Instruction
manual
MODEL PCV2021
MODEL PCH2425
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2001 Porter-Cable Corporation
ESPAÑOL: PÁGINA 21
FRANÇAIS: PAGE 41
Pressure
Washers
MODEL PCH2627
IMPORTANT
Please make certain that the person who is to use
this equipment carefully reads and understands
these instructions before starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the spaces
below and retain for future reference.
Model No. _________________________________
Type ______________________________________
Serial No. _________________________________
MODEL PCH3540HR
MODEL PCH3030
Part No. D22885-011-0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D22885-011-0 and is the answer not in the manual?

Questions and answers

Related Manuals for Porter-Cable D22885-011-0

Summary of Contents for Porter-Cable D22885-011-0

  • Page 1 Instruction manual MODEL PCV2021 MODEL PCH2425 To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2001 Porter-Cable Corporation ESPAÑOL: PÁGINA 21 FRANÇAIS: PAGE 41 Pressure Washers MODEL PCH3540HR MODEL PCH2627 IMPORTANT Please make certain that the person who is to use this equipment carefully reads and understands these instructions before starting operations.
