rollibot RolliCute User Manual

Robotic vacuum
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TM
ROBOTIC VACUUM
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RolliCute and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for rollibot RolliCute

Summary of Contents for rollibot RolliCute

  • Page 1 ROBOTIC VACUUM USER MANUAL...
  • Page 2 Customer Service: 1-844-585-6295...

  • Page 3: Table Of Contents

    Contents Section 1. Safety Warnings & Guidelines .............1 1.1 — Safety Warnings .....................1 1.2 — Disposal at End-of-Life ..................2 Section 2. Parts & Assembly .................3 2.1 — Box Contents ......................3 2.2 — Components Overview ..................3 2.3 — Battery Information & Installation ..............4 2.4 —...

  • Page 4: Section 1. Safety Warnings & Guidelines

    • Clean the outside with dry, non-abrasive cloth only. Do not spray water or liquids onto the RolliCute. • Do not insert objects into the RolliCute or allow the RolliCute to clean up near any part of your body including but not limited to your fi ngers or hair etc.

  • Page 5: Disposal At End-Of-Life

    • Store the RolliCute indoors at a dry and stable temperature. Do not store in an unheated garage, shed, or other location with extreme temperature fl uctuations. • Cover the RolliCute to protect it from dust. Do not store in a dusty environment as, with all electronic devices, dust may cause damage over time.

  • Page 6: Section 2. Parts & Assembly

    4x Edge Brush Caps & 1x Screwdriver 4x Screws 4x Edge Brushes 2x Microfiber Cleaning Cloth 1x Cloth Base 1x User Manual The RolliCute also contains 1x preinstalled fi lter. 2.2 - Components Overview Top View Top Cover Charge Port Status Indicator Bumper...

  • Page 7: Battery Information & Installation

    4-5 hour charging time. Install it before proceeding. Refer any non-routine battery maintenance to RolliBot. Use only the battery included in the original packaging or received from RolliBot as a replacement. pull press Step 1.

  • Page 8: Assembly

    Step 5. Replace the top cover. 2.4 - Assembly See the following images and instructions to assemble the outer parts of the RolliCute. Step 1. Thread the bristles of two edge brushes through two edge brush caps then push the caps down until they attach to the brushes.

  • Page 9: Section 3. Usage

    • Clean the outside with dry, non-abrasive cloth only. Do not spray water or liquids onto the RolliCute. • Do not insert objects into the RolliCute or allow the RolliCute to clean up near any part of your body including but not limited to your fi ngers or hair etc.

  • Page 10: Charging

    After it is fully charged, disconnect it from the charger. • It is recommended to charge the battery at least 16 hours before using the RolliCute for the fi rst time. Batteries perform best after several full charge/discharge cycles.

  • Page 11: Using

    Step 1. Click the power switch on the side of RolliCute to turn it on. Once on, the Status Indicator will turn on and the brushes will start to rotate as the RolliCute begins a quick self-test. Step 2. Once the self-test is complete and all components are ready, the Status Indicator will turn off and the RolliCute will move randomly as it begins to clean.

  • Page 12: Section 4. Maintenance

    • Clean the outside with dry, non-abrasive cloth only. Do not spray water or liquids onto the RolliCute. • Do not insert objects into the RolliCute or allow the RolliCute to clean up near any part of your body including but not limited to your fi ngers or hair etc.

  • Page 13: Cleaning The Dustbin

    • The dust box and fi lter can be cleaned with water if needed. After rinsing, fully dry both the dustbin and fi lter before placing them back in the RolliCute. If not fully dried, the RolliCute’s internal parts may be damaged or the fi ltering may not work.
  • Page 14 Reassemble the fi lter brackets and check that the four tabs are securely closed. Step 6. Put the fi lter back inside the dustbin. Step 7. Put the dustbin back inside the RolliCute and put the top cover back on.

  • Page 15: Cleaning & Replacing The Brushes

    4.4 - Cleaning & Replacing the Brushes The RolliCute comes with four edge brushes, two for initial installation and two extra to use as replacements. See the following image and instructions for information on how to clean and replace the edge brushes.

  • Page 16: Section 5. Troubleshooting & Information

    The RolliCute fell down the steps. Are the cliff sensors working? There may be an issue with the sensors. Check the bottom of the RolliCute around the sensors for dust or debris and clean as needed. Additionally, you can check the top of the stairs for excess debris or obstacles.
  • Page 17 Check the wheels for debris or blockage. Clean as needed. Fan error Clean the entire RolliCute and restart it. If the information in Sections 5.1 or 5.2 does not resolve your issue, please visit our website at www.rollibot.com or contact customer support 1-844-585-6295.

  • Page 18: Section 6. Warranty Information

    AND A VALID CLAIM IS RECEIVED WITHIN THE WARRANTY PERIOD, AT ITS OPTION AND TO THE EXTENT PERMITTED BY LAW, ROLLIBOT WILL: (1) REPAIR THE HARDWARE DEFECT BY USING NEW OR REFURBISHED PARTS THAT ARE EQUIVALENT TO NEW IN PERFORMANCE AND RELIABILITY;...
