License Plate Lamp; Central High Mounted Brake Lamp - Ford TRANSIT 2017 Owner's Manual

E175745
3. Turn the bulb holder counterclockwise
and remove it.
E175746
A Tail and brake lamp.
B Reversing lamp.
C Rear clearance lamp.
4. Remove the bulb by pulling it straight
out.

Central High Mounted Brake Lamp

This is not a serviceable item, see an
authorized dealer if it fails.
Transit (TTH) Canada/United States of America, HK3J 19A321 AA enUSA, Edition date: 04/2016, First Printing
Maintenance
3
4
A
B
C
234

License Plate Lamp

3
E72789
1. Carefully release the spring clip.
2. Remove the lamp.
3. Turn the bulb holder counterclockwise
and remove it. Pull the bulb straight
out.
Interior Lamp
Vehicles with Interior Sensors
E154370
1. Carefully remove the lens.
2. Remove the bulb.
2
1
2
1
