Technical Specifications - HDFury Ultra AVR Key User Manual

24 Ultra AVR Key – User Manual
Support all UHD/BR standard resolution: 4K60 4:2:2 12bit BT2020 HDR, 4K60 4:2:0 10bit, 4K60 4:2:0
12bit, 4K30 4:4:4 12bit, 4K30 4:4:4 16b, 4K24 4:2:2 12bit, ..
Support all VESA mode video format (PC Resolutions) up to ultra-high resolution such as WQSXGA,
QUXGA, QFHD, WQUXGA, 4K
Support any Audio format such as PCM at up to 192kHz, compressed audio (IEC61937), DSD, DST,
DTS, DTS-HD, Dolby True HD, DTS-MA, DTS:X, Atmos and HBR.

Technical Specifications

Audio: PCM at up to 192kHz, compressed audio (IEC61937), DSD, DST, DTS, DTS-HD, Dolby True HD,
DTS-MA and HBR.
DDC Signal: 5V p-p (TTL)
Power Supply: External 5 Volt 2 Amp USB (same as most smartphone/tablet PSU)
Power Consumption: <2Watts
Current Absorption: around 400mA
Shipping Dimensions: 6.3" x 4.2" x 3.3", Weight: 16 oz
Enclosure: Silver with Blue Logo Led
Consolidated Specs Summary
HDMI revision:
Max Resolution:
I/O:
Pass-thru Channel:
HDMI audio:
Audio support:
HDCP Conversion:
Operating Modes:
Special Modes:
EDID Modes:
Dimension:
Enclosure:
rd
Disclaimer: 3 party and/or custom firmware providing extra features are not covered in this manual.
HDMI 2.0b (Level A) 600Mcsc – 18Gbps
4K60 4:4:4 8b, 4K60 4:2:2 12b, 4K120 4:2:0 8b or 8K30 4:2:0 8b
1 HDMI In, 2 HDMI Out, USB.
Support any signals up to 18Gbps including HLG/DV and HDR10+
720p or 1080p Full HDMI Audio.
Any sound format from lower mono up to Dolby Atmos and all latest.
Any HDCP to any HDCP with CST1 support
18Gbps pass-through with full HDMI audio at 720p or 1080p
HDMI Doctor and booster.
SDR BT2020 or HDR BT2020 selection for UHD BR player
2.2"L x 1.5"W x 1"H – in CM: 6 x 4.5 x 3
Weight: 65g – 0.15 LBS
