Nibe F1226 User Manual
Ground source heat pump
Hide thumbs
Also See for F1226:
- User manual (68 pages) ,
- Installer manual (68 pages) ,
- Service instructions manual (36 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nibe F1226
Summary of Contents for Nibe F1226
- Page 1 User manual NIBE F1226 Ground source heat pump UHB EN 1726-2 231651...
- Page 2 Quick guide Navigation Ok button (confirm/select) Back button (back/undo/exit) Control knob (move/increase/reduce) A detailed explanation of the button functions can be found on page How to scroll through menus and make different settings is described on page 14. Set the indoor climate temperature1.1.1 INDOOR CLIMATE HOT WATER...
-
Page 3: Table Of Contents
2 The heat pump – the heart of the house Heat pump function Contact with F1226 Maintenance of F1226 3 F1226 – at your service Set the indoor climate Set the hot water capacity Get information Adjust the heat pump... -
Page 4: Important Information
1.9.1.1 heating curve (curve slope) Serial number must always be given Certification that the installation is carried out according to instructions in the accompanying installer manual and applicable regulations. Date __________________ Signed _________________________ Chapter 1 | Important information NIBE F1226... -
Page 5: Safety Information
Do not start the heat pump, if there is a risk that the water in the system has frozen. NOTE If the supply cable is damaged, only NIBE, its service representative or similar authorised person may re- place it to prevent any danger and damage. -
Page 6: Serial Number
The serial number can be found at the bottom right of the front cover and in the info menu (menu 3.1). Serial number Caution You need the product's (14 digit) serial number for servicing and support. Chapter 1 | Important information NIBE F1226... -
Page 7: F1226 - An Excellent Choice
F1226 – An excellent choice F1226 is part of a new generation of heat pumps, which have been intro- duced to supply your home with inexpensive and environmentally friendly heating. Heat production is safe and economical with integrated hot water heater, immersion heater, circulation pump and control system. -
Page 8: The Heat Pump - The Heart Of The House
-3 °C 0 °C -3 °C 0 °C Värmekälla Värmekälla Heat source The temperatures are only examples and may vary between different installations and time of year. Chapter 2 | The heat pump – the heart of the house NIBE F1226... -
Page 9: Heat Pump Function
The heating medium circulates in a closed system and transports the heated water's heat energy to the house water heater and radiators/heating coils. Chapter 2 | The heat pump – the heart of the house NIBE F1226... -
Page 10: Contact With F1226
F1226 USB port There is a display unit on the front of the heat pump, which is used to communicate with F1226.. Here you: switch on, switch off or set the heat pump in emergency mode. ■ sets the indoor climate and hot water as well as adjusts the heat pump ■... - Page 11 In this mode, the compressor switches off and the im- mersion heater engages. The heat pump display is not illuminated and the status lamp illuminates yellow. Chapter 2 | The heat pump – the heart of the house NIBE F1226...
- Page 12 The USB port is used to update the software. Visit www.nibeuplink.com and click the "Software" tab to download the latest software for your installation. Chapter 2 | The heat pump – the heart of the house NIBE F1226...
-
Page 13: Menu System
Display of temperature and other operating information and access to the alarm log. See page 34. HEAT PUMP Menu 4 Setting time, date, language, display, operating mode etc. See page 37. Chapter 2 | The heat pump – the heart of the house NIBE F1226... -
Page 14: Selecting Menu
OK button. A new window then opens with sub menus. Select one of the sub menus by marking it and then pressing the OK button. Chapter 2 | The heat pump – the heart of the house NIBE F1226... - Page 15 1. Mark the applicable option. One of the options is pre-selected (white). 2. Press the OK button to confirm the selected option. The selected option has a green tick. Chapter 2 | The heat pump – the heart of the house NIBE F1226...
- Page 16 Scroll through the windows in the start guide language 4.6 start guide NIBE F1226 Arrows to scroll through window in start guide 1. Turn the control knob until one of the arrows in the top left corner (at the page number) has been marked.
- Page 17 1. Use the control knob to select the help symbol. 2. Press the OK button. The help text often consists of several windows that you can scroll between using the control knob. Chapter 2 | The heat pump – the heart of the house NIBE F1226...
-
Page 18: Maintenance Of F1226
Maintenance of F1226 Regular checks Your heat pump is, in principle, maintenance free and therefore requires minimal care after commissioning. On the other hand, it is recommended that you check your installation regularly. If something unusual occurs, messages about the malfunction appear in the display in the form of different alarm texts. -
Page 19: Saving Tips
April June July mars april juni juli Månad Month Increasing the indoor temperature one degree increases the energy con- sumption by approx. 5%. Chapter 2 | The heat pump – the heart of the house NIBE F1226... - Page 20 Engine block heater (Operation: 1 h/day, 4 months a year) Passenger compartment heater (Operation: 1 h/day, 4 months a year) These values are approximate example values. Chapter 2 | The heat pump – the heart of the house NIBE F1226...
- Page 21 After 1-2 years the heating curve should be adjusted again, as well as the offset heating curve and the building's thermostat valves, because the heating system, as a rule, requires a lower temperature once the drying process is complete. Chapter 2 | The heat pump – the heart of the house NIBE F1226...
-
Page 22: F1226 - At Your Service
3 F1226 – at your service Set the indoor climate Overview Sub-menus INDOOR CLIMATE 1 For the menu INDOOR CLIMATE there are several sub-menus. Status information for the relevant menu can be found on the display to the right of the menus. - Page 23 If it is warm outdoors and the room temperature is too low, increase the value in menu 1.1.1 by one increment. If it is warm outdoors and the room temperature is too high, reduce the value in menu 1.1.1 by one increment. Chapter 3 | F1226 – at your service NIBE F1226...
- Page 24 It is from this heating curve that the heat pump's control computer determines the temperature of the water to the heating Chapter 3 | F1226 – at your service NIBE F1226...
- Page 25 +2 steps increases the supply temperature by 5 °C at Outdoor temperature Utetemperatur all outdoor temperatures. (°C) Chapter 3 | F1226 – at your service NIBE F1226...
- Page 26 5. Press the OK or Back button to exit read off mode. Chapter 3 | F1226 – at your service NIBE F1226...
- Page 27 When the contact is on, the heating curve offset is changed by the number of steps selected in the menu. If a room sensor is installed and activated the desired room temperature (°C) is set. Chapter 3 | F1226 – at your service NIBE F1226...
- Page 28 °C Set the minimum temperature on the supply temperature to the climate system. This means that F1226 never calculates a temperature lower than that set here. The value can be increased if you have, for example, a cellar that you always want to heat, even in summer.
- Page 29 You can create your own heating curve here, if there are special require- ments, by setting the desired supply temperatures for different outdoor temperatures. Caution Curve 0 in menu 1.9.1 must be selected for own curve to apply. Chapter 3 | F1226 – at your service NIBE F1226...
- Page 30 "-2" and "change in curve" is increased until the desired room temperature is maintained. Caution Wait 24 hours before making a new setting, so that the room temperat- ure has time to stabilise. Chapter 3 | F1226 – at your service NIBE F1226...
-
Page 31: Set The Hot Water Capacity
The function is activated immediately when a time period is selected and confirmed using the OK button. The remaining time for the selected setting is shown to the right. Chapter 3 | F1226 – at your service NIBE F1226... - Page 32 When the time has run out F1226 returns to the mode set in menu 2.2. Select “off" to switch off temporary lux comfort mode Menu Setting range: economy, normal, comfort mode 2.2 luxury Default value: normal economy normal luxury The difference between the selectable modes is the temperature of the hot tap water.
- Page 33 The length of time between increases can be selected here. The time can be set between 1 and 90 days. Factory setting is 14 days. Tick/untick "ac- tivated" to start/switch off the function. Chapter 3 | F1226 – at your service NIBE F1226...
-
Page 34: Get Information
-5.6 °C brine in 6.2 °C A QR code appears on one side. This 3.9 °C brine out QR code indicates serial number, product name and limited operating data. Chapter 3 | F1226 – at your service NIBE F1226... - Page 35 No changes can be made. The information is on several pages. status: Turn the control knob to scroll time factor: between the pages. Chapter 3 | F1226 – at your service NIBE F1226...
- Page 36 4. You can now select to take read outs for different weeks by turning the control knob to the right or left and read off the average temper- ature. 5. Press the OK or Back button to exit read off mode. Chapter 3 | F1226 – at your service NIBE F1226...
-
Page 37: Adjust The Heat Pump
Setting heat pump work mode. plus functions Menu plus functions4.1 Settings for any additional functions installed in F1226 can be made in the sub menus. Chapter 3 | F1226 – at your service NIBE F1226... - Page 38 (immersion heater not permitted). With over capacity mode of "SG Ready" the hot water is set to "luxury" (immersion heater permitted). NOTE The function must be connected and activated in your F1226. op. mode Menu op. mode op. mode 4.2 Setting range: auto, manual, add.
- Page 39 Caution If you deselect "addition" it may mean that sufficient heating in the ac- commodation is not achieved. Chapter 3 | F1226 – at your service NIBE F1226...
- Page 40 Menu advanced 4.9 Menu advanced is intended for the advanced user. This menu has several sub-menus. op. prioritisation auto mode setting degree minute setting factory setting user Chapter 3 | F1226 – at your service NIBE F1226...
- Page 41 Select the average outdoor temperatures in this menu. You can also set the time over which (filtering time) the average temper- ature is calculated. If you select 0, the present outdoor temperature is used. Chapter 3 | F1226 – at your service NIBE F1226...
- Page 42 Do you want to reset all user settings to factory settings? Caution After factory setting, personal set- tings such as heating curves must be reset. Chapter 3 | F1226 – at your service NIBE F1226...
-
Page 43: Disturbances In Comfort
Selecting "aid mode” is not the same as correcting the problem that caused the alarm. The status lamp will therefore continue to be red. If the alarm does not reset, contact your installer for suitable remedial ac- tion. Chapter 4 | Disturbances in comfort NIBE F1226... -
Page 44: Troubleshooting
Enter menu 4.2. If mode "auto" is selected, select a higher value on – "stop heating" in menu 4.9.2. If mode "manual" is selected, select "heating". If this is not enough, – select "addition". Chapter 4 | Disturbances in comfort NIBE F1226... -
Page 45: High Room Temperature
Wait until the temperature condition has been reset. – Minimum time between compressor starts has not been reached. ■ Wait 30 minutes and then check if the compressor has started. – Alarm tripped. ■ Follow the display instructions. – Chapter 4 | Disturbances in comfort NIBE F1226... -
Page 46: Only Additional Heat
1. Go to menu 4.2 op. mode. 2. Mark ”add. heat only” using the control knob and then press the OK button. 3. Return to the main menus by pressing the Back button. Chapter 4 | Disturbances in comfort NIBE F1226... -
Page 47: Technical Data
5 Technical data Detailed technical specifications for this product can be found in the in- stallation manual (www.nibe.eu). Chapter 5 | Technical data NIBE F1226... -
Page 48: Glossary
A heater with a coil in it. The water in the coil heats the water in the heater. Collector Hose where the brine circulates in a closed system between the heat source and the heat pump. Chapter 6 | Glossary NIBE F1226... -
Page 49: Domestic Hot Water
The lower the dimensioned outdoor temperature, the lower the value should be selected on "selecting a heat curve". Efficiency A measurement of how effective the heat pump is. The higher the value is the better it is. Chapter 6 | Glossary NIBE F1226... -
Page 50: Emergency Mode
The cold brine from the collector/borehole is used to cool the accommod- ation. Heat exchanger Device that transfers heat energy from one medium to another without mixing mediums. Examples of different heat exchangers are evaporators and condensers. Chapter 6 | Glossary NIBE F1226... -
Page 51: Heating Medium Side
A valve that mixes the cold water with the hot water leaving the heater. Outside sensor A sensor that is located outdoors. This sensor tells the heat pump how hot it is outdoors. Passive cooling See "Free cooling". Chapter 6 | Glossary NIBE F1226... -
Page 52: Safety Valve
Radiator Another word for heating element. They must be filled with water in order to be used with F1226. Refrigerant Substance that circulates around a closed circuit in the heat pump and that, through pressure changes, evaporates and condenses. During evap- oration, the refrigerant absorbs heating energy and when condensing gives off heating energy. -
Page 53: Water Heater
Water heater Container where domestic water is heated. Is located inside the heat pump, but an extra hot water heater can be installed in the event of large hot water requirements. Chapter 6 | Glossary NIBE F1226... -
Page 54: Item Register
Only additional heat, 46 Saving tips, 19 Troubleshooting, 44 Power consumption, 19 Scroll through the windows, 16 F1226 – An excellent choice, 7 Selecting menu, 14 F1226 – at your service, 22 Selecting options, 15 Adjust the heat pump, 37... -
Page 55: Contact Information
Tel: +7 831 419 57 06 E-mail: kuzmin@evan.ru www.nibe-evan.ru NIBE AB Sweden, Box 14, Hannabadsvägen 5, SE-285 21 Markaryd Tel: +46 (0)433 73 000 E-mail: info@nibe.se www.nibe.se For countries not mention in this list, please contact Nibe Sweden or check www.nibe.eu for more information. - Page 56 WS name: Niklas - F1X26 WS version: a7 (working edition) Publish date: 2017-10-04 12:12 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 231651...
