Summary of Contents for Mr Handsfree blue perfection
-
Page 2: Declaration Of Conformity
We, the undersigned, Company: TE-GROUP nv Address: Kapelsestraat 61, 2950 Kapellen - BELGIUM declare, that the following equipment : Product Name: mr Handsfree BLUE PERFECTION Product Type: Bluetooth ® Carkit Conforms with the requirements of European Council Directive 89/336/EEC amended with 92/31/EEC... -
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ..................2 WHAT DOES MR HANDSFREE BLUE PERFECTION INCLUDE? ......2 DESCRIPTION ....................3 INSTALLATION ....................6 OPERATION ....................... 10 TROUBLE-SHOOTING ..................23 TECHNICAL PARAMETERS ................24 BLUETOOTH ® ....................25 CARE AND TECHNICAL MAINTENANCE ............. 25... -
Page 5: Safety Instructions
Do not operate your carkit off the car battery for a long time, i.e. with the engine switched off, as this may cause your battery to be empty. WHAT DOES MR HANDSFREE BLUE PERFECTION INCLUDE? Handsfree unit with built-in speaker (SM1) -
Page 6: Description
The handsfree unit has the following jacks for connecting external units: Socket for system cable SC1. Socket for cables SC2 and SC3. Socket for external speaker (Use this only with mr Handsfree original accessories). Microphone socket M1. GB - 3... - Page 7 SCREEN (D1) The screen unit includes: 1. LCD with big symbols and icons. 2. Convenient adjustable fixation system which allows you to choose the best viewing position of the LCD and to release the unit easily from the dashboard to avoid theft. 3.
- Page 8 If press Up, Down, Left or Right button: Navigation in the Menu. If press and hold Up, Down, Left or Right button: Quick scrolling of lists. If press: If press Central button: Ending a call. Opening the Menu. Returning to the previous level OK button.
-
Page 9: Installation
SYSTEM CABLES SC2 AND SC3 The system cable SC2 connects the handsfree unit with the power supply and the ignition system and is used for muting the radio. The system cable SC3 is used for plug & play installation. It provides power supply via the cigarette lighter. - Page 10 REMOTE CONTROL (J1) 1. Install the lithium battery (1) in the unit in correct polarity (text towards the battery compartment cover) and close the battery compartment. 2. Fix the unit on the bracket by a screw. 3. Click in the decorative inlay (2) and the joystick button (3). 4.
- Page 11 The fixation needs to be done as it is shown in the picture below. SCREEN UNIT (D1) Mount the bracket of the screen unit (SC1) on the dashboard or any other place where it is clearly visible, but do not impair control or operation of the vehicle.
- Page 12 Ensure that the cable is placed so that it will not be damaged (e.g. not laid under car seats or over sharp edges). CONNECTING TO THE POWER There are 2 ways of connecting the Blue Perfection to the car’s electronic system: Plug & play connection: via the adapter for the cigarette lighter (SC3).
-
Page 13: Operation
OPERATION SWITCHING ON/OFF If mr Handsfree Blue Perfection is connected to the power via the adapter with cable SC3, you can switch on the unit by clicking the adapter into the cigarette lighter. If mr Handsfree Blue Perfection is connected to the power with cable SC2, the unit will switch on automatically when you turn the ignition key. - Page 14 GB - 11 ....................................
- Page 15 5 sec. B. CONNECTION In some cases the device could be disconnected from your phone. For example, if the Blue Perfection was switched off. To restore the connection between the Blue Perfection and your phone: •...
- Page 16 Disconnect the Blue Perfection and the phone through the phone’s menu. Note: If the Blue Perfection and your phone were disconnected and you want to connect them again, it is not necessary to pair these devices again. Restoring the connection will be performed without asking for the access code.
- Page 17 , you can also use the built-in SIM card reader to download your phonebook data in the Blue Perfection memory. To copy the phonebook using the SIM card reader, please disconnect the screen from the bracket SC1, insert the SIM card into the SIM card holder according to the picture, and connect the screen to the bracket.
- Page 18 Use this item to delete all the phonebook records. 2.3 Volume of conversation and call ring This item is used for setting the desired volume of the speaker of the Blue perfection in Talk mode and the volume of the incoming call ringer.
- Page 19 • Use the Up and Down buttons of the joystick to choose the desired brightness. • Press to confirm or to restore the previous setting of the brightness. The custom setting of brightness has 16 levels. Level 0 switches the backlight off, level 15 is the maximum. 2.4.2 Contrast Choose this menu item for setting the contrast of the display.
- Page 20 Timer steps are 10 sec, the maximum is 1 min. • Press to confirm or to restore the previous setting and exit the menu. 2.5.3 Set Default With this item you can restore the factory settings of the Blue Perfection. Parameter Value Brightness 15/15 (max)
- Page 21 You can use the phonebook for dialing out. The records of the phonebook are displayed in alphabetical order in the top part of the display. The Blue Perfection phonebook can store up to 200 records. For a quick search of the desired name, find its first letter with the cursor in the bottom part of the display using the navigation buttons of the joystick.
- Page 22 After the beep, say the tag. • The Blue Perfection will record the corresponding tag from its memory and dial the number. 3. DIALING FROM THE PHONEBOOK You can dial a number from the phonebook stored in the Blue Perfection memory.
- Page 23 • Use the Left and Right buttons to move in the bottom part of the display and to select the first letter of the name. • Use the Up and Down buttons to scroll through the phonebook list. • Press to view detailed information of the record (name and phone number).
- Page 24 5. REDIAL Redial is done from the call lists. By selecting the outgoing call list, you can redial the last 10 numbers that have been dialed with the Blue Perfection after switch on. • In Stand-by mode, press and then •...
- Page 25 8. ANSWERING A CALL If there is an incoming call, the number of the caller will appear on the display. If the name and number are stored in the Phonebook of the Blue Perfection the name will appear on the display as well.
-
Page 26: Trouble-Shooting
• Press to see the telephone number/name of the SMS sender and the message receiving date and time. • Press to dial this telephone number. • Press to exit the SMS viewing mode. TROUBLE-SHOOTING Problem Reason Elimination The device does not work. The cigarette lighter jack Check if the cigarette lighter The green LED of... -
Page 27: Technical Parameters
TECHNICAL PARAMETERS Car battery voltage 12.6 V (10.8 – 13.5) with negative pole of GND. Consumption current In Talk mode – 0.8 A In Stand-by mode – 50 m A Fuse 1.5 A SYSTEM CABLE SC2 • Red: +12B • Black: GND •... -
Page 28: Bluetooth
CARE AND TECHNICAL MAINTENANCE The Blue Perfection is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you to fulfill any warranty obligations and to enjoy this product for many years. - Page 29 FCC Statements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference; and (2) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
