- Page 1 SETU ATA211G Quick Start http://ArtTel.ru...
- Page 2 Disclaimer Matrix Comsec reserves the right to change, at any time, without prior notice, the product design, specifications, components, as engineering and manufacturing may warrant. This is a general documentation for all models/configurations of the product. The product may not support some of the features/facilities described in this document.
-
Page 3: Quick Start
SETU ATA211G VoIP-FXS-GSM Adaptor Quick Start Package Contents • SETU ATA211G with Antenna • Adapter 12V, 1.25 Amp • Ethernet Cables (RJ45) • Two wall mounting screws and screw grips • Warranty Card • External Antenna SMA with Cable •... - Page 4 Select an appropriate site and mount SETU ATA211G. Do not install the system at the places where shocks or vibrations are frequent or strong. Use only the power adapter included in the SETU ATA211G package. Using an alternative non- qualified power adapter may possibly damage the unit.
- Page 5 • Screw the antenna on to the antenna connector. • Insert SIM Card into the SIM holder of the Mobile Port of SETU ATA211G. To do this, • press the SIM holder lock (the small yellow button). You may use a blunt pin to press the lock button.
- Page 6 The default Subnet Mask of the LAN Port of SETU ATA211G is: 255.255.255.0 • Make sure your PC is in the same Subnet as the LAN Port of SETU ATA211G. Change the Subnet Mask of the PC, if necessary. •...
- Page 7 You can also use the WAN Port of SETU ATA211G to access the embedded web server in the same manner. The default IP Address of the WAN Port of SETU ATA211G is: 192.168.001.196 The default Subnet Mask of the WAN Port of SETU ATA211G is: 255.255.255.0 SETU ATA211G offers two Login modes: Admin and User.
- Page 8 On successful login, the Home page will open. The links Basic Settings, Advanced Settings, Supplementary Services and Status, appear on the left pane. Basic Settings are sufficient to get your SETU ATA211G into operation. To set up and operate your system, quickly, •...
- Page 9 When you use the Wizard, • Click the Wizard icon on the top right of your screen. • The Next button takes you to the next page, saving the changes you made on the current page. • The Back button returns you to the previous page. •...
- Page 10 http://ArtTel.ru...
- Page 11 http://ArtTel.ru...
- Page 12 MATRIX COMSEC PVT. LTD. Corporate Office: 394-GIDC, Makarpura, Vadodara - 390010, India. Tel.:+91 265 2630555, Fax: +91 265 2636598 E-mail: Info@MatrixComSec.com Factory: 39-GIDC, Waghodia - 391760, Dist. Vadodara, India. Tel.: +91 2668 262056/57 Technical Support: Tel.: +91 2668 263172/73, Fax: +91 2668 262631 E-mail: Support@MatrixComSec.com...
