Vertix Raptor-i User Manual page 5

Turning On
Press and hold the ON-OFF / INT button. Release the button when you see the BLUE light starting to ash (after
approximately 4 seconds). The speaker will sound an audio warning (long high pitch beep followed by one or
two short high pitched beeps – 2 short beeps means it is connected to a paired device).
Turning O
Press and hold the ON-OFF / INT button. Do not release until you hear an audio warning (2 short low pitched
beeps followed by 1 long higher pitch beep) and both RED and BLUE lights are turned OFF.
BLUETOOTH® Pairing
The Raptor-i is compatible with Bluetooth® technology used for pairing mobile phones, music players and
between Raptor-i headsets.
Pairing Mode
Make sure your Raptor-i is OFF.
Press and do not release the ON-OFF / INT button until you see both Blue and Red lights ashing alternately.
You should hear a long high pitch tone followed by 2 low pitched tones. Your Raptor-i is now in Pairing Mode.
Note that the unit will automatically exit the Pairing Mode in about 60 seconds if pairing is not completed or
unsuccessful. Repeat again if this happens.
Mobile Phone Pairing
With the Raptor-i in Pairing Mode, turn ON your mobile phone's Bluetooth® and search for devices. Please
refer to your mobile phone's user manual if necessary.
Your mobile phone should detect "VTX RAPTOR-i".
Select this and enter the code 0000 (zero zero zero zero).
7
Note : To use the Raptor-i with a mobile phone and GPS Sat-Nav device at the same time, you will need to utilize
the GPS Sat-Nav unit's phone function. Please refer to your GPS Sat-Nav user manual for more infomation.
Intercom Pairing
Switch OFF all Raptors-i near you if possible.
Bring the 2 sets you would like to begin pairing close to each other.
Put them into Pairing Mode. You will see Red and Blue ashing lights on BOTH sets.
Press the ON-OFF / INT button brie y on ONE of the Raptor-i to initiate pairing.
When both Raptor-i show only a Blue ashing light, the pairing is completed and INTERCOM is established
between the 2 sets. Test by talking to con rm.
Repeat the process to pair using one of the units you just paired with another Raptor.
NOTE: Each Raptor-i unit can only pair with 2 other Raptor-i units. The last 2 sets to pair will have a higher priority
and a single INT button press on either of these 2 units will connect them together. The 3rd or last set to pair will
require 2 INT presses to communicate with either of the 2 earlier sets.
Music Player Pairing
Refer to Mobile Phone Pairing
GPS Sat-Nav Pairing
Models such as the Garmin® Zumo 500 and 600 series supports pairing with your mobile phone and o ers an
easy and convenient way for you to enjoy both mobile phone and GPS Sat-Nav functions on your Raptor. Please
see your GPS Sat-Nav user manual on setting up and if the phone function is supported.
For GPS Sat-Nav devices without the integrated mobile phone feature, you will have to decide which one takes
higher priority as Raptor-i can only support ONE High Priority device, you may wish to note that most older or
entry level GPS Sat-Nav devices does not support phone pairing.
8
