• To change the oil, remove the blade, lower
the saw to hor izontal position and then
place the tray by the drain outlet (L)
[SEE FIG. 4].
Store in a safe place, out of
reach of children
Maintain tools carefully

AIR FILTER

• Read engine owners manual for
maintenance intervals. For extremely
dusty conditions you may have to clean
the air filter element 2 to 3 times a day.
• Replace any damaged filters or gaskets.
CAUTION!
The filter must not be cleaned with
compressed air, this will damage
the filter. Filters can be vacuumed
out for cleaning but avoid hitting
or dragging items across the
surface as this will damage the
filter.
Paper filters are to be disposed of
correctly and replaced.
A polyester filter can be cleaned
via vacuuming or low pressure
washing.
Do not use high pressure washing,
this will damage the filter.
A damaged filter must always be
replaced.
A washed filter must be 100% dry
before being placed back onto the
equipment.
Store in a safe place out ot reach
of children.
Remove all adjustment tools and
wrenches
Store diamond tool in a safe place
so it cannot be bent or damaged.
10 Engine belt tension
It may be necessary after using a few times
to retension the belts, without over-
tightening them. To do this :
loosen the 2 nuts (S) fixing the engine to
•
the chassis, without removing them
[ 5];
SEE FIG.
tighten the tensioning nuts (N), these
•
screws pull the engine up.
at normal tension, tighten the engine
•
fixing nuts (S).
11 Important advice
• Periodically, tighten the nuts and bolts
and particularly after the first few hours of
use.
• Check belt tensions, tighten them without
overdoing it.
• When garaged, it is recommended the
blade be removed and suitably stored.
• Make sure the blade is correctly tightened.
• Make sure the blade supports surfaces, the
adaptor plates and the spindle are kept
clean.
The manufacturer declines all
responsibility for loss or damage
resulting from misuse or any
modification, alteration or
powering that does not conform
to the manufacturer's original
specifications.
At the work station, the sound
pressure level may exceed
85xdbx(A)
In this case individual protection
measures must be taken.
When working in a limited or
closed area, make sure that the
ventilation is adequate. The
exhaust gases contain carbon
monoxide (exposure to this toxic
gas can cause loss of
consciousness and can be fatal).
12 Repairs
Contact a Husqvarna construction
Products service center for equipment
repaire. For engine repaires, contact
engine supplier service.
13 Spare parts
For quick supply of spare parts and to
avoid any lost time it is essential to quote
the data on the manufacturer's plate fixed
to the machine and the part number of the
part to be replaced with every order.
00000000 (0)
Item number
See exploded view
Only use original Husqvarna parts.
See IPL for parts.
14 Scrapping
In the event of deterioration and
scrapping of the machine, the
following items
disposed of in accordance with
the requirements
legislation in force.
• Main materials :
Engine: Aluminium (AL), Steel (AC),
•
Motor : Copper (CU), Polyamide (PA)
Machine : Steel sheet (AC),
•
Machine : Cast iron (FT)
Machine : Aluminium (AL)
The instructions for use and spare parts
found in this document are for information
only and are not binding.
As part of our product quality improvement
policy, we reserve the right to make any
and all technical modifications without prior
notice.
Quantity
must be
of the
