OWNER'S MANUAL: Portable Server Rack with Handles and Casters (9U/12U/15U)
THIS MANUAL APPLIES TO THE FOLLOWING SKUs: 00301317, 00301318, 00301319
Keep this information for further reference.
Thank you for purchasing a NavePoint product. If you have any questions regarding the installation or use of your product, please call us at
888.505.1363.
Please examine the product for any damaged parts. If any part is damaged or missing, contact NavePoint for assistance. Do not attempt to install or
use product if it has been damaged.
During installation, lay product contents on cardboard or other protective surface to avoid any damage.
Improper installation or use of this product could result in damage to the product, other equipment, or personal injury. It is recommended that
installation be performed by a qualified installer. NavePoint cannot be held responsible for damage to equipment or personal injury resulting from
improper use or installation of product. If product is intended to store/mount equipment, please ensure the equipment stored/mounted does not
exceed the specified weight capacity. Install the heaviest equipment first and install it at the bottom of the rack. Install equipment starting from
the bottom of the rack and move upward.
Limitations of Liability: In no event will NavePoint, LLC. be liable for any damages, whether direct or indirect, special, punitive, incidental or
consequential damages (including, but not limited to, lost profits or revenue, loss of use, lost business opportunities or loss of goodwill) or for the
costs of procuring substitute products, arising out of or in connection with the use of the product, whether such liability arises from any claim
based upon contract, warranty, tort (including negligence), product liability or otherwise, whether or not seller has been advised of the possibility
of such loss or damage. In no event will seller's total cumulative liability, from all causes of action and all theories of liability, exceed the total
amounts actually paid to seller by customer under the order that gives rise to any liability hereunder.
© 2020 NavePoint, LLC
20200910-01

Advertisement

loading
Need help?

Need help?

Do you have a question about the 00301317 and is the answer not in the manual?

Questions and answers

Summary of Contents for NavePoint 00301317

  • Page 1 Thank you for purchasing a NavePoint product. If you have any questions regarding the installation or use of your product, please call us at 888.505.1363. Please examine the product for any damaged parts. If any part is damaged or missing, contact NavePoint for assistance. Do not attempt to install or use product if it has been damaged.
  • Page 2: Parts Identification

    M6*12mm Screws (x32) M6 Caster Screws (x16) M6 Cage Nuts (x4) Equipment Mounting Hardware M6 Mounting Screws M6 Cage Nuts 9U (x12) 12U (x12) 9U (x12) 12U (x12) 15U (x24) 15U (x24) Tools Required: Phillips Screwdriver (not included) www.NavePoint.com customerservice@navepoint.com...
  • Page 3: Rack Assembly

    Panel (A) and secure them with 6 of the M6 x 12mm Screws (F) using a Phillips Screwdriver. Assemble Second Side Panel to Bottom Panel Repeat above process to secure the other Side Panel (C) into the Bottom Panel (A). www.NavePoint.com customerservice@navepoint.com...
  • Page 4 Vertical Mounting Rail (D). When determining the appropriate depth, be sure to consider the equipment that you plan to mount inside the enclosure. Note: Be sure that the rail depth is the same on both sides of the cabinet. www.NavePoint.com customerservice@navepoint.com...
  • Page 5 Attach 4 Casters (E) to the Bottom Panel (A) Assemble Casters to Bottom Panel using 4 of M6 Caster Screws (G) for each Caster using a Phillips Screwdriver. Note: The enclosure can hold up to 200 pounds evenly distributed. www.NavePoint.com customerservice@navepoint.com...
  • Page 6: Equipment Installation

    Repeat steps 1a and 1b until all required cage nuts are installed. 2 After installing the required cage nuts, use the included black mounting screws and plastic washers to secure your equipment to the rack rail. Place the plastic washers between the screws and the equipment mounting brackets. www.NavePoint.com customerservice@navepoint.com...
