Page 1: Service Manual
SERVICE MANUAL CTM5950S 59 CM CTV Effective: NOV01 CTM5950SERV... - Page 17 REMOTE TOP CAB. - SILVER 1008K SPRAYED 900-R83301-75 "MITSUBISHI IýC" 902-R83301-10 HANDSET REAR CAB - 1008K SILVER SPRAYED 910-R83301-12 BATTERY DOOR - 1008K SILVER SPRAYED R/TOP DOOR-TEAC DESIGN(RC-811) (CT- 919-R83310-26 M5950S)(SILVER 1008K) FOR FRONT CAB TO 514-400425-10 SELF-TAPPING SCREW 4 X 25 B/T (HARDEN) REAR CAB.
- Page 18 PART NUMBER DESCRIPTION LOCATION 800-202501-00 POLYFOAM BOTTOM (C)- LEFT 800-202502-00 POLYFOAM BOTTOM (C) - RIGHT 800-202503-00 POLYFOAM TOP (C) - LEFT 800-202504-00 POLYFOAM TOP (C) - RIGHT POLYBAG 5" X 22" X 0.04MM W/RE-CYCLING 810-052204-14 FRO AC LINE CORD MARK {P/O MAT} 826-432005-00 FOAM SHEET - 43"...
- Page 19 PART NUMBER DESCRIPTION LOCATION PIN CONNECTOR 2 PINS PLUG STRAIGHT (UL) CN333,335,(CN601,602 ON 160-102255-27 (S.H.S) SIDE AV PCB) 160-104255-27 PIN CONNECTOR 4 PINS PLUG (SHS) CN334 161-121402-00 MINI JACK #HSJ0914-01-040 (HOSIDEN) (EP601 ON SIDE AV PCB) RCA JACK 2 PIN (YELLOW) ANGLE AV-8.4-6Y 161-470003-09 (J14 ON SIDE AV BOARD) "LOQING CHENGFENG"...
- Page 20 GIFT BOX - TEAC DESIGN (CT-M5950S)(H3A3A3H) 2-ON L & R SIDES OF 663-230157-01 SERIAL NO.LABEL - TEAC DESIGN CTN,1-R/LABEL,1- WARRANTY CARD RATING LABEL - TEAC DESIGN (CT-M5950S) 240V 669-2025C1-03 130W I/M - TEAC DESIGN (CT-M5950S) "MITSUBISHI 670-202500-05 IýC" 220P. 678-202502-01...
- Page 21 PART NUMBER DESCRIPTION LOCATION 105-109103-08 FIXED INDUCTIVE COIL 1.0UH +-10% (WITTIS) R236,237 FIXED INDUCTIVE COIL 18 UH +-10% 0410 105-180103-08 L106 "WITTIS" CHOKE COIL 200UH 10% CH9012- 201K (ELEC 105-201106-02 L403,904,W255 PRODUCT) 105-500052-06 LINEARITY COI 50UH LX14I242B "HIGHLIGHT" L401 FIXED INDUCTIVE COIL 6.8UH 10% AL0305-6R8K 105-689103-16 L104 "BOLUO DUIWANG"...
- Page 22 PART NUMBER DESCRIPTION LOCATION 113-122005-17 CARBON FILM RESISTOR 1.2K OHM 1/16W +-5% R269,285 113-122105-17 CARBON FILM RESISTOR 1.2K OHM 1/4W +-5% R976 113-123005-17 CARBON FILM RESISTOR 12K OHM 1/16W +-5% R203 113-123105-17 CARBON FILM RESISTOR 12K OHM 1/4W +-5% R974 113-123405-75 METAL OXIDE FILM RESISTOR 12K OHM 2W +-5% R970,971...
- Page 23 PART NUMBER DESCRIPTION LOCATION WIRE WOUND CEMENT RESISTOR 2.2 OHM 5W +- 113-229605-51 R944 113-243105-17 CARBON FILM RESISTOR 24K OHM 1/4W +-5% R979 113-270405-75 METAL OXIDE FILM RESISTOR 27 OHM 2W +-5% R910 113-270605-75 METAL OXIDE FILM RESISTOR 27 OHM 5W R980 113-271005-17 CARBON FILM RESISTOR 270 OHM 1/16 W +-5%...
- Page 24 PART NUMBER DESCRIPTION LOCATION 113-472005-17 CARBON FILM RESISTOR 4.7K OHM 1/16W +-5% R265,266,02,03,254,255 113-472105-17 CARBON FILM RESISTOR 4.7K OHM 1/4W +-5% R908 R270,25,26,28,29,31,32,34, 113-473005-17 CARBON FILM RESISTOR 47K OHM 1/16W +-5% 113-479105-17 CARBON FILM RESISTOR 4.7 OHM 1/4W +-5% R406 113-479605-75 METAL OXIDE FILM RESISTOR 4.7 OHM 5W +-5% R427...
- Page 25 PART NUMBER DESCRIPTION LOCATION CERAMIC CAP. 1200PF 500V +-10% "YINAN 123-122550-95 C418 DON'S" 123-150340-93 CERAMIC CAP. 15 PF 50V +-5% (NPO) C160,161,138 123-151350-60 CERAMIC CAP 150 PF 50V +-10% (SL TYPE) C204 CERAMIC CAP. 0.0015 MFD 2KV +-10% 123-152850-10 C414,434 MATSUSHITA 123-180340-93 CERAMIC CAP.
- Page 26 PART NUMBER DESCRIPTION LOCATION 126-364211-31 POLYPROPYLENE CAP. 0.36 MFD 250V +-10% C408 MYLAR CAP. 0.0047 MFD 50V +-10% ***AUDIO 126-472071-01 C128,130 NOT USER*** MYLAR CAP. 0.047 MFD 50V +-10% ***AUDIO NOT 126-473071-01 C148 USER*** POLYPROPYLENE CAP. 0.047 MFD 200V +-10% 126-473201-35 C419 "XIAMEN FALA"...
- Page 27 PART NUMBER DESCRIPTION LOCATION 130-314004-00 RECTIFIER DIODEN 1N4004 D512 D403- 130-315295-00 RECTIFIER DIODE S5295G TOSHIBA 407,901,902,905,909,910 130-410036-00 ZENER DIODE 3.6V 1/2W ZD103 130-410039-01 ZENER DIODE 3.9V {TAPING} ZD901 130-410056-01 ZENER DIODE 5.6V {TAPING} ZD902 130-410068-01 ZENER DIODE 6.8V 1/2W +-5% {TAPING} ZD503 130-410082-01 ZENER DIODE 8.2V {TAPING}...
- Page 28 PART NUMBER DESCRIPTION LOCATION 160-102805-08 PIN CONNECTOR 2 PIN PLUG STRAIGHT CN903 160-103255-27 PIN CONNECTOR 3 PINS PLUG CN103,105,106,110 160-103805-08 PIN CONNECTOR 3 PIN PLUG STRAIGHT CN403,402 160-104254-27 PIN CONNECTOR 4 PINS PLUG (ANGLE TYPE) J903 160-104255-27 PIN CONNECTOR 4 PINS PLUG (SHS) CN113,115,404 160-104805-08 PIN CONNECTOR 4 PIN PLUG STRAIGHT...
- Page 29 PART NUMBER DESCRIPTION LOCATION (W901,906,907,909 ON 172-726000-99 BARE WIRE 54MM POWER PCB) 172-830120-99 FLAT BRIDED WIRE 2.7 FOR CRT GROUND 20MM FOR D906,10MM- 179-001010-00 OIL SLEEVING 1 mm DIA. C907,40MM- R970,R971,30MM-R427 179-105000-00 UL PVC TUBE 5mm DIA 0.2 FOR CN901,902 500MM FOR LEFT 179-105000-00 UL PVC TUBE 5mm DIA...
- Page 30 PART NUMBER DESCRIPTION LOCATION CN115 TO CHANNEL 191-401041-10 4 PIN FLAT CABLE L=250MM BOARD `1' TO `E',`2' TO `F', 191-401041-10 4 PIN FLAT CABLE L=250MM `3' TO `G',`4' TO `H' 4 PIN L=220MM AWG26 UL1185 W/ TRIPLE 191-401232-10 CN07 TO J903 SHIELD WIRE,1 SIDE PLUG 191-501026-10 5 PIN SOCKET ASS'Y L=480MM (FLAT CABLE)
- Page 31 PART NUMBER DESCRIPTION LOCATION 750-063101-00 SOLDERING LUG LEG:8X4MM FOR Q403,Q909 35MM SOLDERING LUG OD:7 ID:3.2 750-063102-01 FOR AC LINE CORD LEG:4X35MM 766-686801-00 FUSE HOLDER F901 779-882001-01 IRON HEAT SINK (D) FOR IC404 779-882803-02 IRON HEAT SINK IC108 779-882803-03 IRON HEAT SINK {NEW} IC501 ALUMINIUM HEAT SINK - (MODIFY BY 781-932803- 781-932803-06...
- Page 32 PART NUMBER DESCRIPTION LOCATION FUSE 4A/250V 5 X 20MM SLO-BLO #218004 182-224000-33 # F901 LITTELFUSE # FROM POWER SWITCH 1 PIN DOULBE INSOLATION WIRE #18 UL1672 191-101024-10 TO CN901 ON POWER L=750MM BLUE # FROM POWER SWITCH 1 PIN DOUBLE INSOLATION WIRE #18 UL1672 191-101023-10 TO CN902 ON POWER L=750MM BROWN...
