remove bolts
I22-039.01
unplug connectors
bolts not visible
on this side
6
With the headlight/windshield assembly moved forward, unplug the two connectors on
the gauge harness. This will allow you to completely remove the headlight/windshield
assembly.
7
Remove the headlight/windshield assembly.
8
Remove the four bolts securing the upper frame brace. Only two bolts are visible in
Figure E.
9
Using needle nose pliers, release the five holding tabs locking the wiring harness cable ties
to the upper frame brace.
10 Remove the upper frame brace.
2010-2011 Yamaha Vector - PCV - 4
