- Page 1 Quick Installation Guide EtherFast Gigabit Adapter Model No.: SP170 http://www.micronet.info...
-
Page 2: Package Contents
Micronet SP170 Gigabit adapter transforms your notebook PCs into powerful Gigabit workstations. It features latest 1000M technology and it is fully compatible with existing 10/100M networks. SP170 dramatically improves network performance up to 2000M with full-duplex operations. With this hot-swappable, plug-and-play adapter, notebook PCs users can now implement the Gigabit network so easily and transfer huge files at the fastest speed ever. - Page 3 Features Compliant with IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T and IEEE802.3x flow control Support auto-negotiation function to automatically select optimal speed (10/100/1000M) and mode (Full/Half Duplex) Support 802.3x flow control for full-duplex mode and back-pressure flow control for half-duplex mode Support auto uplink, no more cross-over cable Support 802.1Q VLAN tagging Support jumbo frame...
-
Page 4: Physical Description
Physical Description SP170 front view Please refer to the following table for LED definition Status Operation 10M network connection established On/Green 100M network connection SPEED established On/Amber 1000M network connection established On/Green Connection established Blink/Green Transmitting or receiving data LNK/ACT... -
Page 5: Installation
Installation This section describes how to install the adapter for Windows. Install the adapter Start the computer Hold the card with label up and gently slide the card into CardBus slot of notebook, make sure the card is firmly placed in the socket. - Page 6 Adapter. If it display as Realtek RTL8169/8110 Family Gigabit Ethernet NIC, the card is ready. 12. Connect the attached RJ-45 port with an Ethernet switch. 13. Now you are ready to use the adapter. Hot Swap This Gigabit adapter has hot-swap function. But, before you remove the PC card from CardBus slot, please click the Adapter icon on task bar and select stop to force this adapter to be inactive.
-
Page 7: Specifications
Specifications IEEE802.3, IEEE802.3u, IEEE802.3ab, Standard IEEE802.3x Interface 1 * 10/100/1000M RJ-45 port Bus Type 32-bit CardBus PC Interface 68-pin connector Full duplex: 2000M Speed Half duplex: 1000M 10BASE-T: Category 3, 4, 5 UTP/STP Cable Connections 100BASE-TX: Category 5 UTP/STP 1000BASE-T: Category 5, 5e UTP/STP Uplink Auto Uplink (Auto MDI / MDI-X) LED Indicators... - Page 8 CE Mark Warning This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022 for ITE, the essential protection requirement of Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. Company has an on-going policy of upgrading its products and it may be possible that information in this document is not up-to-date.
