Pinnacle 1.5m Skillion Series Assembly Instructions Manual

Gardenshed 1.5w x 1.5d x 2.1hm
Hide thumbs
Table of Contents

Advertisement

Quick Links

GardenShed
1.5W x 1.5D x 2.1Hm
1.5m Skillion Series
Assembly instructions
Congratulations on purchasing your new Pinnacle garden shed. Before assembling, we recommend
you read the instructions thoroughly. Your new shed comes with pre-drilled holes to make assembly
quicker. We recommend you assemble the shed using a trestle table or sawhorses and planks. This
will ensure that you are working off the ground and make it easier for you. Assembly is a two-person
job and should not be attempted in windy conditions.
Tools required: Drill, measuring tape, Phillips-head screw driver, rivet gun, rubber mallet, sturdy ladder, shifting spanner, 2 saw horses, 3mm
steel drill bit, 4mm steel drill bit and a 9mm masonry drill bit.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1.5m Skillion Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pinnacle 1.5m Skillion Series

Summary of Contents for Pinnacle 1.5m Skillion Series

  • Page 1 1.5m Skillion Series Assembly instructions Congratulations on purchasing your new Pinnacle garden shed. Before assembling, we recommend you read the instructions thoroughly. Your new shed comes with pre-drilled holes to make assembly quicker. We recommend you assemble the shed using a trestle table or sawhorses and planks. This will ensure that you are working off the ground and make it easier for you.
  • Page 2 GardenShed 1.5 x 1.5 x 2.1m Build your garden shed in 7 easy steps! Step 1: Check all parts against the component list Step 2: Assemble the rear wall panels Step 3: Assemble the side wall panels Step 4: Assemble the roof panels Step 5: Assemble the front wall panel Step 6: Assemble the front door Step 7: Fit the panels together...
  • Page 3 Step 1: Check all parts against the component list Lay out all parts with number facing outwards and check off against parts list. Part Picture Description Component Location QTY Check Sheet Sheet 2057x770 Rear wall Sheet 1977-2057x770 Sheet Side wall Left Sheet 1977-2057x770 Sheet...
  • Page 4 GardenShed 1.5 x 1.5 x 2.1m Part Picture Description Component Location QTY Check Brace Brace 1034 Door Roof side Channel Channel 1508 wall Channel Channel 1508 Rear wall Channel Channel 1508 Rear wall Channel Channel 1508 Front Channel Channel 1508 Front Channel Channel 1515...
  • Page 5 Part Picture Description Component Location QTY Check Brace Corner brace 1898 Corner Brace Corner brace 2055 Corner Brace Corner brace 2055 Corner Lip 1601 Roof Joining brace Joining brace Door Fittings part list: All fittings in this list are located in box 2 Picture Component Picture...
  • Page 6 Qty checking date: ____ / ____ / _____ Qty checking personal badge number: _______________ Signature: _________________________________________ In the unlikely event that you find you are missing a part, please contact Pinnacle at 1800 349 776. A copy of proof of purchase may be requested. Shed overview:...
  • Page 7 Step 2: Assemble the rear wall panels You will find it easier to assemble your shed using sawhorses with timber studs attached (timber needs to be the same length as the shed (1.5m)) or alternatively, a trestle table. Place 2 x part 6A (sheet) on your worktable and join together with the self-tapping screws as per the diagram below. Now fit part 20B (top channel) and part 20C (bottom channel) to the sheeting by tapping it in (diagram A) or sliding it in (diagram B).
  • Page 8 GardenShed 1.5 x 1.5 x 2.1m Step 2: Assemble the rear wall panels (continued) ROOF TOP EDGE Now fit part 31 (mid wall channel) to the sheeting and position it with the self-tapping screws provided. Please note the groove should face downwards.
  • Page 9 Step 3: Assemble the side wall panels Place part 2D and 7A (sheet) on your worktable and tap or slide on part 25 (top channel) and part 20A (bottom channel). Position and fix part 31 (mid wall channel) using the self-tapping screws. Fix part 20A (bottom channel) with self-tapping screws but not part 25 (top channel) at this stage.
  • Page 10 GardenShed 1.5 x 1.5 x 2.1m Step 4: Assemble the roof panel Place 2 x part 8 (sheet) on your worktable and join together with the self-tapping screws provided as per the diagram below. Now tap or slide in 2 x part 20A (channels) onto the sheeting and fix them to the top and bottom with the self-tapping screws provided. Make sure that the small lips on channels 20A are always facing out.
  • Page 11 Step 4: Assemble the roof panel (continued) Now fit 2 x part 51 (side lips) to the sheeting and fix them with the self-tapping screws provided.
  • Page 12 GardenShed 1.5 x 1.5 x 2.1m Step 5: Assemble the front wall panel Place part 4B (sheet) on the worktable. Fit part 20D (top channel), part 20E (bottom channel) and part 41B (jamb) (There are pre-drilled holes for the next step on both parts 4B and 41B that must be aligned) and part 33R (mid wall channel) to the sheeting and fix them with the self-tapping screws.
  • Page 13 Step 6: Assemble the front door Place part 5B (door sheet) on the worktable and fix 2 x part M26, part 24G and part 24F (channels) with the provided 3.0 x 10mm rivets. Make sure the small lips on channels M26 are always facing out. This ensures rainwater cannot build up inside your shed. RIDGES FACING UP FIXW ITH3 .0*10MMR IVET FIX WITH 3.0MM RIVETS...
  • Page 14 GardenShed 1.5 x 1.5 x 2.1m Step 6: Assemble the front door (continued) Once channels are fitted to both doors, align 2 x part U12 (brace) and part W (joining brace) with holes on the back of the door and position temporarily with some tape or simply hold in place.
  • Page 15 Step 6: Assemble the front door (continued) Turn door over with bracing aligned with holes (make sure the ridges of the door are facing up) and fix the bracing with the provided 3.0 x 10mm rivets through the front of the panel. Then turn door over and insert plastic stoppers at the ends of braces as shown below. ROOF TOP EDGE RIDGES FACING UP Note: Fix rivets...
  • Page 16 GardenShed 1.5 x 1.5 x 2.1m Step 6: Assemble the front door (continued) Fit part 5B (assembled door) to the front wall panel as per the diagram below. Use a rivet gun to fix the door using the pre-drilled holes. Fix the pad bolt (but NOT its keeper at this stage) using the pre-drilled holes and the self-tapping screws (diagram A) or the rivets (diagram B) provided.
  • Page 17 Step 7: Fit the panels together Attach the side walls to the back wall, then the front wall, then the roof. Fix all the components using self tapping screws. Fix part 71 (pad bolt keeper) using 16mm self-tapping screws (diagram A) or using rivets (diagram B) ensuring the keeper lines up with the pad bolt.
  • Page 18 GardenShed 1.5 x 1.5 x 2.1m Now fit the bolt down kit as per the diagram. Strengthen the mid wall braces by applying part 72 (mid wall brace bracket) to each corner if necessary. WALL SHEET BOLT & NUT BOLT & NUT WALL SHEET STEEL ANGLE STEELA NGLE...
  • Page 19 Apply channel safety cover (L type) to part 31 (channel) and channel safety cover (R type) to part 33R (channel). Also apply the self-tapper covers to screw ends visible in the walls on the inside of the shed as per the diagram below.
  • Page 20 GardenShed 1.5 x 1.5 x 2.1m The door can be hinged on the opposite side as well. Align the door with the edge and make holes using a cordless drill. Remove the pins from the hinges and reverse their direction before you attach the door. If you are concerned about the visibility of any pre- drilled holes, you can fill them with rivets.
  • Page 21 Warranty statement: This warranty against defects is given by: Pinnacle Hardware. Business Address: 28 Hudson Court, Keysborough VIC 3173 1800 349 776 Email: support@pinnacle.net.au New Zealand customers please contact: HARCO (Harkness & Young Ltd) Ph: 09 276 4071 Email: sales@harknessyoung.co.nz Details of Manufacturer’s Warranty...
  • Page 22 GardenShed 1.5 x 1.5 x 2.1m IMPORTANT 1. Manufacturer’s Disclosure This warranty against defects shall not apply in the following situations: A) Where the product is not assembled in accordance with the instructions provided in the product kit. B) Where the product is used to store corrosive materials such as fertilizer, chlorine etc; C) Where the damage to the product is caused by storms.
