10
C
1: U
HAPTER
NPACKING
I
NSTRUCTIONS
9 Save the foam supports and plastic bag in case you need to pack up and
move the chassis to a different site, or in case you need to return the
chassis to your network supplier or to 3Com.
10 Inspect the chassis and verify that it contains:
One power supply (rear, bottom left or right)
Two fan trays (rear, top left and right)
One Switch Fabric Management Module in slot M1 or M2 (front)
(Starter kits only) The correct type and number of interface modules:
Model Number 3C16830 holds five 8-port 10/100BASE-TX
Interface Modules (3C16828) in slots 1 through 5.
Model Number 3C16831 holds two 8-port 10/100BASE-TX
Interface Modules (3C16828) in slots 1 and 2, and two 8-port
100BASE-FX MT-RJ Interface Modules (3C16829) in slots 3 and 4.
Model Number 3C16832 holds five 2-port 1000BASE-T Interface
Modules (3C16841) in slots 1 through 5.
Model Number 3C16833 holds five 2-port 1000BASE-SX Interface
Modules (3C16842) in slots 1 through 5.
If your starter kit is not described here, consult your sales paperwork for
the interface modules that should be preinstalled.
All unoccupied module slots and the second power bay should be
covered with blank faceplates.
If the shipping box does not contain the correct components (including
the accessories listed in step 6), follow the instructions in step 1.
11 If you are not prepared to install the chassis, replace it in the shipping box
with the plastic bag and foam supports in their original positions to
prevent damage to the chassis.
12 Read the Switch 4005 Installation and Maintenance Guide to verify that
you have met prerequisite installation conditions, to acknowledge
important safety information, and to follow the installation procedures.
A printed copy of this guide is included in all chassis shipping boxes.
Alternatively, you can download a copy of this guide from the 3Com Web
site. Click the "Find Documentation" link on this page:
http://support.3com.com/index.htm
