  • Page 1 Acer Aspire 1700 series User’s guide...
  • Page 2 Copyright © 2003 All Rights Reserved Acer Aspire 1700 Series Computer User's Guide Original Issue: March 2003 Changes may be made periodically to the information in this publication without obligation to notify any person of such revision or changes. Such changes will be incorporated in new editions of this manual or supplementary documents and publications.

  • Page 3: Table Of Contents

    First things first Your guides Basic care and tips for using your computer Getting familiar with your computer A tour of your computer Opened front view Closed Front view Left view Right view Rear view Bottom view Features Display Indicators Keyboard Special keys Keyboard ergonomics...
  • Page 4 Peripherals and options External display devices External keypad External pointing device Printer Expansion devices PC Card USB devices Miscellaneous options Installing New Components Opening The Case CPU upgrade Hard disk upgrade Memory upgrade Moving with your computer Disconnecting from the desktop Moving around Preparing the computer What to bring to short meetings...
  • Page 5 Troubleshooting Frequently asked questions Appendix A Specifications Appendix B Notices Index...

  • Page 7: First Things First

    You are advised to read it thoroughly and keep it handy for future reference. For more information on our products, services, and support, please visit our web site www.global.acer.com. Basic care and tips for using your computer Turning your computer on and off To turn on your computer, open the lid and press the power button above the keyboard.
  • Page 8 viii Note: if you are unable to shut down the computer in the usual way, press and hold the power switch for more than four seconds. You should then wait at least two seconds before turning the computer on again. Taking care of your computer Your computer will serve you well if you take care of it.
  • Page 9 Taking care of your battery pack(Optional) It is also important that you look after your computer's battery pack. Use the correct battery model for your computer. Do not use other • kinds of batteries. Turn the power off before removing or replacing the battery. •...

  • Page 11: Getting Familiar With Your Computer

    Getting familiar with your computer...
  • Page 12 Getting familiar with your computer Your Aspire 1700 series computer combines solid performance, versatility, multimedia capabilities and portability with a stylish design. Increase your productivity by working wherever you are. This chapter provides an in-depth "tour" of your computer's features.

  • Page 13: A Tour Of Your Computer

    A tour of your computer After setting up your new Aspire computer, as illustrated in the Just for starters… poster, take a few minutes to explore the unit. Opened front view Item Description Display Large liquid crystal display (LCD) provides visual output.
  • Page 14 Item Description Click buttons & Right and left buttons that provide the same functions scroll key as the buttons on a computer mouse. The scroll key scrolls the contents of a window up and down. Audio DJ controls Button and indicators for the Audio DJ function. For and indicator more information, see “Audio”...

  • Page 15: Closed Front View

    Closed Front view Item Description Speakers Left and right speakers deliver stereo audio output Wireless Lights when the Wireless LAN capability is enabled. communication indicator Power indicator Lights when the computer is on.

  • Page 16: Left View

    Left view Item Optical drive Optical disc read indicator Optical drive eject button Optical drive emergency eject hole Floppy drive Left Latch PC card eject button PC card slot Getting familiar with your computer Description Depending on your model, the optical drive is one of the following: CD-ROM drive for reading CDs.

  • Page 17: Right View

    Right view Item Right Latch Speaker/Headphone-out jack Line-in/Mic-in jack IEEE 1394 port IEEE 1394 port USB ports DC-in jack Description Locks and releases the lid.(One on the right and one on the left) Connects to audio line-out devices (e.g.,speakers, headphones). Accepts audio line-in devices (e.g., audio CD player, stereo walkman).

  • Page 18: Rear View

    Rear view Item USB ports Modem jack S-video External display port COM port Network jack Parallel port PS2 port Kensington lock slot Getting familiar with your computer Description 2 ports for connecting USB 2.0 devices. Connects the built-in fax/data modem to a phone line.

  • Page 19: Bottom View

    Bottom view Item Battery cover Sub-woofer Ventilation slots Description Protects the battery bay. Enhance the audio quality. Enables the computer to stay cool, even after prolonged use.

  • Page 20: Features

    Features Performance Intel Pentium 4 Northwood/Celeron processor. • L2 cache 512K (Northwood), 128K (Celeron). • SiS M650 with SiS 962, support 400/533Mhz Front Side Bus , Intel HTT • support 40 GB or higher-capacity Desktop 5400rpm, 7200rpm HDD. • Microsoft Windows XP operating system. •...
  • Page 21 Large & comfortable palm rest area with well-positioned touchpad. • Expansion PC card slot enables a range of add-on options. • Upgradeable CPU, hard disk and memory modules. •...

  • Page 22: Display

    15”. For 17”, it supports SXGA resolution with16 million colors at 1280 x 1024 . Video performance Your Aspire 1700 series computer features an accelerated graphics port (AGP) video system with SiS M650 embedded VGA engine and 32MB UMA RAM, and nVIDIA NV-18M series(64MB AGP card) as option. This provides a robust solution, while enabling high quality video output.

  • Page 23: Indicators

    Indicators Your computer provides an array of five indicators located above the keyboard, in addition to two indicators positioned at the top right hand corner of the LCD panel. These indicators show the status of the computer and its components. The five indicators located above the keyboard provide the following status information: Description...
  • Page 24 Description Caps Lock active. Num Lock active. (Note: the keypad lock must be turned on to use the embedded numeric keypad.) Scroll Lock active. The two indicators located at the front of the unit provide the following status information: Description Power mode: Steady green Steady orange...

  • Page 25: Keyboard

    Keyboard The keyboard features full-size keys with an embedded keypad, separate cursor control keys, two Windows keys, and twelve function keys (hot keys). Special keys Lock keys The computer features three lock keys, each with its own status indicator light. Lock Key Description Caps Lock...
  • Page 26 Windows keys The keyboard features two keys that provide Windows-specific functions. Description Windows key Pressed alone, this key has the same effect as clicking on the Windows Start button; it launches the Start menu. It can also be used with other keys to provide a variety of functions: + Tab activates the next Taskbar button.
  • Page 27 Hotkeys Using the Fn key with another key creates a hot key, providing a quick and convenient method for controlling various functions. To use a hot key, first hold down the Fn key. Next, press the second key in the combination.
  • Page 28 HotKey Fn + F8 Speaker on/off Fn + <right Brightness arrow> Fn + <Left Brightness arrow> down Fn + <up Volume up arrow> Fn + <down Volume arrow> down Fn + Pg Up Home Home Fn + Pg Dn Euro key Your computer supports the new Euro currency character.

  • Page 29: Keyboard Ergonomics

    Keyboard ergonomics The wide palm rest area provides a comfortable platform for your hands when typing on the keyboard. The ergonomic design enables you to adopt a relaxed, yet very efficient, typing style.

  • Page 30: Touchpad

    Touchpad The built-in touchpad is a PS/2- compatible pointing device that senses movement on its surface. The cursor responds to your finger movements on the touchpad. In addition, the two click buttons provide the same functionality as a computer mouse, while the scroll key enables easy up and down scrolling in documents and web pages.
  • Page 31 Use the scroll key (2) to scroll through long documents and web pages. • Press the top of the key to scroll up, and the bottom to scroll down. Function Left Button Execute Click twice quickly. Select Click once. Drag Click and hold.

  • Page 32: Launch Keys

    3 is used to launch the Internet browser. Keys 3 and 4 start the Launch Manager application. All five launch keys can be set by the user. To set the launch keys, run the Acer Launch Manager. Launch key...

  • Page 33: Storage

    Storage Your computer's all-in-one design offers a variety of data storage options: The high capacity Enhanced-IDE hard disk drive. • The hard drive is upgradeable, enabling you to increase your storage capacity in the future. Consult your dealer if you need to upgrade. The high speed optical drive.

  • Page 34: Emergency Ejection Of The Optical Drive Tray

    Place a CD or DVD on the open tray. Align the disc's center hole with the • tray's spindle. Gently push down on the disc until it clicks in place on the spindle. • Gently push in the tray until it clicks closed. •...

  • Page 35: Connectivity Options

    Connectivity options Your computer has built-in connectivity options, enabling you to hook up to a network or communicate over a phone line. Ethernet and LAN The integrated network feature allows you to connect your computer to an Ethernet-based (10/100Mbps) network. To use the network feature, plug an Ethernet cable into your computer's network jack, and then connect the other end to a network jack or hub on your network.

  • Page 36: Fax/Data Modem

    Fax/data modem Your computer features a software modem(V9.0/V9.2 56Kbps), enabling you to communicate over a phone line. This means that you can connect to the Internet via a dialup account with an ISP, log in to your network from a remote location, or send faxes.

  • Page 37: Audio

    Audio Your computer includes an integrated stereo audio system. Built-in stereo speakers and a subwoofer are located at the front of the unit. Volume is adjusted using software, such as Volume Control in Windows, or any other application that provides a volume adjustment control. Two audio ports on the right side of the computer enable external devices to be connected.

  • Page 38: Audio Dj

    Audio DJ Audio DJ offers all the convenience of an audio CD / MP3 player, enabling you to play your favorite music CDs or “My MP3” folder from the HDD even when your computer is in power-off mode. Operate Audio DJ as follows: •...
  • Page 39 Audio DJ features the following control buttons Description Volume Down Volume Up Previous Track Next Track Stop/Eject Play/Pause Shuffe On/Shuffle Off...

  • Page 40: Securing Your Computer

    Securing your computer Your computer features hardware and software security solutions, in the form of a slot for a Kensington lock and a password facility. Security slot A slot for a Kensington slot enables you to physically protect your computer from theft.
  • Page 41 On the Advanced tab, select the option to prompt for a password when • your computer resumes from standby. To cancel password protection, reset the password with a blank password.
  • Page 42 Getting familiar with your computer...
  • Page 43 Operating on battery...
  • Page 44 Your Aspire 1700 series computer operates on battery or AC power. This chapter provides information for operating on battery power, as well as information on how your computer manages and saves power.
  • Page 45 power...

  • Page 46: Operating On Battery Power

    Battery pack(Optional) Your computer uses a re-chargeable 12-cell LI-ION 2.2Ah battery pack. Battery pack characteristics The battery pack has the following characteristics: Employs current battery technology standards. • Delivers a battery-low warning. • To prolong the life of your Ni-Mh battery pack, fully deplete the battery before recharging.

  • Page 47: Installing And Removing The Battery Pack

    Fully deplete the battery until the battery-low warning appears. Reconnect the AC adapter and fully charge the battery again. Follow these steps again until the battery has been charged and discharged three times. Use this conditioning process for all new batteries, or if a battery hasn't been used for a long time.
  • Page 48 To install a battery pack: * Please refer to “Opening The Case” on page 49 berfore you proceed to next step. Loosen the screws on the battery cover and remow it from the battery bay. Align the battery to the battery bay and tighten the screws. To remove a battery pack: Refer to “Opening The Case”...

  • Page 49: Charging The Battery

    Charging the battery To charge the battery, first make sure that it is correctly installed in the battery bay. Plug the AC adapter into the computer, and connect to a mains power outlet. You can continue to operate your computer on AC power while your battery is charging.

  • Page 50: Battery-Low Warning

    Battery-low warning When using battery power pay attention to the Windows Power Meter. Warning: connect the AC adapter as soon as possible after the battery-low warning appears. Data will be lost if the battery to become fully depleted and the computer shuts down. When the battery-low warning appears, the recommended course of action depends on your situation: Situation...

  • Page 51: Power Management

    Power management Your computer features a built-in power management unit that constantly monitors system activity. System activity refers to any activity involving one or more of the following devices: keyboard, touchpad/mouse, floppy disk drive, hard disk drive, optical drive, peripherals connected to the computer. If no activity is detected for a period of time (the settings are controlled in Windows Power Management), the computer turns off some, or all, of these devices in order to conserve power.

  • Page 52: Peripherals And Options

    Peripherals and options...
  • Page 53 Your Aspire 1700 series an expandable desktop replacement. This chapter provides information on connecting peripherals to expand your system and upgrading key components to enhance system performance and keep your computer in step with the latest technology. You are advised to consult your dealer for information on peripherals.

  • Page 54: External Display Devices

    External display devices You can connect an external (VGA) monitor or projector to your computer's external display port. See the section entitled "Display" for information on using the computer's simultaneous display and multi- display features. Use the Fn + F5 hot key to toggle the display setting between the computer's LCD panel and the external display device.

  • Page 55: External Keypad

    Peripherals and options External keyboard Your computer features a full-size keyboard. However, if you prefer, you can connect an external keyboard to one of your computer's USB ports. This enables you to enjoy the comfort and added features of a full-size desktop system keyboard when inputting typed data on your computer.

  • Page 56: Printer

    Printer Your computer supports both parallel and USB printers. Refer to the printer's manual for information on: Setting up the hardware. • Installing the necessary drivers in Windows. • Operating instructions. • To use a USB printer, simply connect the device to one of your computer's USB ports, and then wait for Windows to find the new hardware.

  • Page 57: Expansion Devices

    Expansion devices PC Card Your computer features a PC card slot that supports a standard Type II PC card (PCMCIA or CardBus). This greatly increases your computer's usability and expandability. A variety of PC cards are available, such as flash memory, fax/data modem, LAN, and SCSI cards. Consult your dealer for information on PC card options for your computer.

  • Page 58: Usb Devices

    To remove a PC card: Close any applications using the PC card. Double click on the PC card icon on the taskbar, and then select the option to safely remove the card. Wait for the message telling you that it is now safe to remove the card. Press the PC card eject button to partially eject the card from the slot.

  • Page 59: Miscellaneous Options

    Peripherals and options Miscellaneous options Battery pack It is a good idea to have a battery, especially when you travel with your computer. This greatly increases your productive range when you are on the move. AC adapter Having a spare AC adapter allows you to keep one in two different places.

  • Page 60: Installing New Components

    Installing New Components Make sure you only use components that are compatible with your Aspire computer. Consult your dealer regarding compatibility of new components before you purchase them. To ensure proper installation, refer to the documentation provided with new components before you start to add or replace components. Possible upgrade options include the following: Replace the HDD with a higher capacity model.

  • Page 61: Cpu Upgrade

    CPU upgrade Caution! A microprocessor and heat sink may be hot if the system has been running. Also, there may be sharp pins and edges on some board and chassis parts. Contact should be made with care. Consider wearing protective gloves. After removing the bottom panel: a) Loosen the four screws in the air baffle/heat sink assembly.
  • Page 62 To install a new processor Raise the locking bar on the socket. Align the processor with the socket. Orient the processor so that the triangle on the corner of the processor aligns with the triangle on the corner of the socket. Insert the processor into the socket.

  • Page 63: Hard Disk Upgrade

    Peripherals and options Hard disk upgrade It is possible to replace your hard disk with a higher capacity drive when you need more storage space. Your computer uses a 3.5 inch Enhanced-IDE hard disk. Consult your dealer if you need to perform a hard disk upgrade.

  • Page 64: Memory Upgrade

    Memory upgrade Your computer features two memory slots that accept 184-pin industry-standard DIMMs (Dual Inline Memory Modules). The memory slots support PC-2100 and PC-2700 DDR SDRAM (Synchronous Dynamic Random Access Memory). The memory slots are easily accessible, allowing you to upgrade your computer's memory.
  • Page 65 Peripherals and options...

  • Page 66: Moving With Your Computer

    Moving with your computer...
  • Page 67 Your Aspire 1700 series computer is ideal for taking with you when you move around. This chapter provides tips on things to consider when traveling with your computer.

  • Page 68: Disconnecting From The Desktop

    Disconnecting from the desktop Before moving with your computer, you must turn it off and disconnect all peripherals: Save your work and close all applications. Shut down Windows to turn off your computer. Unplug the AC adapter from the mains outlet, and then disconnect it from the computer.

  • Page 69: Moving Around

    Moving with your computer Moving around Sometimes you might need to move your computer a short distance. For example, you might need to move from your office desk to a meeting room. In these situations, you don't have to shut down the operating system.

  • Page 70: Taking The Computer Home

    Taking the computer home When you move between your office and home you will need to prepare your computer for the short trip. Preparing the computer After disconnecting your computer from the desktop (see "Disconnecting from the desktop"), prepare the unit as follows: Remove all media from the drives.

  • Page 71: Setting Up A Home Office

    Moving with your computer Setting up a home office If you frequently work on your computer at home, as well as at work, it may be worthwhile purchasing a second AC adapter. This will allow you to travel lighter, as you can keep an AC adapter in each location. You might also find it worthwhile keeping a second set of peripherals at home, such as a keyboard, keypad, mouse and printer.

  • Page 72: Traveling With The Computer

    Traveling with the computer Sometimes you might need to make longer trips with your computer. Preparing the computer Prepare the computer as you would for moving between your office and home. It is advisable to make sure that the battery is fully charged. If you are traveling by air, you might be required to turn on the computer during security checks.

  • Page 73: Traveling Internationally With Your Computer

    Traveling internationally with your computer Occasionally you might need to travel between countries with your computer. Preparing the computer Prepare the computer as you would for normal travel. Remember to take special precautions for air travel (see "Traveling with your computer").

  • Page 74: Software

    Software...
  • Page 75 Your Aspire 1700 series computer includes system utilities. This chapter provides information on the important software that comes with your computer.

  • Page 76: System Software

    System software Your computer comes preloaded with the following software: Microsoft Windows operating system. • Hardware BIOS setup utility. • System utilities, drivers and application software. • Note: to run software applications in Windows, first click on the Start button. Next, select the appropriate folder, and then click on the application icon.

  • Page 77: Bios Setup Utility

    Software BIOS Setup Utility The BIOS Utility is a hardware configuration program built into your computer’s BIOS (basic input/output system). Your computer is already properly configured and optimized, and you do not need to run this utility. However, if you encounter configuration problem, you may need to run it.

  • Page 78: Troubleshooting

    Troubleshooting...
  • Page 79 This chapter instructs you on how to deal with common system problems. Please read it before calling a technician. Solutions to more serious problems may require opening the computer. Do not attempt to open and service the computer by yourself. Contact your dealer or an authorized service center for assistance.

  • Page 80: Frequently Asked Questions

    Frequently asked questions This section suggests solutions to commonly encountered problems. I press the power switch, but my computer does not start or boot-up. Look at the Power status indicator: If it is not lit, no power is being delivered to the computer. Check •...
  • Page 81 The image is not full-screen. Make sure that the resolution is set to a resolution your system supports: Right click on your Windows desktop and select Properties to bring • up the Display Properties dialog box. Alternatively, click on the Display icon in Control Panel.
  • Page 82 The keyboard does not respond. Try attaching an external USB keyboard to one of your computer's USB ports. If it works, the internal keyboard might have become disconnected. Contact your dealer or an authorized service center. The floppy disk drive cannot read a diskette. Check the following: Make sure that the diskette is properly inserted in the floppy disk •...
  • Page 83 I want to set up my location to use the internal modem. Follow these steps: Click on Start, and then click on Control Panel. • Double-click on Phone and Modem Options. • In the Dialing Rules tab, begin setting up your location. •...

  • Page 84: Appendix A Specifications

    Appendix A Specifications...
  • Page 85 This appendix lists the general specifications of your computer.
  • Page 86 Microprocessor Intel® Pentium® 4 2.4 G~3.06G or higher processor. • Intel® Celeron® 1.7G~2.0G or higher processor. • Memory Desktop 128 , 256, 512 MB, 1G Double Data Rate Synchronous • Dynamic Random Access Memory (DDR-SDRAM). Two user-upgradeable 184-pin industry-standard DIMM slots (DDR- •...
  • Page 87 I/O ports One type II PC Card slot (PCMCIA and CardBus). • One RJ-11 modem jack (V.90, 56K). • One RJ-45 network jack (Ethernet 10/100). • One DC-in jack. • One parallel port (ECP/EPP). • One external monitor port. • Two IEEE 1394 port.
  • Page 88 Operating system Microsoft Windows XP. • Power 12-cell Li-ion smart battery pack. • 150-Watt AC adapter, auto sensing 100~240Vac, 50~60Hz. • Options 256MB/512 MB/1GB DDR-SDRAM memory upgrade module. • Additional AC adapter. • Additional battery pack. •...
  • Page 89 Appendix A Specifications...

  • Page 90: Appendix B Notices

    Appendix B Notices...
  • Page 91 This appendix lists the general notices for your computer.

  • Page 92: Fcc Notice

    FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 93: Modem Notices

    Appendix B Notices Notice: Canadian users This Class B digital apparatus meets all requirements of the Canadian Interference- Causing Equipment Regulations. Remarque à l’intention des utilisateurs canadiens Cet appareil numérique de la classe B respected toutes les exigences du Règlement sur le materiel brouilleur du Canada.

  • Page 94: Important Safety Instructions

    Telecommunications notices A-Tick notice For safety reasons, only connect headsets with a telecommunications compliance label. This includes customer equipment previously labelled permitted or certified. Important safety instructions Read these instructions carefully. Save them for future reference. Follow all warnings and instructions marked on the product. Unplug this product from the wall outlet before cleaning.

  • Page 95: Laser Compliance Statement

    Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions: When the power cord or plug is damaged or frayed. If liquid has been spilled into the product. If the product has been exposed to rain or water. If the product does not operate normally when the operating instructions are followed.

  • Page 96: Lcd Pixel Statement

    PRODUCTO LÁSER DE LA CLASE I ADVERTENCIA: RADIACIÓN LÁSER INVISIBLE AL SER ABIERTO. EVITE EXPONERSE A LOS RAYOS. ADVARSEL: LASERSTRÅLING VEDÅBNING SE IKKE IND I STRÅLEN. VARO! LAVATTAESSA OLET ALTTINA LASERSÅTEILYLLE. VARNING: LASERSTRÅLNING NÅR DENNA DEL ÅR ÖPPNAD ÅLÅ TUIJOTA SÅTEESEENSTIRRA EJ IN I STRÅLEN VARNING: LASERSTRÅLNING NAR DENNA DEL ÅR ÖPPNADSTIRRA EJ IN I STRÅLEN ADVARSEL: LASERSTRÅLING NAR DEKSEL ÅPNESSTIRR IKKE INN I STRÅLEN...
  • Page 97 Appendix B Notices • This device complies with RSS 210 of Industry Canada. Europe - EU Declaration of Conformity This device complies with the standards listed below, following the provisions of the EMC Directive 89/336/EEC: • ETSI EN 301 489-1/17 •...
  • Page 98 residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
  • Page 99 Appendix B Notices...

  • Page 100: Index

    Index ACPI audio connecting externally controlling volume troubleshooting battery bay battery pack battery-low warning caring for characteristics charging checking charge level installing low conditions maximizing life optimizing removing using the first time BIOS Setup Utility 66–?? entering brightness hotkeys caps lock on indicator care battery pack...
  • Page 101 hotkeys lock keys troubleshooting Windows keys keypad connecting externally launch keys left view memory installing upgrading microphone troubleshooting modem setting location mouse connecting externally mute hotkeys notice DVD copyright protection num lock on indicator optical drive options hard disk upgrade memory upgrade PC Cards spare AC adapter...
  • Page 102 connecting utility BIOS Setup 66–?? volume adjusting Windows keys...
