SIM508 EVB User Guide
4.3 LCD & ADC
Pin Signal
1 DISP_EN
2 GPIO_5
3 DISP_CLK
4 BUZZER
5 DISP_D0
6 AUXADC1
7 DISP_A0
8 SIM_PRESENCE
9 NCLDRESET
10 TEMP_BAT
SIM508-EVB_UGD_V1.01
Figure 16: LCD & ADC interface
I/O
O
I/O
O
O
I/O
I
O
I
O
I For measure the batter temperature
Page 19 of 25
Description
Display enable output
GPIO5 reserved for user
Display clock output
Buzzer output.
Display data line
Adc input
Display data or address select
SIM Card Detection
Display reset outplay
SIMCOM
