Handlebar Adjustment - Polaris Outlaw 525 IRS Owner's Manual

Maintenance

Handlebar Adjustment

Improper adjustment of the handlebars or incorrect torquing of the adjuster block tightening bolts
can cause limited steering or loosening of the handlebars, resulting in loss of control and possible
serious personal injury or death. Follow the adjustment procedures exactly, or see your Polaris
dealer for service.
The handlebars can be adjusted for rider preference.
1. Loosen the four handlebar bolts.
2. Adjust the handlebar to the desired height. Be sure the
handlebars do not contact the gas tank or any other part
of the machine when turned fully to the left or right.
3. Torque the two front bolts to 10-12 ft. lbs. (14-16 Nm),
then torque the two rear bolts.
NOTE:
A gap of up to 1/8" (3 mm) will remain at the rear bolts.
4. Check sprocket bolt torque. Torque to 30 ft. lbs. (40
Nm).
166
WARNING
Loosen
bolts
