How It Works; Energy Use - Envirovent cyclone 7 Installation Manual

The Cyclone 7 is a major advancement in extract fan
technology, designed to deliver high performance in
controlling humidity levels in kitchens, bathrooms and
utility rooms using the lowest energy consumption.
The Cyclone 7 also incorporates patented BioCote
antibacterial protection to inhibit the growth of bacteria,
microbes and mould on the surface of the fan by up
to 99.9%.

HOW IT WORKS

The Cyclone 7 works in a constant trickle mode to
create background ventilation to maintain a healthy
environment.
Vapour tracking
As standard the unit is fitted with vapour tracking. The
fan senses the amount of moisture being created in
the room which causes the fan to increase in speed to
match the rising humidity and reduce in speed to match
falling humidity. This intelligent function reduces your
energy costs, wear and tear on the motor and ensures
a long quiet life.
Pullcord
All units are fitted with a pullcord override for odour
control (if remote see below). In the event that you
wish to activate the fan to full power in conditions of
low humidity simply pull on the pullcord and the fan will
boost to maximum extraction rate.
OPTIONS
Remote control
Remote control override for odour control. In the
event that you wish to activate the fan to full power
in conditions of low humidity simply press the remote
control boost switch and the fan will boost to the
maximum extraction rate for 3 to 4 minutes before
returning to the trickle extract rate.
N.B: When battery requires changing, unscrew the
switch front cover. The battery is located on the back
of the cover (CR2032) lithium coin battery). Switch
will remain paired with the fan even after battery
replacement.
Remote Switch Wire
The unit is available with a remote switch wire. On these
units the boost switch may be located up to 3 meters
away from the unit.
®

ENERGY USE

The Cyclone 7 uses ultra Low Watt Motor Technology
to achieve the lowest running costs of any domestic
extract fan. It uses only a minimal amount of electricity
whilst eliminating stale and moist air from the home.
This gives an annual running cost of only £1.97 based
on an electricity cost of £0.15 per unit (KWH), and a two
hour 'boost' per day.
Household Appliance
Cyclone 7
Fridge Freezer
21" Television (viewing time)
100W Light Bulb
Home Computer
Games Console
Iron
Tumble Dryer
Coldfill Dishwasher
Time required to consume
£1.97 of electricity
1 Year
6 and a half days
5 and a half days
5 and a half days
1 and a half days
1 and a half days
13 Hours
5 and a quarter hours
7 Full Loads
2
