(108) MODEL 636T FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 04/21/2014
Krystal Clear™
Model 636T Filter Pump
220 - 240 V~, 50 Hz, 165 W
Hmax 1.0 m, H min 0.19 m, IPX5
Max. Water Temperature 35 °C
For illustrative purposes only.
Don't forget to try these other fine Intex products: pools,
pool accessories, inflatable pools and in-home toys, airbeds
and boats available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifications and appearance, which may
result in updates to the instruction manual without notice.
© 2014 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.- Intex
Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle Rechte
vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous licence de/
Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in
Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex
Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l'Union Européenne
par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR
Roosendaal – The Netherlands
www.intexcorp.com
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
English
English
108A
108A
108-*A*-R0-1505
Advertisement
Table of Contents
Related Manuals for Intex krystal clear 636T
Summary of Contents for Intex krystal clear 636T
-
Page 1: Safety Rules
Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR... -
Page 2: Table Of Contents
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A TABLE OF CONTENTS Warnings................3 Parts Reference............... 4-5 Setup Instructions............6-9 Operating Instructions............ 10 Operating Time Table............11 Maintenance..............12-13 Pool Care and Chemicals..........13 Long Term Storage............13 Troubleshooting Guide........... -
Page 3: Warnings
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities. -
Page 4: Parts Reference
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. REF. - Page 5 (108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. REF.
-
Page 6: Setup Instructions
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A POOL OUTLET - STRAINER & PLUNGER VALVE SETUP (optional) The strainer grid prevents large objects from jamming and/or damaging the filter pump. The plunger valve assembly prevents water from flowing into the filter pump while the filter cartridge is being placed or cleaned. - Page 7 (108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A POOL INLET - NOZZLE & PLUNGER VALVE SETUP (optional) 1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer connector (13) (see drawing 5). Be careful not to lose the step rubber washer (10).
- Page 8 (108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A FILTER PUMP HOSE CONNECTION SETUP 1. Remove the Krystal Clear™ filter pump and hoses from the packaging. 2. Place the filter pump in such a manner, that you can easily assemble the hose (7) connections to the plunger valve.
- Page 9 (108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A FILTER PUMP STATIONARY MOUNTING OPTION Some countries, especially in the European community, require the filter-pump to be secured to the ground or to a base in a permanent upright position. Check your local authorities to determine if there is a regulation in your area regarding above-the-ground swimming pool filter-pumps.
-
Page 10: Operating Instructions
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A OPERATING INSTRUCTIONS 1. Make sure the filter pump is switched off. The switch is located on the motor housing. 2. Connect the power cord to a GFCI protected electrical outlet. WARNING Risk of electric shock. -
Page 11: Operating Time Table
Frame Pool and 80% for Easy Set operating hours Pool Size & Oval Pool) per day (Gals) (Liters) (Hours) INTEX ABOVE GROUND POOLS (AGP’s) 18’ x 42” (549cm x 107cm) 4,786 18,115 EASY SET ® POOL 18’ x 48” (549cm x 122cm) 5,455 20,647 18’... -
Page 12: Maintenance
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A CLEANING OR REPLACING FILTER CARTRIDGES It is recommended that the filter cartridge be replaced at least every 2 weeks. 1. Make sure the filter pump is turned off, then disconnect the power cord from the electrical outlet. -
Page 13: Pool Care And Chemicals
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A POOL CARE AND CHEMICALS • All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water. -
Page 14: Troubleshooting Guide
(108) MODEL 636T FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 04/21/2014 English 108A TROUBLESHOOTING GUIDE TROUBLE CAUSE SOLUTION FILTER MOTOR • The motor is not plugged in. • Filter cord must be plugged into a 3 wire FAILS TO START •... -
Page 15: Common Pool Problems
• The drain valves are loose. • Finger tighten all caps. SEDIMENT ON • Dirt or sand on • Heavy use, getting in • Use Intex pool vacuum to clean POOL BOTTOM pool floor. and out of pool. bottom of pool. -
Page 16: Limited Warranty
LIMITED WARRANTY Your Krystal Clear™ Filter-Pump has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the Krystal Clear™...
