MACHINE LAYOUT Security Lock Slide Control Record/Stop/Play/Rewind LED for Record Mode and Low Battery Indication VOX Switch (Voice Activated Control) Dictate/Conference Switch Remote Microphone Jack Microphone Volume Control for Playback Cassette Compartment Speaker AC Adapter Jack Battery Compartment Cassette and Battery Compartment Cover Fast Play and Instruction Cues...
DESCRIPTION The Dictaphone Model 1244 portable recorder is a compact minicassette recorder that provides the following features: • Conference recording • VOX recording • Record indicator • Low battery indicator • Fast play with audible feedback • End-of-cassette warning tone •...
• Insert 2 AAA alkaline batteries (or nickel-cadmium rechargeable battery pack) into battery compartment. The optional AC Adapter can be used instead of batteries to power your Model 1244 portable recorder: To use the optional AC Adapter: • Insert the power cord into the external power jack (DC 3V).
RECORDING AND EDITING Recording Dictation To record dictation: • Move Lock switch left to Off position. • Move the Slide Control up to Rec position. Record LED indicator will illuminate. Reviewing and Correcting To review your dictation: • Move Slide Control down and hold in Rew position.
Page 8
Reviewing and Editing Your Dictation Reviewing: • Move and hold the Slide Control in Rew. Recorded areas on the tape produce audible feedback • Release the Slide Control to begin playback. Adjust the Volume Control as needed. Ending Your Dictation When recording is complete: •...
Page 9
End of Letter Cues The Alert Indexing feature permits you to record cue tones to mark the end of letters. These tones assist the transcriptionist in locating and processing your dictation more efficiently. To record a cue at the end of each letter: •...
• Move the Slide Control to Rec and begin dictating. The Record/Battery LED indicator will illuminate. Conference Recording The Model 1244 minicassette portable recorder can be used to record conferences, meetings, seminars, interviews, etc. To record conferences: • Move the Dict/Conf switch to Conf position.
Page 11
Interview Recording An optional Remote Microphones can be used for interview or conference recording. • Plug the remote microphone into the mic jack. • Move the Slide Control to the Rec position, and hold the microphone about three inches from the person speaking.
Convenience Features • Record Indicator: The red Record indicator (LED) illuminates while you are recording. • Low Battery Indicator: If battery power is too low, the Record LED will not illuminate when you attempt to record. • End-of-Tape-Warning: A warning tone sounds when you reach the end of the tape in Play or REC modes.
Page 13
• Conference Microphone – Compact high sensitivity microphone • Telephone Record Adapter – Permits recording of two-way telephone conversations. • Dictaphone Bulk Eraser – Permits rapid erasure of minicassettes. • M-30 Minicassettes – Box of 5 high quality leaderless minicassettes.
SPECIFICATIONS Height: 114 mm (4.5 in.) Width: 51 mm (2.0 in.) Thickness: 24.5 mm (1.0 in.) Weight: 170g (6 oz.) Power Source: Two 1.5 v AAA or AC adapter Media: M-30 Minicassette Recording Time: 15 minutes per side Tape Speed: 4 cm/sec (1.6 in./sec.
