User's Manual
Wireless LAN USB Adapter
Model No.: SP907BB
Website:http://www.micronet.info

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP907BB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MicroNet SP907BB

Summary of Contents for MicroNet SP907BB

  • Page 1 User’s Manual Wireless LAN USB Adapter Model No.: SP907BB Website:http://www.micronet.info...

  • Page 2: Table Of Contents

    Introduction... 2 1.1. Package Contents... 2 1.2. Appearance... 2 1.3. System Requirements ... 2 1.4. Environments ... 2 Installation ... 4 Software Installation ... 6 3.1. Software Utility ... 7 Ad-Hoc (Peer to Peer) Mode Setup ... 11 4.1. Application 1：Access the Internet without an AP... 11 4.2.

  • Page 3: Introduction

    1. Introduction Thank you for using Micronet SP907BB. This installation guide will help you install SP907BB and connect to the Internet quick & easy. 1.1. Package Contents 1. Micronet SP907BB Wireless LAN USB Adapter 2. Quick Installation Guide 3. Manual & Driver CD Disc 4.
  • Page 4 Ad-Hoc mode is a Peer-to-Peer mode. Without an AP, computers can also Ad-Hoc Mode connect to each other by SP907BB. With this mode, computers are able to share data or connect to the Internet if one of them is already connected to.

  • Page 5: Installation

    Note: The screens showed below are from Windows 2000. For other Windows system, the steps are the same, but the screens shown will be a little different. After plugging SP907BB into your PC, it will automatically find and alert a New USB Device. Click “Next” to continue.
  • Page 6 Your PC will recognize the device of “USB Wireless LAN Card”, and click “Next” to install driver. Finally, click the “Finish” to leave this dialogue window. After installation, please check whether the installation is success. Start→Setting→Control Panel Double click “System”→click “Hardware”→Device manager→Network Adapters. If the install is success, it should include “USB Wireless Lan CARD”...

  • Page 7: Software Installation

    3. Software Installation Insert the “Manual & Driver CD-ROM” into the CD-ROM driver of your PC, and you’ll see the software installation window as shown below. Click “Setup Driver & Utility”, and choose the “default” item through the installation process. After successful installation, you’ll see the new icon appear in the icon tray.

  • Page 8: Software Utility

    3.1. Software Utility Click the icon and the software utility window shows up. Status window allows you to change Operation Mode, Channel, SSID, Tx Rate, Int Romaing, and Radio. It also shows the connecting signal and quality for you to adjust related infrastructures and configurations.
  • Page 9 Double click the device you want to connect. Encryption window: SP907BB is able to provide 64/128Bit encryption. Advanced window: It provides you to adjust PREAMBLE, Fragmentation Threshold, RTS/CTS...
  • Page 10 Threshold, and Power Save function. Profiles window: It provides customers to change settings and save them in the configuration file.
  • Page 11 Info window: It shows the latest software version and MAC address.

  • Page 12: Ad-Hoc (Peer To Peer) Mode Setup

    4. Ad-Hoc (Peer to Peer) Mode Setup 4.1. Application 1：Access the Internet without an AP With existing Internet connection, another computer can access the Internet by using Peer to Peer mode of SP907BB. Mac Platform Existing Internet 現有上網環境 connection Ethernet card 1 Computer 1 網路卡一...
  • Page 13 Install USB Wireless Lan Card in “computer 1”, and “computer 2”. 2. “Computer 1” Setup Click “Start” (1) -> Settings (2) -> Click Network and Dial-up Connections (3) Under Network and Dial-up Connections, there are two Connection icons; one is the original Ethernet card, another is the new SP907BB.
  • Page 14 iii. Check the status of the Connection icon. Click the Connection icon, and you can see the device name and status under Network Connections. The name of this WLAN CARD is “USB Wireless LAN Card”, and another one is the original connected device, “Ethernet card 1”.
  • Page 15 Double click the WLAN icon in Icon Tray, and enter into the “Software and Utility window”. Software and Utility window: vii. Change to the “Ad-Hoc” mode Under “Monitor window”, click “Change” (1) to modify the Operation Mode to “Ad-hoc” mode (2). Change the SSID name to “ANY”...
  • Page 16 Check whether the Setup is success Computer 1: Enter into DOS MODE, and type “IPCONFIG”. (Start -> Run -> Type cmd or command) (in Windows 98/me OS System)

  • Page 17: Application 2：Data Sharing Between Computers

    Under “Monitor window”, click “Change” to modify the Operation Mode to “Ad-hoc” mode. Change the SSID name to “ANY”, and then click “Submit” to save this change. After setting, this SP907BB could be the Gateway for other WLAN devices. Please reset the computer. In computer 2: Double click the WLAN icon in the Icon tray.

  • Page 18: Appendix

    5. Int. Roaming: Its default setting is ‘Disable’, and does not need to be adjusted. 6. Radio: The default setting is ‘ON’. It means to stop the SP907BB’s RF function. If your WLAN card is embedded, you can stop its function by turning the Radio “ON”.
  • Page 19 When frame smaller than the RTS Threshold value, the SP907BB will automatically transmit the frame if the channel is available. If the channel is used, SP907BB will follow the 802.11b regulation that would ask the receiving device whether to send the frame. This will take more time for devices to check with each other, but it also prevents the loss of frames.
