Handle Bar Controls - motogadget m.unit blue Operating And Installation Manual

8.6 Connecting Battery's Positive Terminal
Cable connection has to be carried out as shown in the drawing at the right side. The minimum
wire cross section must no go below 10mm². The cable end has to be supplied with an eyelet and
will be mounted with a M5 screw to the m-Unit. The maximum torque applied to the M5 fastening
screws must not exceed 4 Nm. Screw adhesive medium strength must be applied to the screw
prior installation.
MAKE SURE THE EYELET IS INSULATED IN A PROPER WAY AND CANNOT GET IN
CONTACT TO OTHER PARTS CONNECTED TO VEHICLE GROUND.

8.7 Handle Bar Controls

Three different types of handle bar controls are compatible with m-Unit. The particular type which
will be used with m-unit must set in the setup menu.
Configuration A) – 5-push button controls
- turn lights left
- turn lights right
- low beam / high beam
- start
- horn
Configuration B) – Harley Davidson and BMW controls
- turn lights left
- turn light right
- low beam / high beam
- start
- horn
Configuration C) – most Japanese and European motorcycles
- turn lights left / right
- low beam / high beam
- start
- horn
configuration D) – new Ducati models
- turn lights left / right
- low beam / high beam
- start
- horn
configuration E) – 4-push-button controls
- turn lights left
- turn lights right
- low beam / high beam
- horn
- start
- kill switch
In case of using the OEM handle bar controls together with m-Unit; head light flashing push button
is not applicable. There is also no possibility to switch the parking light by the m-Unit.
Additional safety switches like side stand switch have to be connected as shown in chapter 8.9.
- push button
- push button
- push button
- push button
- push button
- push button
- push button
- switch
- push button
- push button
- 3 way switch
- switch
- push button
- push button
- 3 way switch
- push button
- push button
- push button
- push button
- push button
- push button
- push button
= left turn + light simultaneously
= right turn + light simultaneously
