
Keep this information for further reference.
WARNING
Different wall materials require different type of
anchoring devices. Use anchoring devices suitable
for the walls which you are using in your applica-
tion. For advice on suitable anchoring systems,
contact your local specialist.
Limitations of Liability: In no event will NavePoint, LLC. (or its
officers, directors, employees or agents) be liable for any dam-
ages, whether direct or indirect, special, punitive, incidental or
consequential damages (including, but not limited to, lost profits
or revenue, loss of use, lost business opportunities or loss of
goodwill) or for the costs of procuring substitute products, arising
out of or in connection with the use of the product, whether such
liability arises from any claim based upon contract, warranty, tort
(including negligence), product liability or otherwise, whether
or not seller has been advised of the possibility of such loss or
damage. In no event will seller's total cumulative liability, from
all causes of action and all theories of liability, exceed the total
amounts actually paid to seller by customer under the order that
gives rise to any liability hereunder.
12U 15U
28 32
4 4
18 18
10 10
M3.5 Screw
H-3
Extra cage nut set for accessories included .
www.NavePoint.com
customerservice@navepoint.com
© 2017 NavePoint, LLC
Rev. 20170517
18U
32
4
18
10
M6 Nut
H-4
