Page 1 SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 2 http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 3 SETU ATA211 VoIP-FXS-FXO Adaptor System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 4 Neither Matrix Comsec nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs or expenses incurred by the purchaser or third parties as a result of: accident, misuse or abuse of this product or unauthorized modifications, repairs or alterations to this product or failure to strictly comply with Matrix Comsec's operating and maintenance instructions.
Page 5: Table Of Contents
About this System Manual ..........................1 How to Read this System Manual ........................2 Knowing SETU ATA211 ..........................5 The Overview ..............................5 Applications of SETU ATA211 ..........................7 Getting Started ..............................9 Preparing for Installation ............................. 9 Connecting SETU ATA211 ..........................11 Configuring SETU ATA211 ..........................
Page 6 Acronyms ................................ 150 Features at a Glance ............................152 Product Specifications ............................. 153 System Commands ............................156 Warranty Statement ............................157 Regulatory Information ............................ 159 Open Source Licensing Terms and Conditions ....................161 Index ................................169 Table of Contents http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 7: Introduction
CHAPTER 1 Welcome! Welcome to the world of Telecom Solutions. Thank You for choosing SETU ATA211. This product is designed to give you the highest performance, combined with real ease of use. We hope you will make optimum use of this intelligent, intuitive, feature-packed VoIP Phone Adapter.
Page 8: How To Read This System Manual
How to Read this System Manual This System Manual is organized in a manner to help you get familiar with SETU ATA211, learn how to install it, how to connect it to the IP network, how to configure the Basic Settings that allow you to start making and receiving calls, and move on to the Advanced configuration to use the special features and functions.
Page 9 LAN administrator: A person who maintains the LAN network of an organization. Using this manual, you will be able to install, operate and make optimum use of SETU ATA211. If you encounter any technical problems, please contact your Dealer/reseller or Matrix for support.
Page 10 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 11: Knowing Setu Ata211
Using ATA211, you can make VoIP calls and browse the Internet simultaneously. SETU ATA211 can be used in residences, small and home offices, offices of medium and large enterprises. SETU ATA211 supports 3 SIP trunks, allowing you to subscribe with three different Internet Telephony Service Providers or to use the SIP trunks for Peer-to-Peer Calls.
Page 12 To connect a PSTN line or a PBX. LEDs SETU ATA211 has an LED each for the FXS port, FXO Port, the SIP Trunks (SIP1, SIP2) and POWER, to indicate the status of the ports, and various events occurring on the ports, including errors.
Page 13: Applications Of Setu Ata211
Residential Application - Home users use SETU ATA211 to make low-cost international calls to family, friends and relatives. IP Network Broadband ATA211 Modem/Router Proxy PSTN SOHO Application - Small Office owners use SETU ATA211 to make low-cost calls to their overseas customers, employees, suppliers, etc IP Network Broadband ATA211 Modem/Router Proxy PSTN Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 14 Business Application - Corporate Offices use SETU ATA211 to make low-cost international calls to their overseas customers, employees, suppliers, etc. IP Network Proxy FXS1 ATA211 Broadband Modem/Router Switch PSTN Peer-to-Peer Calls Application - Corporate Offices also use SETU ATA211 to communicate between various branch offices, at no cost..
Page 15: Getting Started
Verify the package contents. Contact your vendor/Service Provider/system administrator, if any of the above listed items is missing or damaged. Protecting SETU ATA211 You are recommended to take the measures listed in the following protect yourself and SETU ATA211. Installation Precautions Do not install the system in a place where •...
Page 16: Safety Instructions
Unplug the product from the wall outlet before cleaning.Do not use liquid cleaners. Use only dry and soft cloth. Always get your product serviced by a trained, qualified person. Contact your authorised dealer or Matrix support, • liquid has been spilled into the product or the product has been exposed to rain or water.
Page 17: Connecting Setu Ata211
You may also connect a PBX to the FXS port of SETU ATA211. • Connect the PSTN line to the FXO Port of SETU ATA211, using a standard telephone cable with an RJ11 plug. You may also connect PBX to the FXO port of SETU ATA211.
Page 18 (SIP is configured for P2P calling). Continuously OFF Indicates that SIP2 is disabled. You can also view the status of the ports on the Status page of the web-based graphical user interface of SETU ATA211. See “System Status”. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 19: Configuring Setu Ata211
Admin Mode Admin is defined as the person who installs, configures and maintains the SETU ATA211. The Admin can also be the User. In the Admin mode, you have full access to system configuration, all configurable parameters, features and facilities, and system maintenance: •...
Page 20 If required, change the IP Address and the Subnet of the computer. You may also connect the LAN port of SETU ATA211 to a computer on LAN. If you connect the LAN port of SETU ATA211 to a LAN Switch, make sure that the IP Address of LAN port of SETU does not conflict with the IP Address of any device on the LAN, and SETU ATA211 is in the same Subnet as the LAN computer.
Page 21 On successful login, the Admin mode page will open. • The left pane shows the links Basic Settings, Advanced Settings, Supplementary Services, and Status. Basic Settings are sufficient to get your SETU ATA211 into operation. • Click the links to expand. To log in as User, Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 22 Configuring using a Phone You can enter the Admin mode and the User mode using the phone connected to the FXS Port of SETU ATA211, and change feature settings, and certain network parameters like the IP Address and Subnet Mask of the LAN and the WAN port of SETU ATA211, select the Connection Type (IP Addressing) by dialing “System Commands”...
Page 23: User Mode
To change IP Address of the LAN Port dial 12<LAN IP Address>#* For example, to change the IP address to 192.168.1.120, dial 12192168001120#* • When you dial a valid command, SETU ATA211 plays a confirmation tone for 3 seconds, and plays the programming tone. •...
Page 24 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 25: Basic Settings
Basic Settings CHAPTER 4 The Basic Settings enable you to configure SETU ATA211 for basic functions. As Basic Settings cover much of your configuration requirements, you will be able to operate and use the system efficiently, when you configure Basic Settings.
Page 26: Region
Click Basic Settings to expand. The following links appear under Basic Settings: • Region • • • • Passwords • Network Each of these are explained in detail in the following. Region Click Region. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 27 Default: India. During an incoming call, SETU ATA211 will play the ring over the SLT as per the Ring Cadence of the country you selected. For a complete list of Ring Cadences of different countries supported by SETU ATA211, see “Appendix”.
Page 28 India, you can select the time zone for India (GMT+5.30 Calcutta, Chennai, Mumbai, and New Delhi). The time for India is offset from GMT by +5.30 hours. Similarly, if your SETU ATA211 is installed in Hawaii, select the time zone for Hawaii, which is off- set by GMT -10:00 hours, to set the correct time and date.
Page 29: Sip Trunks
SIP Trunks SETU ATA211 supports three SIP trunks, which may be configured as Proxy or Non-Proxy, i.e. Peer-to-Peer trunks. You may register with three different ITSPs and use their services. Click the link SIP. The parameters of SIP Trunk 1 appear on your screen.
Page 30 Select Peer-to-Peer, if you want to use the trunk for Peer-to-Peer (non-proxy) calls. If you select Peer-to-Peer, you must also configure the number strings in the Peer-to-Peer Table. • Click the arrow icon to configure the Peer-to-Peer Table. A new window opens. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 31 For example, if the peer-to-peer number to be dialed out is 123@abc.com, enter abc.com as Destination Address. If the number is 1234@ 192.168.1.197, enter 192.168.1.197 as the Destination Address. The Destination Address can also be in the form of Address:Port number. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 32 Authentication Password. SIP Registration is applicable for Proxy SIP Trunks only. Default: Disabled. Select the check box to enable. SETU ATA211 will send the REGISTER message to Registrar proxy or Outbound proxy as applicable. Select the OG Calls without Registration check box to allow the users to make outgoing calls irrespective of whether the SIP Trunk has been successfully registered with proxy or not.
Page 33 To add ‘rinstance’ in REGISTER? Message, keep this feature enabled. Default: Enabled. ‘rinstance’ is any random value which can be used by the SETU ATA211 to fetch its own contact binding, i.e. to know the Registration Expiry Timer assigned by the server.
Page 34 • Answer the call, collect number & route to FXS: Select this option, if FXS port of SETU ATA211 is connected to the FXO port of the PBX and you want callers to reach extensions of the PBX by simply dialing the extension number.
Page 35 If you have selected Pin Authentication, you must configure the PIN Authentication Table. To do this, 2. SETU ATA211 supports display of Calling Line Identity (CLI) on the FXS Port, depending on number received in the request SIP mes- sage.
Page 36 PIN Authentication is applicable when incoming call option on the SIP Trunk is selected as Answer the call, collect the number and route to FXS OR Answer the call, collect the number and route to FXO. If you select Digest Authentication, you must configure the Digest Authentication Table. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 37 The User ID may be a maximum of 40 characters. The User Password may be a maximum of 16 characters. • If you have finished entering the User IDs and their corresponding User Passwords in this Table, click Submit. • Close the window. To know more about this feature, see “Digest Authentication”. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 38 Vocoders are the various voice codecs used to compress the data in RTP packets for optimum use of bandwidth and for ensuring voice quality. You can set 4 Vocoder options in the order of preference. The Vocoders supported by SETU ATA211 in the order of preference, i.e. 1st to 4th, listed in the Used Codecs box are: •...
Page 39 ITSP you have subscribed this SIP trunk restricts the dialing of the prefix 00 for international numbers. If you happen to dial this prefix, your call will be rejected by the ITSP. ANT is also used when SETU ATA211 is deployed for networking between PBXs at multiple sites, and “Multi Stage Dialing”...
Page 40 • The Automatic Number Translation table opens in a new window. In this table, you can store as many as 24 Dialed Numbers and their corresponding Substitute Numbers, at Index Numbers 01 to 24. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 41 Make sure you disable Outbound Proxy on SIP trunk and configure the STUN Server Address and port “System Parameters”. Select the appropriate DTMF sending/receiving mechanism that is compatible with the DTMF sending/ receiving mechanism of your ITSP or remote peer. SETU ATA211 supports: • Inband •...
Page 42 G.711. Default: T.38 (UDPTL). If the FAX sent using T.38 is rejected, SETU ATA211 will use Pass Through as the Fall Back protocol to send the fax. If you have completed the configuration of SIP Trunk 1, click Submit to save settings.
Page 43: Fxo Port
FXO Port SETU ATA211 supports a FXO Port, • which may be interfaced with the analog trunk from PSTN and used to route incoming calls to FXS port or SIP trunks. • which may be interfaced with FXS port of the PBX.
Page 44 SIP1, SIP2, SIP3 or Dialed Number Table. If you select this option, select the Incoming Call Route. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 45 Table. If the number matches, the destination route corresponding to the number will be used for call routing. If you select this option, you must configure the Dialed Number Table. To do this, • Click the arrow icon. The Dialed Number Table opens in a new window. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 46 For the number you entered, select as Destination Route the SIP Trunk / FXS port/ FXO port. At the bottom of the table, select Destination Route for dialed numbers that do not match with any of the entries configured in this table (No Match Found) by the Source Port. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 47 If you want to Authenticate Incoming Calls on FXO port, that is you want to allow incoming calls only after callers have authenticated themselves, enable PIN Authentication. Default: Disabled. You must configure the PIN Authentication Table. To do this, • Click the arrow icon. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 48 PIN number can be a of maximum 4 digits. The characters allowed are: 0-9,*, # • If you have finished entering, click Submit. • Close the window. To know more about this feature, see “PIN Authentication”. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 49 Disconnect Signaling is used in the application where a PCO machine is connected to the FXS port of ATA211. This signalling is used to indicate the event of call disconnection (when the called party has gone On-hook) so that the PCO machine can stop billing. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 50 Now, during the call, when remote party 'Y' goes On-hook, but the PSTN does not send any disconnect signal as an indication of On-hook, party 'X' will not know this and remain Off-hook, even after party-Y has gone On-hook. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 51 Make a list of numbers that need to be modified before being dialed out from the FXO port. Make a list of the corresponding modified numbers that the system should substitute the dialed numbers with. • Click the arrow icon. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 52 If you have selected the Dial Type as Pulse, you must set the Pulse Dial Ratio as per your country. You can select the required pulse dial ratio from the following options: 40:60, 50:50 and 33:67. Default: 50:50. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 53 FXO Port. This is used when exchange takes some tome to detect that FXO Port is Off-hook. Valid range: 1 to 9 sec. Default: 1 sec. Configure the FXO Busy Wait Timer, if you want SETU ATA211 to wait before routing a call to a busy FXO port.
Page 54 You may also adjust the Listening Volume (Receive) on FXO port to increase or decrease the volume of the calling party's voice being transmitted to you. Select the required Listening Volume level from the drop- down list. Default: 0 db. Click Submit to save the settings. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 55: Fxs Port
FXS Port SETU ATA211 supports an FXS port. Depending upon your requirement, you can either connect an standard, analog telephone instrument to the FXS port, or interface the FXS port with the FXO port of a PBX. To configure the FXS port parameters, Click FXS.
Page 56 Select Route all calls as per Dialed Number Table, if you want specific numbers to be routed though specific SIP Trunks only. If you select this option, you must configure the Dialed Number Table. To do this, Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 57 Default: SIP 1. • At the bottom of the table, select Destination Route for dialed numbers that do not match with any of the entries configured in this table, i.e.No Match Found. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 58 The PIN Authentication Table page opens in a new window. • Enter the PIN to be authenticated against each Index in the Table. PIN number can be of a maximum of 4 digits. The characters allowed are: 0-9,*, #. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 59 You may disable the feature you do not want to allow to the FXS port. 4. Class of Service (CoS) defines the set features of SETU ATA211 that the phone connected to the FXS port is to be allowed access to.
Page 60 If a PCO machine is connected to the FXS port of the SETU ATA211, whenever the Called Party (remote party) disconnects, the FXS port of SETU ATA211 needs to be informed of this event in the form of a signal, so that the PCO machine can consider the call as complete and stop billing. In the absence of such a signal, the call will be considered as completed only when the Caller goes On-hook, resulting in inaccurate billing.
Page 61 Default: 32 msec. Select the appropriate AC Impedance according to the AC Impedance supported by the device connected to the FXS port of SETU ATA211. The device may be a phone or a PBX. You may select from the following impedance options: •...
Page 62 Select the required Listening Volume level from the drop-down list. Default: 0 db. If you have completed the configuration of FXS port, click Submit to save settings. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 63: Passwords
The default Admin and the default User Password are the same, 1234. Since the Admin Login gives the you access to configure all the parameters of SETU ATA211, while the User login has access to only user specific parameters, you may change the default password and use different Passwords for Admin and User Login.
Page 64 Changing User Password You can change the User Password only from Jeeves. To change User Passwords from Admin Mode: Log in as Admin. Click the link Basic Settings on the left pane to expand. Click Passwords. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 65 If you want to avoid having to set the entire system configuration to default settings, you may dial the related system command from your phone. To restore default User Password, Lift the handset of your phone. Dial #*** You will get dial tone after successful execution. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 66 Dialing this command string will also reset the Admin Password to factory default, if the option ‘Default Admin Password when User defaults the ATA? is enabled in the System Parameters. To avoid this, make sure you disable this option before you default the User Password. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 67: Network Parameters
Select Routing Mode, according to your installation scenario as NAT or Bridge. Default: NAT. • Select NAT as Routing Mode, if the LAN and WAN port of SETU ATA are in different network segments. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 68 The LAN port of SETU ATA211 is used for connect a standalone computer or a LAN Switch. If you need to change the IP Address or the Subnet Mask of the LAN Port of SETU ATA211, you may do so now.
Page 69 Select the Connection Type according to the IP addressing scheme of the network which SETU ATA211 is connected: DHCP, PPPoE, and Static. • Select DHCP, if the network uses a DHCP server to assign the IP address, Subnet Mask and Gateway address to SETU ATA211.
Page 70 Select Automatic DNS if you want DNS Address and Domain name to be assigned by the DHCP/PPPoE server automatically. This option will be applicable only if you have enabled DHCP or PPPoE as connection type. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 71 Select the VLAN/CoS check box to enable VLAN ID tagging on all packets generated by the system. Default: Disabled. • Enter the VLAN ID that you have assigned to the VLAN in which the SETU ATA211 is connected. The valid range for this is 0-4094. Default: 0001. •...
Page 72 SETU ATA211 will send all the RTP packets with RTP QoS setting, enter the RTP DiffServe/ ToS as per your requirement. Valid range is from 00-63, Default: 46 MAC address selection provides you two options: Unique and Clone. Default: Unique MAC Address.
Page 73: Advanced Settings
PCAP Software Upgrade Auto-Configuration System Parameters Certain parameters of SETU ATA211 are applied system-wide and are not specific to a port. These parameters are called System Parameters. To configure System Parameters, Log into Jeeves as Admin with your password. Click Advanced Settings on the left pane to expand the links.
Page 74 Click the link System. The System Parameters page opens. You may configure the following parameters on this page, as required: General Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 75 SIP Trunk. SETU ATA211 plays routing tone to the FXS / FXO port user when call is made through the SIP trunk. You may clear the Play Routing Tone check box, if you do not want the system to play routing tone.
Page 76 The valid range of the STUN Server Port is from 1024–65535. Default: 03478. • Clear the SIP Port fetched using STUN check box, if SETU ATA211 is located behind the NAT router and you have forwarded the SIP listening port of the SETU ATA211 in the router.
Page 77 “SIP Trunks”. • UDP NAT Keep Alive: When SETU ATA211 is connected behind a NAT router and SIP messages are transported over UDP, NAT Keep Alive messages must be sent to refresh the binding in the NAT router. Select the UDP NAT Keep Alive check box to enable. Default: Disabled.
Page 78 • RTP Listening Port: This is the port on which the SETU ATA211 listens for RTP Packets. This port is also used as the source port for sending RTP packets to the remote peer. The valid range for this port is 1024–65526.
Page 79: Called Party Number Table
Index02. The system will match the length of the digits with the minimum and maximum configured for the entry at Index02. If the minimum and maximum digits match the system routes the call through the FXO port selected as Destination Route for numbers starting with ‘2’. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 80 For the number you entered, define the Minimum Digits, which the system must receive to consider it as a valid number. Default:01 • For the number you entered, define the Maximum Digits. The number received must not exceed the maximum digits you have defined here. Default:24 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 81 • For the number you entered, select the Destination Route. It may be the FXS or FXO port to route the Called Party number. Click Submit save your entries. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 82: Dialed Number Table
The Dialed Number Table is a list of numbers or part numbers (you must configure), with a preferred SIP trunk / FXO port / FXS port for each number. When the user dials a number from the FXS port, SETU ATA211 checks the Dialed Number Table for a match using the best fit logic.
Page 83 Default: SIP 1 If no Destination Route is selected (‘None’) for an entry, the system will reject the call, even if a match is found for the dialed number in this table. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 84 For calls made from the FXO port, select the destination route for the option If dialed number does not match with either of the programmed number in the Dialed Number Table & call is made from FXO, route the call through. Default, SIP Trunk 1. Click Submit save your entries. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 85: Peer-To-Peer Numbers
To use this feature: • There must be a SETU ATA211 installed at each location. • The SETU ATA211 at each location must have a Static IP Address. Let us take the installation scenario illustrated below as an example. Location-B Location-A...
Page 86 For the number you entered, configure the digit length in the table. As the number you want to dial, 3001, has four digits, configure Minimum Digit for this number as ‘4’. Also configure the Maximum Digit as ‘4’. The Peer-to-Peer table you configure for SETU ATA211 at Location-A would look like this: Index Number...
Page 87 Index001 is reserved for No Match Found. For each Index number, • In the Number field, enter the peer-to-peer number string—prefix or entire number—that will be dialed. The number string must not exceed 24 characters. Default: Blank. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 88 To dial an IP Address, press * key (star/asterisk). For example, to call the IP Address 192.168.200.200, dial 192*168*200*200. When you press the * key it is interpreted by the SETU ATA211 as a '.' (dot/period). • Talk, when the remote party answers the call.
Page 89: Digest Authentication
SIP devices are stored. You must configure this table. When you enable this feature on a SIP trunk, for all incoming calls (SIP requests), • SETU ATA211 will challenge the identity of the calling party, i.e. the SIP device initiating the request to send its digest credentials. •...
Page 90 Click the link Advanced Settings on the left pane to expand the links. Click Digest Authentication. The Digest Authentication Table page opens. You can configure upto 500 entries in this table. This Table is common for all SIP trunks. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 91 • Enter the user name assigned to the caller/calling device in the User ID field. SETU ATA211 will use this User ID to match the digest credentials sent by the caller/calling devices when challenged. Make sure the User ID you enter here and the User ID assigned at the calling end are the same. The User ID can be up to 40 characters long.
Page 92: Daylight Savings Time
9. In most countries in Asia and Africa, and in certain countries of South America, DST is not observed. 10. SETU ATA211 sets its Date and Time according to the Time Zone you selected, and synchronizes the time according to the NTP Server you selected.
Page 93 Click Submit to save your DST settings. Example: If you are installing SETU ATA211 in a country in the European Union, as per the European Summer Time, the DST would start on the Last Sunday in March and end on the Last Sunday in October each year. Clocks Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 94 Now, go to the option DST End, and configure as follows. • Select 5th as the Ordinal. • Select Sunday as the Day. • Select October as the Month. • Set Time to 01 Hours and 00 Minutes. Click Submit to save DST settings. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 95: Static Routing Table
Network A and Network B are in different subnets. • You can configure only one default Gateway address in SETU ATA211 to send IP packets. • Now, as SETU ATA is connected behind two Routers, it will not be able to determine where to route the IP packets.
Page 96 If a perfect match is found, SETU ATA211 will start sending the IP packets to the corresponding Gateway Address configured in the table. If no match is found, SETU ATA211 will send the IP Packets to the default Gateway Address you configured in the “Network Parameters”...
Page 97 Gateway Address: This is the IP address of the node where the IP packets are to be sent. Generally, it is the IP address of the LAN interface of the Router (to which SETU ATA211 is connected). The Gateway Address must be in the same subnet as SETU ATA211.
Page 98: Restart Setu Ata211
Restart SETU ATA211 If you need to restart SETU ATA211, you may do it using Jeeves, instead of switching OFF and switching ON the system again. When you restart the system, all active calls will be disconnected and the ports in use will be released. The system configuration however, will not be affected.
Page 99: Reinstate Factory Defaults
'Default Admin password when ‘User’ defaults the ATA? in the System Parameters. See “Advanced Settings”. Restoring Factory Defaults Using Jeeves To restore Factory Defaults from Admin mode, Log in as Admin. Click the Advanced Settings link on the left pane to expand. Click Factory Defaults. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 100 You will get programming tone. Dial 21-Reverse Admin/User Password-#* For example: 21-4321-#* (the reverse of the default password 1234). In case you have forgotten the password, set the User / Admin Password to default. See “Passwords” instructions. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 101: Software Upgrade
Software Upgrade SETU ATA211 provides you the facility to upgrade the system software at the click of a button. SETU ATA211 supports an embedded FTP server which can be used for Uploading and Downloading System files, configuration files, drivers etc.
Page 102 • web: contains html files. Click any of these folders to view the files that SETU ATA211 is currently using. You may either delete the existing files or copy the existing files to another location (as backup). Copy the new configuration files from their location and paste these new files in these folders.
Page 103: Syslog (Debug)
'Syslog Server' on IP network. You can view the system debug messages on the remote server. Each debug message includes the MAC Address of SETU ATA211 which is sending debug messages in 'syslog server'.
Page 104 The system will send debug messages only for the level you have selected. ATA supports following Syslog Levels: • APPL • CONFIG • • • CALL • • • SNTP • STACK • • AUTO CONFIG • 5. Click Submit to save the settings. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 105 To debug the System from User mode, Log in as User. Click the Syslog link, under User Settings on the left pane. To configure Syslog settings, refer the steps 4 and 5 described for the Admin mode. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 106: Pcap Trace
A maximum of 1 MB of packets can be captured and stored in the system. SETU ATA211 also supports Filters and Promiscuous mode for capturing packets, which you can use to specify the types of data packets to be captured.
Page 107 When Promiscuous Mode is disabled, the system will capture only traffic that is directly related to it. Only traffic to, from or routed through the SETU ATA211 will be picked up by the PCAP Trace. 'Filter Settings' and 'Promiscuous Mode' (enabled) will not be cleared during power down.
Page 108 To use PCAP Trace from User mode, Log in as User. Click the PCAP link, under User Settings on the left pane. To configure PCAP settings, refer the steps 4 to 10 described for the Admin mode. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 109: Auto Configuration
TFTP/HTTP/HTTPS Server. This feature is useful for ITSPs and where multiple SETU ATA211 are connected. ITSPs can store the configuration files of each SETU ATA211 that they provide to their customers on the Auto Configuration Server (ACS). The configuration files of each ATA are to be stored in a folder named by its MAC Address.
Page 110 • Never: Select this option if you do not want Auto-Configuration process to be done during power ON. • At Each Power ON: Select this option if you want SETU ATA211 to perform Auto-Configuration at each power ON. • At Next Power ON: Select this option if you want SETU ATA211 to perform Auto-Configuration only during the next power ON.
Page 111 TFTP/HTTP/HTTPS server from where the configuration files are to be downloaded. When SETU ATA211 gets auto configured, it will send the request for the configuration files to the selected TFTP/HTTP/HTTPS server and restore the files from the folder as per this path.
Page 112 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 113: Features Of Setu Ata211
If you go On-hook during the feature tone, your call with party A will be disconnected. • If you go On-hook during error tone, you will get ring back. If you go Off-hook when your phone rings, you will get connected with party A again. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 114: Making A Second Call
When party B answers the call, you are in speech with party B. Making a second call feature can also be used with other features such as Call Transfer-Attended, Call Toggle and 3-Party Conference. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 115: Call Transfer
Call Transfer Using Call Transfer you can connect the person you are in speech with, with another party. SETU ATA211 offers two types of Call Transfer: • Call Transfer - Blind: You can transfer the call to the desired party, without informing the party of the transfer.
Page 116 If the transfer has failed, you will get error tone for two seconds and will be connected to the transfer target (party B), if available. If the transfer target has disconnected the call, you will be connected to the transferee. • If the transfer has timed out, you will get continuous error tone. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 117: Call Toggle
• This way, you can talk alternately to A and B, by dialing Flash-#4 again. When toggling between calls, you can disconnect the call you are currently in speech with by going On- hook. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 118: Call Waiting
Call Waiting When your phone is busy, the Call Waiting feature notifies you about another incoming call in the form of beeps. The Call Waiting feature of SETU ATA211 allows you to: • reject/ignore the waiting call. • hold the current call and attend to the waiting call.
Page 119 Incoming call on the FXO port cannot be rejected. Hence, issuing this command will only stop playing beeps and you will remain in speech with party A. • put party A on hold, by dialing Flash-#4. The beeps will stop, you will be in speech with party B. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 120 • disconnect your call with party A, by dialing Flash-#5 and answer the waiting call. The beeps will stop, you will be in speech with party B. Party A will be disconnected. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 121: Conference
When you go On-hook during an active Conference, the Conference will be terminated and both the calls will be disconnected. While initiating the conference, the SETU ATA211 supports the Vocoder G.711 (Mu-law) only. To use this feature, make sure that the Conference feature is enabled in the Class of Service of the FXS port.
Page 122: Do Not Disturb (Dnd)
Click Supplementary Features link. To set DND, select the Do-Not-Disturb check box. Default: disabled. To cancel DND, clear the Do-Not-Disturb check box. To set or cancel DND from User mode, Log in as User. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 123 To cancel, clear the check box. Using Phone • Lift handset of your phone. • Dial #19-Admin Password (default: 1234). • Dial #18-User Password (default: 234). • Dial 61-1-#* to set. • Dial 61-0-#* to cancel. • Replace handset. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 124: Call Forward
Timer for the phone to answer. This timer is configurable, and is set to 45 seconds as default. If the phone does not answer before the timer expires, SETU ATA211 considers it as No Reply and forwards it to the desired destination number.
Page 125 To use Call Forward from User mode, Log in as User. Click the Supplementary Features link under User Settings on the left pane. Select the check box for the Call Forward option you want to set: • Call Forward-Unconditional Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 126 Replace handset. To set/cancel Call Forward- Busy: • Lift the handset of your phone. • Dial #19-Admin Password (default:1234) • Dial #18-User Password (default:1234) • Dial 54-1-#* to set. • Dial 54-0-#* to cancel. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 127 To set/cancel Call Forward-No Reply: • Lift the handset of your phone. • Dial #19-Admin Password (default:1234) • Dial #18-User Password (default:1234) • Dial 56-1-#* to set. • Dial 56-1-#* to cancel. • Replace handset. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 128: Caller Id Restriction
Dial 66-SIP Trunk Number -Code-#* Where, SIP Trunk Number is 1 for SIP Trunk 1 2 for SIP Trunk 2 3 for SIP Trunk 3 Code is 1 to Enable CLIR 0 to Disable CLIR • Replace handset. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 129: Selective Trunk Access
Talk, when the remote party answers the call. To dial a number from SIP3: • Lift the handset of your phone. • Dial #86. • Dial the desired number. • Talk, when the remote party answers the call. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 130: Speed Dialing
Index Number. • SETU ATA211 will check the FXO Speed Dialing Table to fetch the number configured for the Index number and the corresponding Destination trunk (SIP1 / SIP2 / SIP3) to dial out the number. This feature will work on the FXO port, only if Incoming Call Routing option is selected as: •...
Page 131 Similarly, to configure Speed Dialing Tables for the FXO port and the SIP trunk, click the FXO and SIP tabs respectively. To configure Speed Dialing for the FXS port from the User mode: Log in as User. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 132 Click the Speed Dialing link. The Speed Dialing Table opens. To configure the Speed Dialing Table, follow the same instructions as provided for configuring the table from the Admin mode. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 133: Supplementary Services Of Service Provider
SETU ATA211. If you want to use the features of SETU ATA211, you must select Gateway as the Subscriber Type for the FXS port of SETU ATA211. However, you will be able to access the features of the service provider or network, also in the Gateway mode, by dialing Flash, followed by #0, the Access Code for Using Supplementary Services of Service Provider.
Page 134: Multi Stage Dialing
Multi Stage Dialing Multi-stage Dialing is useful when SETU ATA211 connected to a SIP Server being used for networking the PBXs of multiple sites. The extension users of the networked PBXs can dial the entire number string, both the destination number and the extension number of the destination PBX together.
Page 135 At the India office, PBX3 is interfaced with SETU ATA211, which is assigned SIP ID 23. • At the China office, PBX4 is interfaced with SETU ATA211, which is assigned a SIP ID 24. • Now, from the office in Canada, where PBX1 is installed, the extension user 101 of PBX1 wants to call extension 102 of PBX2 in Australia.
Page 136 Configuring Multi-Stage Dialing For this feature to work, at each site where the SETU ATA211 is installed, do the following: • Make sure that Auto Attendant or Direct Inward Dialing is enabled on the FXO port of the PBX on which SETU ATA211 is interfaced.
Page 137 In the Substitute Number column, enter the number which the system should dial out in place of the number dialed by the users. The SETU ATA211 considers the character '~' as Wait for Answer and it considers the character '^' as Pause.
Page 138 You may log out of Jeeves or continue, as required. The above example and configuration instructions are for Multi-stage Dialing on SIP trunks only. You may also configure Multi-stage Dialing on the FXO port, if required. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 139: Disconnect The Call
A dials #82 (access code for Disconnect the Call). • The current call is released. • A gets error tone. You can disconnect calls using access codes on the FXO and FXS port only. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 140: Making New Call
Answer the call, collect number & route as per incoming call route selection • Route to FXS. If not answered within ring timer, answer the call, collect number & route as per incoming call route selection Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 141: Pin Authentication
SETU ATA211 supports PIN Authentication for outgoing calls from the FXS port and for incoming calls on the FXO port and SIP trunks. You may use PIN Authentication on the FXO port / the SIP trunks / FXS port to restrict access to SETU ATA211 to specific callers.
Page 142 Enter the PIN to be authenticated against each Index in the Table. The PIN can have a maximum of 4 digits. The characters allowed are: 0 to 9,*, # • If you have finished entering the PIN Numbers, click Submit to save your entries. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 143: System Status
Viewing System Status from Jeeves To view System Status on Jeeves from Admin Mode, • Log in as Admin. • Click the Status link to open the page. To view System Status on Jeeves from User Mode, Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 144 • Log in as User. • Click Status link to open the page. • The following parameters will be displayed for SIP trunks 1, 2 and 3. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 145 This reason is displayed when Outbound is enabled but Outbound programmed address is not configured. Router's IP address is not This reason is displayed when Router's IP Address is to be used in programmed signaling but the address is not programmed. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 146 Subnet Mask: This field displays the current Subnet Mask Address of the WAN port. • Gateway Address: This field displays Gateway Address assigned to the WAN Port of SETU ATA211. This field displays the IP Address of the LAN port of the Router.
Page 147 • NAT Type: This field displays the NAT Type, if STUN is enabled in SETU ATA211. Commonly used NAT types are: • Unknown • Open • Conenat • Restrictednat • Portrestrictednat • Symmetricnat • Symmetricfirewall • Blocked • IP Address fetched using STUN: This field displays the IP address fetched using STUN, if STUN server address is configured.
Page 148: Viewing System Status On Phone
Firmware • Version-Revision: Current Software Version-Revision of SETU ATA211 is displayed here. • Kernel Date: The Date of current Kernel of the system is displayed here. Auto Configuration • Status: This field displays the type of Auto Configuration option selected.
Page 149 005 if the registration request has failed, cannot be sent to the server. Each time you go On-hook to view status of a port or trunk, you must enter the configuration mode again to view the status of another ports or trunks. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 150 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 151: Appendix
1.0on 4.0off 0.5on 0.5off 0.3on 0.3off 1on 1off Turkey cont. 2.0on 4.0off 0.5on 0.5off 0.2on 0.2off 1on 1off 0.6on 0.2off 350+440 cont. 400+450 0.4on 0.2off 0.375on 0.4on 0.35off 1on 1off 0.4on 2.0off 0.375off 0.225on 0.525off Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 152: Ring Cadences
Frequency Code Country (Hz) T1ON T1OFF T2ON T2OFF Australia Belgium Brazil China Egypt France Germany 0.79 Greece India Israel Italy Japan Korea Malaysia New Zealand Poland Portugal Russia Singapore South Africa Spain Thailand USA/Canada Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 153: Frequently Asked Questions (Faqs)
No. You do not need another internet connection to use ATA211. ATA211 has inbuilt router which enables you to surf internet and making VoIP calls at the same time. I am using the ATA211 to make VoIP calls and surf internet. I have connected my PC to LAN port of Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 154 Refer “Software Upgrade” topic. Q.15 If I forgot the password, can I still use the Web Jeeves for configuration? Ans. Yes. But you need to set the password value to factory default. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 155 Q.22 Can I route the Incoming calls on SIP to FXO? Ans. Yes. You can configure suitable routing option for 'Route the Incoming Calls' in the Webpage 'SIP Trunk'. Refer “SIP Trunks”. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 156: Acronyms
Simple Network Time Protocol SOHO Small Office Home Office STUN Simple Traversal of UDP over NAT Transmission Control Protocol TFTP Trivial File Transfer Protocol User Datagram Protocol Uniform Resource Identifier Universal Reference/Resource Locator Voice Activity Detection Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 157 Wide Area Network VoIP Voice Over Internet Protocol Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 158: Features At A Glance
Gateway and Network types. Speed dialing #9-Index Number To default Login Password #*** Making a new call Disconnect the call Selective Trunk Access-FXO Selective Trunk Access-SIP1 Selective Trunk Access-SIP2 Selective Trunk Access-SIP3 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 159: Product Specifications
Echo Cancellation: G. 168, with programmable tail length of 8, 16 and 32 msecs. Forward Error Correction (FEC) Voice Activity Detection (VAD) Fax using T.38 and Pass Through Flash Timer Programming Voice Codecs G.711 (a-Law and u-Law), G.729, G.723 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 160: Time Settings
LED Indication LED for Power LED for FXS LED for FXO LED for SIP1 LED for SIP2 Security Password Protected Administrator and User settings Dimension (W x H x D) 7.9x10.5x2.7 cm (3.1x4.1x1.1 inch) Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 161: Power Supply
External Adapter: 12VDC@ 1.25Amp. Power Consumption: 5W Environmental Operating Temperature: -10°C to 50°C (14°F to 122°F) Operating Humidity: 5-95% RH, Non-Condensing Storage Temperature: -40°C to 85°C (-40°F to 185°F) Storage Humidity: 0-95% RH, Non-Condensing Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 162: System Commands
Admin & User 61-Code-#* Set/Cancel DND Admin & User 66-SIP Trunk-Code-#* Send/Block Caller ID for SIP1, SIP2, SIP3 Only Admin 72-Code-#* Set/Cancel Call Waiting Admin & User 99-#* Cancel all features Admin & User Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 163: Warranty Statement
Warranty Statement Matrix Comsec Pvt. Ltd. (Matrix) warrants to its consumer purchaser any of its products to be free of defects in material, workmanship and performance for a period of 15 months from date of manufacturing or 12 months from the date of installation which ever is earlier.
Page 164 Matrix has been advised of the possibility of such damages or losses or for any claim by any other party. Except for the obligations specifically set forth in this Warranty Policy Statement, in no event shall Matrix be liable for any direct, indirect, special, incidental or consequential damages whether based on contract or any other legal theory and where advised of the possibility of such damages.
Page 165: Regulatory Information
Regulatory Information Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 166 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 167: Open Source Licensing Terms And Conditions
You must make sure that they, too, receive or can get the source code. And you must show them these terms so they know their rights. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 168 2. You may modify your copy or copies of the Program or any portion of it, thus forming a work based on the Program, and copy and Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 169 1 and 2 above on a medium customarily used for software interchange; or, b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing source distribution, a complete Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 170 You are not responsible for enforcing compliance by third parties to this License. 7. If, as a consequence of a court judgment or allegation of patent Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 171 If the Program does not specify a version number of this License, you may choose any version ever published by the Free Software Foundation. 10. If you wish to incorporate parts of the Program into other free Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 172 (at your option) any later version. This program is distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY; without even the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. See the Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 173 If your program is a subroutine library, you may consider it more useful to permit linking proprietary applications with the library. If this is what you want to do, use the GNU Lesser General Public License instead of this License. Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 174 Matrix SETU ATA211 System Manual http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 175: Index
DNS Address 64 Static DNS 64 TCP NAT Keep Alive Interval 71 Transfer Notification Timer 69 Echo Cancellation 47, 55 UDP NAT Keep Alive First Digit Wait Timer 69 Interval 71 Forced Maturity Timer 43 Unique 66 Forward Error Correction 69 http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 176 VLAN header 65 VLAN/CoS Layer RTP CoS 65 SIP CoS 65 Voice Activity Detection (VAD) 70 VoIP Silence Disconnect Timer 69 Volume 48, 56 Warranty Statement 157 http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 177 http://arttel.ru/shop/voip-shlyuzy/golosovoj-shlyuz-matrix-setu-ata211...
Page 178 MATRIX COMSEC PVT. LTD. Corporate Office: 394-GIDC, Makarpura, Vadodara - 390010, India. Tel.:+91 265 2630555, Fax: +91 265 2636598 E-mail: Info@MatrixComSec.com Factory: 39-GIDC, Waghodia - 391760, Dist. Vadodara, India. Tel.: +91 2668 262056/57 Technical Support: Tel.: +91 2668 263172/73, Fax: +91 2668 262631 E-mail: Support@MatrixComSec.com...
