Arkon SLIM-GRIP SM523-G User Manual

SM523-G |
Cup Holder Mount with Flexible Goosneck Shaft with Slim-Grip™ Smartphones
SM050-2 Slim-Grip™
Universal Phone Holder
88mm expandable to 138mm
with Extra Long Support Legs
Cup Holder Mounting
Connect the gooseneck shaft (A) to the cup holder base (B) by
Step 1.
aligning the groove on the base to the ridge inside of the bottom
of the shaft.
(C) Thumb wheel
adjustment
knob
Step 2. Place the Universal Cup Holder Mount into the designated cup
holder in the vehicle. Adjust the thumb wheel adjuster (C) to open
or close the cup holder prongs to fit in the cup holder.
For oversize cup holder openings or the adjustable "pop out" cup
Step 3. holders use the optional self-adhesive side support pads (D). Install
the pads by removing the adhesive backing and placing it on the
flat surface side of the cup holder support leg.
(D) Optional
support
pads
Safety Precautions
!
Do not install Arkon products over an air bag cover or within the air
bag deployment zone. Arkon Resources, Inc. assumes no responsi-
bility of liability for injury or death as a result of car crashes and / or
air bag deployment.
Arkon is not responsible for any damages caused to your car, your
device, or yourself due to the installation or use of this pedestal mount.
GN033-SBH
SP-SM050-LF
Cup Holder Mount
Extra Long
Support Legs
(2 Pack)
(A) Cup Holder
Neck
(B) Cup Holder Base
Package Contents:
(1) GN033-SBH - 5" Cup holder mount with flexible gooseneck shaft
(1) SM050-2 Universal phone and portable device holder
(1) SP-SM050-LF - Extra Long Support Legs (2 Pack) for larger phones
Holder included is Universal, designed to fit nearly ALL non-flip mobile phones regardless of whether a
protective case or silicone sleeve is attached to the phone.
• Most smartphones, mobile phones, and cell phones
having heights between 80mm and 138mm tall
• Apple iPhone - All models
• RIM BlackBerry - All non-flip models
• HTC Phones - All non-flip models
• Motorola Phones - All non-flip models
• Nokia Mobile Phones - All non-flip models
No tools required for installation.
Note: mount may not work with adjustable, "pop out" cup holders or oversize
cup holder openings found in full-size pickup trucks.
Do not place mount in or near an air bag deployment zone or where it
!
will obstruct view of the road.
All brand names and product names are trademarks or registered trademarks of their respective owners.
Install the Support Legs to the Holder
Step 1. Insert the holder support legs (A) by sliding them into the
support leg grooves (B) on the top and bottom of the holder.
A
A
iPhone Holder Attachment
Step 1. Adjust the angle of the dual T head by tightening the adjustment
nut at the top of the cup holder shaft (A).
Step 2. Install the iPhone holder to the shaft by inserting the dual T-tabs
(B) on the shaft into the T-slots (C) on on the back of the holder.
(B) Cup Holder
(A) Angle
Adjustment
Nut
The Mobile Mounting Specialists™
Consumer Hotline:
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
• Palm - All non-flip models
• LG Mobile Phones - All non-flip models
• Samsung - All non-flip models
• Sony Ericsson - All non-flip models
• Sanyo - All non-flip models
• Pantech - All non-flip models
• Google - All non-flip models
B
A
A
B
Shaft T-tabs
(C) T-slots
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in Taiwan & China
