ISDT BatteryGO BG-8S User Manual page 3

Tqfdjgjdbujpot
Voltage measurement accuracy :
Balancing cells accuracy :
Qpsu!ejbhsbn
This product is suitable for the lithium battery which has the XH 2.54 balance port, connect the balance port align
from BAT- as showed in the figure. When connecting 1S battery, input Voltage from XT60i must be more than 5V.
Working voltage :
Input voltage 1s :
Input voltage 2-8S :
Battery cells :
Support USB charging :
Support smart battery :
Dimension :
Weight :
4S
5S
6S
7S
8S
5.0V - 36V
0.8V - 15V
0.8V - 4.8V
1-8s
±0.005V @ 4.2V
< 0.005V
QC3.0, BC1.2, Maximum output 12V/2A
Charging and discharging setting,
read battery info and usage history.
80 X 55 X 19 mm
59 g
1S
2S
3S
