- Page 1 Instruction manual mo.rear rear light module V1.0...
- Page 2 Thank you for choosing a quality product from motogadget. All motogadget products are developed and manufactured in Germany. Please read the following information and recommendations thoroughly and follow these in- structions during installations and use of the product. No liability shall be assumde by motoga- dget for damage or defects resulting from negligence or failure to follow the operating and installation guide.
- Page 3 In this regard, we refer to our General Terms of Business and Delivery, which are published at www.motogadget.com. Should a return of the received delivery be agreed, please note that we only take back goods in their original packaging. The mo.switch and its accessories must be returned within the legal period of time and without any traces of use.
- Page 4 • IT IS NOT POSSIBLE TO USE THE MO.REAR AT VEHICLES WITH POSTIVE BATTERY POLE FOR VEHICLE GROUND. • IT IS NOT POSSIBLE TO USE THE MO.REAR ON VEHICLES WITH A 6V ELECTRICAL SYSTEM. • IT IS NOT POSSIBLE TO USE THE MO.REAR ON VEHICLES WITHOUT BATTERY.
- Page 5 4. Features mo.rear is an all-in-one vehicle tail light unit for motorcycles for use within the EU. When attached to the vehicle in a compliant manner, the light unit complies with the applica- ble EU directives and regulations. There is no obligation to register and no documents need to be carried.
- Page 6 6. Installation according to Category 1 approval (license plate size 240x130mm) The mo.rear is attached to the rear of the vehicle centrally above the license plate using 2 pieces M4 or M5 screws according to the following sketch:...
- Page 7 7. Electrical Connection The individual wires are connected as follows: • black: vehicle ground • red: brake light • yellow: taillight & license plate light • green: left turn signal • white: right turn signal 8. Important Instructions • The light module must be installed in center and above the license plate, as shown in the installation sketch.
- Page 8 We wish you a safe ride and look forward to your positive review. If you are not satisfi ed, please give us the opportunity to correct it and contact service@motogadget.de.
