Brake Adjustment

Periodically check (measure) the freeplay of the front and
rear brakes (A). Refer to the specifications chart on page
144 for the acceptable range of freeplay.
To adjust the front brake freeplay, turn the adjustment
knob (B). To adjust the rear brake freeplay, turn the
adjuster nut (C).

Brake Lever Travel

Service the brakes when brake lever travel (D) reaches the
following total lever travel measurements. Always service
the brakes when there is no longer sufficient stopping
ability at the specified lever travel setting.
Component
Front brake lever
Rear brake lever
Total Lever Travel
1 3/4" (45mm)
2 1/2" (65mm)
Maintenance
A
B
D
C
