Summary of Contents for rollibot LASEREYE
- Page 1 ROBOTIC VACUUM USER MANUAL...
- Page 2 Customer Service: 1-844-585-6295...
- Page 3 The LaserEye is an intelligent vacuum that uses the latest technology to improve your quality of life. We’ve designed LaserEye to be easy to use in your home, offi ce, or just about anywhere else that can use a little bit of tidying. Its ultra-smart navigation and scheduling means it can easily clean any space, any time.
-
Page 4: Table Of Contents
2.1 Box Contents ....................4 2.2 Components Overview ................4 2.3 Remote Control Overview ................. 5 Section 3. How The LaserEye Cleans ..............6 Section 4. Initial Setup ................... 6 4.1 Charging Station Assembly & Setup ............6 4.2 Film Removal....................6 Section 5. -
Page 5: Section 1. Safety Warnings & Guidelines
Clean the outside with a dry, non-abrasive cloth only. Do not spray water or liquids onto the LaserEye. • Do not insert objects into the LaserEye or allow the LaserEye to clean up near any part of your body. •... -
Page 6: Disposal At End-Of-Life
• Charge in a clean and dry indoor environment. • Cover the LaserEye to protect it from dust. Do not store in a dusty environment as, with all electronic devices, dust may cause damage over time. • Do not use an adapter with a damaged cord or plug. -
Page 7: Section 2. Parts & Assembly
1x Adapter 2x Edge Brush(1x Preinstalled) 2x Screws User Manual 2x Small Air Filters (Preinstalled) 1x Exhaust Filter (Preinstalled) 1x User Manual The LaserEye comes with the battery pack and some parts preinstalled. 2.2 Components Overview Control Panel Laser Sensor Bumper... -
Page 8: Remote Control Overview
Cliff Sensors Charging Contacts Edge Brush 360˚ Front Wheel Battery Compartment Wheels Rubber Agitator Brush Bristle Agitator Brush Dustbin Control Panel Detail Current Time Schedule Key Start/Stop Keys Clock Setting Key Spot Cleaning Key Battery Indicator Home Key 2.3 Remote Control Overview The remote control uses a CR2025 3V battery. -
Page 9: Section 3. How The Lasereye Cleans
(0.5in or 1.5cm), wood or laminate fl ooring, linoleum, and ceramic tile etc. in indoor environments. Every time the LaserEye is turned on and preparing to clean, it will rotate as it scans. During this scan, the LaserEye analyzes surroundings to determine the size of the area and map out a path covering every reachable part of the fl oor. -
Page 10: Section 5. Charging Instructions
Click the Power Switch to turn the vacuum on and wait 20 seconds. Step 2. Place the LaserEye on the fl oor and slowly push it towards the Station’s center until the Step 3. contacts on the underside of the vacuum connect with the base. -
Page 11: Section 6. Usage Instructions
LaserEye’s functions. • When setting the clock and cleaning schedule, the LaserEye uses 24-hour time for precise timing. • After approximately 3 minutes of non-use, the Control Panel will turn off to conserve battery power. Press any key to turn it on again. -
Page 12: Section 7. Maintenance Instructions
Clean the outside with dry, non-abrasive cloth only. Do not spray water or liquids onto the LaserEye. • Do not insert objects into the LaserEye or allow the LaserEye to clean up near any part of your body. • Do not use this device to pick up anything that is burning or smoking. -
Page 13: Maintaining The Dustbin
It is recommended that you empty the dustbin after the fi rst few cleaning cycles especially if the LaserEye was able to clean hard to reach areas. After this, clean out the dustbin after every 3-4 cleaning cycles. For dustbin and additional maintenance, see the images and instructions in the upcoming sections. - Page 14 Use the included screwdriver to fasten the screws and reattach the side to the motor. Step 6: Close and/or reinstall all remaining parts of the dustbin then return it to the LaserEye, Step 7: making sure it is fully inserted.
-
Page 15: Maintaining The Agitator Brushes
• If the dustbin is not emptied regularly, the LaserEye may not work properly. • If rinsed, the large fi lter MUST be fully dried before reinstalling. If water enters the LaserEye, the vacuum may sustain serious internal damage. • The exhaust fi lter should only be cleaned and/or rinsed as needed as excess maintenance may cause damage. -
Page 16: Maintaining The Edge Brush
Step 2. and Cliff Sensors. Section 8. Storage Instructions Before storing your vacuum, select a dry, indoor environment and ensure the LaserEye is fully charged. Charge it if needed. Properly storing your LaserEye will help improve performance and battery life expectancy. -
Page 17: Section 9. App Setup
Before storing, fully charge the LaserEye to prevent battery over-discharge due to non-use. • Cover the LaserEye to protect it from dust. Do not store in a dusty environment as, with all electronic devices, dust may cause damage over time. -
Page 18: Section 11. Troubleshooting
Charging Station, the LaserEye may have trouble reaching it and/or run out of battery power. Ensure the area around the Station is clear at all times. The LaserEye fi nished a spot cleaning cycle. Use the remote or the keys on top of the A (2): LaserEye to stop it and/or change the type of cleaning performance as desired. -
Page 19: Section 12. Warranty
Warranty services are provided by Warranty Pro. If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, RolliBot will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;...
