Page 1: Service Manual
SERVICE MANUAL CTM6850S 68 CM CTV Effective: NOV01 CTM6850SERV... -
Page 17: Description Qty
SPRAYED "MITSUBISHI IýC" HANDSET REAR CAB - 1008K SILVER 902-R83301-10 SPRAYED 910-R83301-12 BATTERY DOOR - 1008K SILVER SPRAYED R/TO DOOR-TEAC DESIGN {RC-787} {CT- 919-R83310-25 M6850S} W/SILVER 1008K SPY FOR JACK PLATE TO REAR 509-305010-00 MACHINE SCREW 3 X 10 KM (BLACK) CAB. - Page 18 PART NUMBER DESCRIPTION LOCATION 35MM SOLDERING LUG OD:7 ID:3.2 750-063102-01 FOR SPK.WIRE LEG:4X35MM 777-733A01-00 FOR POWER KNOB SPRING ID=10.0MM L=22.0MM 826-432005-00 FOR UNIT TOP FOAM SHEET - 43" X 20" X 0.5MM THK 834-210803-00 FOR CRT MTG. RUBBER WASHER OD=21 ID=8 T=3.0 840-051030-11 RUBBER PAD (ONE SIDE W/TAPE) FOR CRT...
- Page 19 {240V} 140W I/MANUAL - TEAC DESIGN {CT-M6850S} 670-202900-13 {220P.} SCREEN STICKER - TEAC DESIGN {CT- 678-202901-02 M6850S} TOTAL CARE LABEL - TEAC (E) DESIGN (MC- 678-868A01-31 D48) 690-931339-02 WARRANTY CARD- TEAC (D) DESIGN EAN CODE LABEL - 9325073003330 {TEAC 693-202901-04...
- Page 20 CYCLING P.E.MARK POLYBAG 50"X55"X0.04MM PE MAT. TEAC 810-505504-1B FOR UNIT DESIGN {CT-F6805S} 884-2029C3-02 PRESET PLATE - TEAC DESIGN {CT-M6850S} SIDE JACK COVER - ENG STD W/SS.(AV 884-382524-02 2IN)(4 KEYS) 884-729A43-02 JACK COVER - TEAC DESIGN {CT-F683) FRONT CABINET (C) - SILVER 1008K 900-202921-01 SPRAYED W/GREY 433C SS.
- Page 21 PART NUMBER DESCRIPTION LOCATION CARBON FILM RESISTOR 10 OHM 1/4W +- 113-100105-17 R238,242 METAL OXIDE FILM RESISTOR 10 OHM 3W +- 113-100505-75 R422,411 R123,141,173,174,180,194,19 CARBON FILM RESISTOR 100 OHM 1/16W +- 113-101005-17 CARBON FILM RESISTOR 100 OHM 1/16W +- 113-101005-17 R201,202,207,239,240,247 CARBON FILM RESISTOR 100 OHM 1/16W +- 113-101005-17...
- Page 22 PART NUMBER DESCRIPTION LOCATION CARBON FILM RESISTOR 12K OHM 1/4W +- 113-123105-17 R974 METAL OXIDE FILM RESISTOR 12K OHM 2W 113-123405-75 R970,971 +-5% CARBON FILM RESISTOR 120K OHM 1/16W 113-124005-17 R413 +-5% CARBON FILM RESISTOR 1.2 OHM 1/4W +- 113-129105-17 R248 CARBON FILM RESISTOR 150 OHM 1/16W +- 113-151005-17...
- Page 23 PART NUMBER DESCRIPTION LOCATION METAL OXIDE FILM RESISTOR 27 OHM 2W +- 113-270405-75 R910 113-270605-75 R980 METAL OXIDE FILM RESISTOR 27 OHM 5W CARBON FILM RESISTOR 270 OHM 1/16 W +- 113-271005-17 R241,414 CARBON FILM RESISTOR 2.7K OHM 1/2W +- 113-272205-12 R415 CARBON FILM RESISTOR 27K OHM 1/16W +-...
- Page 24 PART NUMBER DESCRIPTION LOCATION CARBON FILM RESISTOR 4.7K OHM 1/16W +- 113-472005-17 R265,266,02,03,254,255 CARBON FILM RESISTOR 4.7K OHM 1/4W +- 113-472105-17 R908 CARBON FILM RESISTOR 47K OHM 1/16W +- 113-473005-17 R270,25,26,28,29,31,32,34,35 CARBON FILM RESISTOR 4.7 OHM 1/4W +- 113-479105-17 R406 METAL OXIDE FILM RESISTOR 4.7 OHM 5W 113-479605-75 R427...
- Page 25 PART NUMBER DESCRIPTION LOCATION CERAMIC CAP. 1200PF 500V +-10% "YINAN 123-122550-95 C418 DON'S" 123-150340-93 C160,161,138 CERAMIC CAP. 15 PF 50V +-5% (NPO) 123-151350-60 C204 CERAMIC CAP 150 PF 50V +-10% (SL TYPE) CERAMIC CAP. 0.0015 MFD 2KV +-10% 123-152850-10 C434 MATSUSHITA 123-180340-93 C137...
- Page 26 PART NUMBER DESCRIPTION LOCATION POLYPROPYLENE CAP. 0.36 MFD 250V +- 126-364211-31 C408 MYLAR CAP. 0.0047 MFD 50V +-10% 126-472071-01 C128,130 ***AUDIO NOT USER*** MYLAR CAP. 0.047 MFD 50V +-10% ***AUDIO 126-473071-01 C148 NOT USER*** POLYPROPYLENE CAP. 0.047 MFD 200V +- 126-473201-35 C419 10% "XIAMEN FALA"...
- Page 27 PART NUMBER DESCRIPTION LOCATION D101-104,106-111,114- 130-134148-01 SILICON DIODE IN4148 116,195,507-510 130-240809-50 VERIABLE CAPACITANCE DIODE BB809 D112-113 130-310021-00 RECTIFIER DIODE EGIZ SANKEN D970,975,976 130-310021-50 RECTIFIER DIODE BAV21 PHILIPS {TAPING} D501,502,503,414 130-310228-50 DAMPER DIODE BY228 "PHILIPS" {TAPING} D402 RECTIFIER DIODE 3JH45 TOSHIBA 3.0A 130-310345-00 D401,906 600V...
- Page 28 PART NUMBER DESCRIPTION LOCATION REMOTE CONTROL RECEIVER HS0038A2 136-500038-00 OPT602 (ON SENSOR PCB) "TEMIC" 137-245760-31 X105 CRYSTAL 24.576 MHZ 20PF "ZHUHAI HOPE" 137-357954-20 X102 CRYSTAL 3.579545 MHz "KOWHA" CRYSTAL 4.433619 MHZ 20PF +-30PPM 137-443619-26 X101 "JIANG CHANG" 137-800000-20 X103 CRYSTAL 8.0 MHZ KITRONICS S608-610,104-107 (ON TACT SWITCH 4 PINS L=11 MM KFC-A06-L11 146-104002-00...
- Page 29 PART NUMBER DESCRIPTION LOCATION UL 1007 TOP COAT WIRE AWG 26 160MM 172-626016-40 FOR MAIN PCB `C' TO `C' BLACK 10 X 10 MM FOR SPEAKER TO SPEAKER 172-626020-40 UL 1007 TOP COAT WIRE AWG 26 200MM GRILLE 172-626020-40 FOR MAIN PCB `A' TO `A' UL 1007 TOP COAT WIRE AWG 26 200MM W03-04,06-16,094,101- 172-726000-99...
