Page 1: Table Of Contents
VACUUM CLEANER ELECTRONIC VC-H110 SERIES VC-H113 / VAH-1113 VC-H114 / VAH-1114 VC-H130 VACUUM CLEANER CONTENTS 1. Precautions 2. Specifications 3. Operating Instructions 4. Schematic Diagrams 5. PCB Diagrams 6. Troubleshooting 7. Exploded Views and Parts List... -
Page 2: Precautions
7. Grasp the plug firmly when removing it. To avoid damage to cord, plug, prongs or socket, always disconnect the cord from the electrical outlet before replacing the dust bag or servicing the cleaner. 8. The use of an extension cord is not recommended. 9. Repairs should be done only by qualified service personnel. SAMSUNG ELECTRONICS.,LTD... -
Page 3: Specifications
2. Specifications VC-H113 VC-H114 MODEL NAME VC-H130 VAH-1113 VAH-1114 Basic spec. CAR Only Charging Charging Suction Power (W) Max. Vacuum (mmH BODY Voltage DC 12V DC 4.8V DC 7.2V Spec. Power Consumption Input – 1.34VA 1.56VA ADAPTER Output – DC 6.7V DC 7.8V... -
Page 4: Operating Instructions
3. Operating Instructions DUST-COVER DUST-COVER RELEASE BUTTON DUST-FILTER ON/OFF SLIDE SWITCH HANDLE FILTER-COVER ACCESSORIES CHARGER CREVICE TOOL DUST FILTER ELECTRIC POWER CORD FOR CAR (VC-H130 ONLY) SAMSUNG ELECTRONICS.,LTD... -
Page 5: Troubleshooting
• Check the off position of the main switch when charging • Suction power is weak • Check that the inlet is clogged with a • Remove the object large object • Check that the dust-filter is filled with • Attach the filter-cover dust properly SAMSUNG ELECTRONICS.,LTD... -
Page 6: Exploded Views And Parts List
7. Exploded Views and Parts List 7-1 Assembly Body SAMSUNG ELECTRONICS.,LTD... - Page 7 SHEET PE FORM CONNECTOR-TERMINAL DJ72-70137A GRILLE-MOTOR ABS,GRY,HG0760 DJ96-00002A BATTERY ASSY 7.2V/1600mAh*6 DJ91-10116A BATTERY ASSY 4.8V/1600mAh*4 ASSY MOTOR VC-H114,7.2V, ASSY MOTOR VC-H113,4.8V, 12-1 DJ97-00004B ASSY MOTOR SUB ASSY,7.2V DJ97-00004C ASSY MOTOR SUB ASSY,4.8V 12-1-1 DJ31-10114C MOTOR-DC 7.2V DJ31-00008A MOTOR-DC 4.8V 12-1-2...
- Page 8 7-2 Assembly Adapter SAMSUNG ELECTRONICS.,LTD...
- Page 9 Parts No Description Specification Q’ty H113 H114 H1114 SVC PARTS DJ91-10114D ASSY ADAPTER ASSY EURO YELLOW VC-H113 DEMKO DJ91-10114E ASSY ADAPTER ASSY RED VC-H113 DEMKO DJ91-10114F ASSY ADAPTER ASSY BLUE VC-H113 DEMKO DJ91-10114G ASSY ADAPTER ASSY PEPPERMINT VC-H113 DEMKO DJ91-10114H...
- Page 10 5. PCB Diagrams A. Basic B. Minor Change PBA-MAIN (A-TYPE) VC-H113 (DJ41-20194C) VC-H114 (DJ41-20194B) LOC.NO SPEC PARTS NO R-CARBON : 1Kohm, 5%, 1/4W, AA, TP 2001-000042 COMMON – R-CARBON : 270ohm, 5%, 1/4W, AA, TP 2001-0000 – COMMON R2, R3...
- Page 11 4. Schematic Diagrams A. Basic *Car only Model except dotted Box B. Minor Change *Car only Model except dotted Box SAMSUNG ELECTRONICS.,LTD...
