Inflation Option - Intex 620PC Owner's Manual

2. Attach the AC line cord to the pump cord connector and plug into an AC
electrical outlet. See Fig (2 & 3).
3. Press the inflation button (
4. When the airbed is inflated to the desired firmness, press "
Note: The pump will automatically switch OFF after about five and half minutes of
operation when the pump is left unattended.
5. Lie down on the airbed to test the firmness.
6. If the sleeping surface is too hard, adjust the firmness by pressing the slight deflation
button ( ) to release some air. Press again until the desired firmness is achieved.
See Fig (5). If the airbed becomes too soft repeat step #3 thru #6 as necessary.

INFLATION OPTION

1. If electrical power is not available then a conventional foot or manually operated air
pump can be connected to the 2-in-1 valve for inflation.
2. Pull the 2-in-1 inflation valve cap out, insert air pump nozzle into the valve to inflate the
airbed. See Fig (6).
IMPORTANT NOTE
Proper inflation of the airbed.
The ambient temperatures of air have an effect on the airbed internal pressure. At low ambient
temperature the air will contract within the airbed and the airbed will feel softer: add air as
necessary. At high ambient temperature the air within the airbed will expand significantly and the
airbed will become hard and may burst: release air to avoid damage to the airbed or to soften the
feel. Do not expose the airbed to extreme temperatures (hot or cold). Stretching is a natural
characteristic of new vinyl. During initial use, the airbed may become soft and require additional
inflation to maintain desired firmness. This is normal for the first few days of use. Dimensions
shown are approximate and will vary due to the vinyl temperature and the air temperature.
In no event shall Intex, their authorized agents or employees be liable for damages (such
as pin holes) to the airbed caused by negligence, ordinary wear and tear, abuse and
carelessness, or external forces.
SAVE THESE INSTRUCTIONS
(311IO) 620PC BUILT-IN ELECTRIC PUMP ENGLISH 4.875" X 7.25" 07/08/2016
220 – 240 V
√
FIG (2)
) to inflate. See Fig (4).
FIG (4)
FIG (5)
Page 3
110 – 120 V
FIG (3)
" again to switch OFF.
FIG (6)
311
IO
