10.9 Alarm

The different alarms that can occur are described in
( Chapter 11).
Under Alarms there is:
• Information log
• Delete information log
• Alarm log
• Delete alarm log
• Alarm indication
> Information log
The information log displays information from the heat
pump. The control panel output mode displays the
symbol for information log when the active information
is available.
> Delete information log
The information log is deleted here.
> Alarm log
The alarm log shows the alarms and warnings that have
occurred. Alarm category (
in the top left corner of the display. If the alarm is active,
the alarm symbol ( Chapter 8.3) is displayed both in
the alarm log and the initial menu of the control panel.
> Delete alarm log
The alarm log is deleted here.
> Alarm indication
Under Alarm indication settings for alarm buzzer and
status lamp are made here.
>> Alarm buzzer signal
>>> Interval
Factory setting
Lowest value
Highest value
Tab. 41 Interval
B Set the length of the alarm interval.
The alarm buzzer sounds for one second and is silent
during the rest of the interval. The setting applies to
all alarm buzzers.
6 720 643 415 (2010/03)
Chapter 11.5) is displayed
2s
2s
3600s (60min)
>>> Blocking time
Factory setting
Start time
Stop time
Tab. 42 Blocking time
B Set the times between which alarms buzzers should
not be allowed to produce an acoustic signal.
>> Alarm indication control unit
>>> Block alarm buzzer
Factory setting
Alternative
Tab. 43 Block alarm buzzer
The setting applies only to the control unit's alarm
buzzer.
>> Alarm indication room sensor
>>> Block alarm buzzer
Factory setting
Alternative
Tab. 44 Block alarm buzzer
The setting applies only to circuit 1.
The setting applies to Circuit 1 and to a CANbus-
connected room sensor.
Factory setting
Alternative
Tab. 45 Block status lamp
The setting applies to all room sensors.

10.10 Access level

Access level is Customer as standard: This level gives
you access to all functions that the user requires. The
installer also has access to the additional functions
required at installation.

10.11 Return to factory settings

B Select Return to factory settings and Yes to reset all
customer settings to the factory settings. Settings
made by the installer are not affected.
Factory setting
Alternative
Tab. 46 Return to factory settings
Settings Customer level
Off
0:00 - 23:45
0:00 - 23:45
No
No/Yes
Yes
No/Yes
Yes
No/Yes
No
Yes/No
