Bluetooth Serial Adapter
FB100AS User Guide
Version 1.0
During transmitter operation, in order to meet RF Maximum permissible Exposure Safety
Guidelines, a minimum distance of 20cm shall be maintained between antenna and personnel.
Firmtech Co., Ltd
B-606, Ssangyong IT Twin Tower, Sangdaewon-dong, 442-5
Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea 462-120
Tel : +82-31-719-4812
Fax : +82-31-719-4834
Marketing Inquiry : contact@firmtech.co.kr
Technical Support Inquiry : techsupport@firmtech.co.kr
www.firmtech.co.kr
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Firmtech FB100AS
Summary of Contents for Firmtech FB100AS
- Page 1 Guidelines, a minimum distance of 20cm shall be maintained between antenna and personnel. Firmtech Co., Ltd B-606, Ssangyong IT Twin Tower, Sangdaewon-dong, 442-5 Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea 462-120 Tel : +82-31-719-4812 Fax : +82-31-719-4834 Marketing Inquiry : contact@firmtech.co.kr Technical Support Inquiry : techsupport@firmtech.co.kr www.firmtech.co.kr...
-
Page 2: Revision History
Version 1.0 History FB100AS User Guide Revision Revision History Revision Date Change Descriptions 01-04-2009 - Write a draft 페이지 2 / 27... - Page 3 Any part or whole of products or operation description shall not be copied, reproduced, translated, nor transformed into readable form by electronic device or machines, without prior consent in writing by Firmtech Co., Ltd There might be some misprinting or technical faults in the products and operation description which are subject to change without prior notice.
-
Page 4: Table Of Contents
1.1 Features of Bluetooth ............................5 1.2 Operation of Bluetooth .............................5 2 Porducts Overview ................................6 3 PRODUCT COMPONENTS .............................7 3.1 Basic Components of FB100AS ........................7 4 Product Appearance ................................8 5 Interface ....................................9 5.1 FB100AS Interface ..............................9 5.2 Pin Connection ..............................10 6 Features of Dip Switch .............................. -
Page 5: What Is Bluetooth
Version 1.0 What is Bluetooth? FB100AS User Guide 1 What is Bluetooth? 1.1 Features of Bluetooth Objectives of Bluetooth : To Realize Wireless Communication for Short Distance with Low Power Consumption, High Reliability, and Low Cost. Frequency in Use: To Use ISM(Industrial, Scientific, Medical) Band which does not require any permission to use. -
Page 6: Porducts Overview
Selectable Power Supply between D-Sub 9 pin Connector and USB Connector Stable Data Transmission / Receipt ※ We request the new users of FB100AS to read the information on this description carefully before they start to use the products. 페이지 6 / 27... -
Page 7: Product Components
FBA004DA (4dBi Dipole Ant) (Operation Manual and Test Program) <Table 3-1 Basic Components of FB100AS> ※ If you find any of above components is defective, or not included in the package, please contact the seller you purchased. 페이지 7 / 27... -
Page 8: Product Appearance
Version 1.0 Product Appearance FB100AS User Guide 4 Product Appearance <Figure 4-1 Details and Dimension of FB100AS> 페이지 8 / 27... -
Page 9: Interface
Version 1.0 Interface FB100AS User Guide 5 Interface 5.1 FB100AS Interface <Figure 5-1 D-SUB 9 Pin Connector> INPUT/OUTPUT PIN NO. NAME OF SIGNAL FUNTION DIRECTION CONNECT_CHECK 1:N - Connect Check Output 1:1 - Data Carrier Detect Transfer Data Output Data output... -
Page 10: Pin Connection
Version 1.0 Interface FB100AS User Guide 5.2 Pin Connection 5.2.1 Connection Diagram with Flow Control <Figure 5-2 FB100AS Connection Diagram with Flow Control> 5.2.2 Connection Diagram without Flow Control <Figure 5-3 FB100AS Connection Diagram without Flow Control> 페이지 10 / 27... - Page 11 Version 1.0 Interface FB100AS User Guide 5.2.3 Connection Diagram with 1:N Function <Figure 5-4 Connection Diagram with 1:N Function> Note : If Flow Control is not required, communication can be achieved with only RX, TX, and GND connected to the Host.
-
Page 12: Features Of Dip Switch
Version 1.0 Features of Dip Switch FB100AS User Guide 6 Features of Dip Switch <Figure 6-1 Features of Dip Switch> 6.1 Dip Switch 1 (FUNCTION Switch) FEATURES BASIC SET D-SUB Power Supply or Selectable Power Supply USB Power Supply USB Power Supply... -
Page 13: Dip Switch 2 (Baud Rate Switch)
Version 1.0 Features of Dip Switch FB100AS User Guide 6.2 Dip Switch 2 (Baud Rate Switch) 2400bps 4800bps 9600bps 19200bps 38400bps 57600bps 115200bps 230400bps <Figure 6-3 Transmission Rate> 6.3 Initial Set Value of Dip Switch TYPE Function Switch Baud Rate Switch FB100AS <Table 6-2 Initial Set Value of Dip Switch>... -
Page 14: Power Indicator Led / Status Led
Version 1.0 Power Indicator LED / Status LED FB100AS User Guide 7 Power Indicator LED / Status LED <Figure 7-1 Appearance of FB100AS> LED TYPE STATUS DESCRIPTION Power Indicator LED Power Input The Red Light Turns on (Power LED) Connecting to Bluetooth... -
Page 15: Performance Of Product
Operating -20℃ ~ +55℃ Temperature Limit Operating -30℃ ~ +80℃ Communication Speed 1,200bps – 230,400bps Antenna Dipole Antenna Interface 9 pin D-SUB Female (RS232) Flow Control RTS, CTS, DTR, DSR support <Table 8-1 Performance of FB100AS> 페이지 15 / 27... -
Page 16: Current Consumption
Master Slave Power save Master <Table 9-1 Current Consumption of FB100AS> TEST CONDITIONS Baud rate : 9600 bps, Input Voltage : DC 5V The power consumption is subject to change depending on the transmission rate and volume of data. 페이지 16 / 27... -
Page 17: Initial Set Value Of Products
Operation Mode MODE0 (1:1 통신) Debug Char 0x02 <Table 10-1 Initial Set Values of FB100AS> The Operating Set Values of Products is changeable by using Dip Switch or PC software (Window Hyper Terminal, or FIRMTECH PC Configuration Program.) Note : Please refer to 12 PC Configuration for details on changing the setting. -
Page 18: Bluetooth Pairing
Version 1.0 Bluetooth Pairing FB100AS User Guide 11 Bluetooth Pairing 11.1 Configuration using Dip Switch 11.2 Configuration using C-WIZARD 페이지 18 / 27... -
Page 19: How To Complete Pc Configuration
12.1 PC Configuration using BTConfig tool (1) Please provide FB100AS with power, then check if the Status LED of FB100AS is flickering or not. If red LED is flickering, turn off the power and set the fourth of FUNCTION Dip-Switch at OFF position. - Page 20 Version 1.0 How to complete PC Configuration? FB100AS User Guide <Figure 12-2 BTConfig tool CONNECT display> <Figure 12-3 Connection Display of BTconfig tool> (4) If above <Figure 12-2> appears on the display, select the red lined square 1 ~ 3, and press CONNECT button(red lined square 4), then the Serial Connection, Ready To Set (red lined box 1) will be turned into green color as shown on <Figure 12-3>.
-
Page 21: Pc Configuration Using Serial Communication (Hyper Terminal) Program
To set up PC Configuration using Hyper Terminal, following procedures shall be performed prior to the power is being supplied after the FB100AS is connected to the PC. To set up PC Configuration, the Serial Communication Program is required. We will use Hyper Terminal in describing the procedures. - Page 22 Terminal], then connection window will appear on which enter appropriate name and click. <Figure 12-7 Hyper Terminal Set up Window 2> (3) When the <Figure 12-7> comes up, select the COM port connected to FB100AS, and clicks the OK button.
- Page 23 Version 1.0 How to complete PC Configuration? FB100AS User Guide <Figure 12-8 Hyper Terminal Set up Window 3> (4) When Registration Information Window comes up as on <Figure 12-8>, select Bit per second : 9600, Data bit : 8, Parity : none, Stop bit : 1, Flow control : none, which will execute Hyper Terminal.
- Page 24 Now the Hyper Terminal program setting procedure is completed to use PC Configuration. (7) If the Power is approved for FB100AS, the menu such as <Figure 12-11> will appear on the Hyper Terminal. <Figure 12-11 Pc Configuration Menu>...
- Page 25 “Retry >” message appeared as well. Upon completion of PC Configuration setting up, turn off the FB100AS, and change the Function Dip Switch #4 (PC configuration) to OFF position and turn the power ON, which will start the Bluetooth to operate normally.
-
Page 26: Approval Information
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected Consult the dealer or an experienced radio/television technician for help. 13.3 CE Hereby, Firmtech Co., Ltd, declares that this FB100AS is in compliance with the essential requirements and other relevant provisions of directive 1999/5/EC. 페이지 26 / 27... -
Page 27: Telec
Version 1.0 Approval Information FB100AS User Guide 13.4 TELEC 13.5 SIG 페이지 27 / 27...
