Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2002 Porter-Cable Corporation
7:41 AM
Page 1
ESPAÑOL: PÁGINA 17
FRANÇAISE : PAGE 35
Double Insulated
Circular Saw
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
MODELS
347k and 447k
Part No. 900003 - 04-09-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Porter-Cable 347k
Summary of Contents for Porter-Cable 347k
- Page 1 900003 - 04-09-02.qxd 4/18/02 7:41 AM Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2002 Porter-Cable Corporation Page 1 ESPAÑOL: PÁGINA 17 FRANÇAISE : PAGE 35 Double Insulated Circular Saw MODELS 347k and 447k...
-
Page 2: General Safety Rules
900003 - 04-09-02.qxd 4/18/02 7:41 AM WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: · lead from lead-based paints, ·... - Page 3 900003 - 04-09-02.qxd 4/18/02 7:41 AM Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts. Avoid accidental starting.
- Page 4 If both hands are holding the saw, they cannot be cut by the blade. Keep your body positioned to either side of the saw blade, but not in line with the saw blade. KICKBACK could cause the saw to jump backwards.
- Page 5 4/18/02 7:41 AM 14. Maintain a firm grip on the saw and position your body and arm in a way that allows you to resist KICKBACK forces. KICKBACK forces can be controlled by the operator, if proper precautions are taken.
-
Page 6: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 7: Functional Description
Check the telescoping guard to insure it is in working order. Clean inner blade flange, retract telescoping guard, and place sharp blade on arbor making sure teeth point up at front of saw as shown in Fig. 2. CAUTION: AVOID CONTACT WITH BLADE TEETH TO PREVENT PERSONAL INJURY. - Page 8 TO ADJUST DEPTH OF CUT FOR NORMAL CUTTING It is recommended that the depth of cut be adjusted so that the saw blade just protrudes through the thickness of material being cut. Adjust depth of cut as follows: CAUTION: DISCONNECT TOOL FROM POWER SOURCE.
- Page 9 45° or the 90° position. In normal operation the bevel stop sleeve (C) Fig. 6, is aligned as shown in Fig. 6. To adjust the saw for a bevel cut beyond the normal 45° to 90° range: CAUTION: DISCONNECT TOOL FROM POWER SOURCE.
- Page 10 4/18/02 7:41 AM Fig. 6 The saw can now be adjusted for a bevel cut between the normal stop (45° or 90°) and 3° beyond the normal stop. Position saw to desired angle and firmly tighten bevel adjustment knob. NOTE: The bevel stop sleeve must be returned to the normal position (see Fig.
-
Page 11: Blade Wrench Storage
Fig. 9 LINE-OF-CUT INDICATOR Line-of-cut indicator slots (Fig. 9), are provided at the front of the saw base. The right slot is used to follow a line when making a 90° cut. The left slot is used to follow a line when making a 45° cut. -
Page 12: Operation
Fig. 14 illustrates proper hand support of the saw. Clamp work on a rigid support such as a bench or saw horses. See Fig. 14. Mark the line of cut on the work. Be sure cut-off line is beyond end of support to the right only enough to allow proper operation of the telescoping guard. - Page 13 See Fig. 14. Do not force the cut. Let the saw do the cutting at the rate of speed permitted by the type of cut and the material being cut. When the cut is completed, release the switch and allow the blade to stop before lifting the saw from the work.
-
Page 14: Bevel Cutting
Mark the area clearly with lines on all sides. Start near the corner of one side and place front edge of saw base firmly on the work. Hold saw up so blade clears the material. Be sure you have adjusted the blade properly for depth of cut. -
Page 15: Maintenance
FACTORY SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricate with fresh lubricant. Have new brushes installed, and test the tool for performance. -
Page 16: Service And Repairs
PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period. - Page 17 Pour obtenir des pièces et accessoires pour les produits Porter-Cable • Delta, s’adresser à tout distributeur Porter- Cable • Delta, centre de service agréé ou centre de service d’usine Porter-Cable • Delta. Si vous n’avez accès à aucun de ces centres, appeler le 888-848-5175 et on vous dirigera vers le centre de service d’usine Porter-Cable •...
