GIGA-TMS Mini400B series User Manual

Portable msr reader with rechargeable battery and bluetooth
Hide thumbs

Advertisement

Quick Links

Download this manual
*** USER' S MANUAL ***
FCC ID: WXAMINI400B

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mini400B series and is the answer not in the manual?

Questions and answers

Related Manuals for GIGA-TMS Mini400B series

Summary of Contents for GIGA-TMS Mini400B series

  • Page 1 *** USER’ S MANUAL *** FCC ID: WXAMINI400B...
  • Page 3 TM951241 - 1 -...

  • Page 4: Specifications

    Information ..................Technical And Operational Description ........................... Connections ................Card Data Format ..................Specifications Communication Protocol ..............FCC COMPLIANCE STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 5 Mini400B Series Magnetic Swipe Reader MACHINE TYPE FUNCTION Muti-Charge F - MEM Li-Polymer Rechargeable 512 KB 1 2 3 BlueTooth LED STATUS 2048 REC QUEUE AUTO Ver 1.1 Mini400B VER 1.2 Track 1 & 2 & 3 Bluetooth adaptor Installation Refer to page10...
  • Page 6 Information Lithium Ion Polymer Battery Handling Guideline Danger ! It may cause the battery swelling, leaking, explosion or ignition, if you do not reading following: 1. Do not store battery in a manner that allows terminals to short. 2. The cell batteries are requested to be stored within a proper temperature range specified in this specifications. 3.
  • Page 7 Information Standard Package CD-ROM ( DISK5269 ) Main unit ( Mini400B ) Chain Sling ( TM09F1001 ) Option Li-Polymer Rechargeable Battery 3.7V 250mAH USB Cable ( BAT-T0011 ) ( WAS-T0233 ) - 5 -...
  • Page 8 Front Panel Display and Operations Battery Box Power & Control Button Connector Card Reader Bluetooth & Battery Power ,Memory ,Read Status Status LED indicator LED indicator Card Reader Swipe the card through the entire length of the slot to read. Power,Memory,Read Status LED Indicator When encountering erroneous input, defective card, misread,bad memory or incorrectly encoded data and so on, the device will turn on...
  • Page 9 Technical And Operational Description Display Information Power,Memory,Read Status LED Indicator Status Green LED Red LED Buzzer Read Card Take turns blink Power On Beep. Beep. 2 times Take turns blink Auto Power Off Beep. Beep. 2 times Ready Blink Read OK Beep.
  • Page 10 Technical And Operational Description Operational Description 1. Powered by Battery For normal use, the unit is powered by battery. Push the Power Switch Button for about 1.5 seconds to turn on the unit. Also push the Power Switch Button for about 1.5 seconds to turn off the unit.
  • Page 11 Connections WAS-T0233 USB 4P FEMALE PIN FUNCTION MINI USB 4P FUNCTION Connect to PC PORT Personal Computer Mini400B Note: 1. When Mini400B is connected/disconnected to USB port, it would be turned On/Off automatically. 2. Normally the charging time is about 1.5 ~ 2.5 hours (Default setting is low battery charge mode, it is detected when the battery is low, it would be charge until Full automatically).
  • Page 12 CARD DATA STRING TRACK 1 TRACK 2 TRACK 3 DATE & TIME TRACK1 DATA TRACK2 DATA TRACK3 DATA DATE TIME WEEK TRACK1 DATA TRACK2 DATA TRACK3 DATA DATE TIME WEEK TRACK 1 CARD ID Track 1 IATA Bits Per Inch Bits Per Character 1.
  • Page 13 Magnetic Stripe Card : TRACK 1 / IATA / 210 bpi / 79 Alphanumeric Characters 1 2 3 TRACK 2 / ABA / 75 bpi / 40 Numeric Characters TRACK 3 / Thrift / 210 bpi / 107 Numeric Characters Bluetooth Interface : BlueTooth SPP Profile ,Class 2 ,Compatible Bluetooth V2.0+EDR,V1.2,V1.1...
  • Page 14 GNET FEATURES Support TTY (TELE TYPE) OPERATION - Use TTY to send commands and messages. Simple handshaking - One enquiry one answer back. Multi-link capability Expandability - GNET provides 4 major functions: 1. POLLING 2. LOGIN / LOGOUT 3. DATABASE 4.
  • Page 15 Communication Protocol Command Index Table Topic Command Contents Description 4 Characters for Login(0000) Login Logout New four digit password Set Password Get Register SETTING Set register Get Product Version Date,Time,Week Set Date,Time and Week Get Date and Time Get Number of Record DATABASE Number Read Record by Number...
  • Page 16 Communication Protocol 1. GET NUMBER OF RECORD : NUMBER CHKSUM NUMBER Record Count . 4 Bytes Width ( 0000h ~ 0080h ) EXAMPLE 000C The Total of Record Count : 12 2. READ RECORD BY NUMBER : NUMBER NUMBER DATA CHKSUM NUMBER Record Count .
  • Page 17 Communication Protocol 4. SET DATE AND TIME : YYYYMMDDhhmmssw Week YYYY Year (1980 - 20xx ) Month (01 - 12 ) Date ( 01 - 31 ) Hour ( 00 - 23 ) Mintue ( 00 - 59 ) Second ( 00 - 59 ) Week ( 1 - 7 ) EXAMPLE 200005051230006...
  • Page 18 Communication Protocol EXAMPLE V1.0R00 Firmware Version = 1.0 Modify times = 0 7. SET REGISTER : REGISTER PARAM CHKSUM REGISTER Register Address . 2 Bytes Width ( 00h ~ FFh ) PARAM Set Parameters of Register CHKSUM C + REGISTER + , + PARAM 7-1.
  • Page 19 Communication Protocol EXAMPLE Modem : 2400 Non- modem : 9600 Write to Parameter Table Address : 10 h Auto Power Off Time (Low Byte) : 5 Seconds 7-3. SET AUTO POWER OFF TIME (HIGH BYTE) : SECH CHKSUM SECH "00-FF" (00-FF)/2 *256 Seconds EXAMPLE Modem : 2400...
  • Page 20 Communication Protocol 7-5. SET TRACK ACTIVE MODE : TRACK MODE CHKSUM TRACK MODE "30" TRACK 1 "FF" ENABLE "31" TRACK2 "00" DISABLE "32" TRACK3 "01" REQUIRED EXAMPLE Write to Parameter Table Address : 30 h TRACK ACTIVE MODE : TRACK 1 ENABLE . 7-6.
  • Page 21 Communication Protocol 8. GET REGISTER : REGSTER PARAM CHKSUM REGSTER Register Address . 2 Bytes Width ( 00h ~ FFh ) PARAM Set Parameters of Register 8-1. GET POWER MODE : MODE CHKSUM Same 7-1. SET POWER MODE EXAMPLE Write to Parameter Table Address : 12 h Get Power Mode : Real Control 8-2.
  • Page 22 Communication Protocol 8-3. GET AUTO POWER OFF TIME (HIGH BYTE) : SECH CHKSUM Same 7-3. SET AUTO POWER OFF (HIGH BYTE) EXAMPLE Get Parameter From Parameter Table Address : 11 h Auto Power Off Time Period (High Byte) : 2*256/2 Seconds 8-4.
  • Page 23 Communication Protocol 9. LOGIN : PASSWORD PASSWORD 4 Characters for Login. 0000=Initial value EXAMPLE 0000 Login password : 0000 10. LOGOUT : EXAMPLE Logout 11. SET PASSWORD : PASSWORD CHKSUM PASSWORD New four digit password EXAMPLE 1234 Set new password : 1234 - 21 -...
  • Page 24 Communication Protocol 12. GET/SET BLUETOOTH NAME(only workable with cable WAS-T0233) NAME NAME default setting=MINI400 EXAMPLE MINI400B G=GET S=SET 12-1. GET/SET BLUETOOTH PIN CODE(only workable with cable WAS-T0233) PIN CODE NAME default setting=MINI400 EXAMPLE 1234 G=GET S=SET Set new PIN CODE : 1234 12.
