Connecting the DVC-1000 Videophone

First, place the i2eye VideoPhone directly on top of a television. To

obtain the best viewing experience, the i2eye should be approximately 5

to 10 feet away from where you are viewing it.

Attach the supplied audio/video cable to the i2eye and to the matching

audio/video jacks on the television or VCR.

Attach the supplied Ethernet cable to the i2eye and to the Cable or DSL

modem or Ethernet network device (hub, switch or router).

Attaching a telephone is optional, but recommended for optimal sound

quality when videoconferencing. Attach a standard telephone cable to the

telephone and directly to thei2eye. Do NOT attach the telephone to a

wall telephone outlet.

Plug the supplied AC power cable into an AC outlet and then into the

i2eye.

Attaching an external microphone is optional, but recommended for

optimal sound for a group videoconference.

Sharing a Broadband Connection

With the i2eye DVC-1000

If you are sharing your broadband connection with any other

devices, use additional Ethernet (CAT5 UTP) cables to connect

your broadband equipment to a router or home gateway.

When you have completed the steps in this Quick Installation

Guide, your connected VideoPhone should look similar to this:

Before using your D-Link i2eye VideoPhone, you will want to understand

the network requirements for this device. If you are using a home gateway

or router and sharing the broadband connection with your DVC-1000, please

read Using the DVC-1000 with a Router or Gateway on Page 33 of the

manual included with the DVC-1000.
