  • Page 1 HDfury 4 (aka 3Dfury) User Manual Rev 1.0...
  • Page 2: Table Of Contents

    HDfury 4 – User Manual Table of Contents Table of contents …..................2 Overview …...................... 3 Connecting Cables …..................4 Power Status/LED …..................5 RGB Shift (Image Centering) …................ 6 3D Mode Button....................7 Stream Select Button..................8 Frame Rate Button................... 9 Dip Switch Settings……………………………………………………………………………………...
  • Page 3: Overview

    HDfury 4 – User Manual Overview The HDfury team would like to thank you personally for purchasing the HDfury4! This unique HDMI converter will allow you to connect 2D/3D HDMI devices to any TV, Monitor and Projector, either through Component, RGBHV, DVI-D or HDMI. It can output both Digital and Analog Video/Audio simultaneously.
  • Page 4: Connecting Cables

    HDfury 4 – User Manual Connecting Cables To use your HDfury4: • Connect a HDMI input cable to the HDMI input. • Connect a video output cable to the analog video output or hdmi output. • Connect the HDfury4 power supply.
  • Page 5: Power Status/Led

    Power/Status LED The HDfury4 logo will glow blue when in use. When the HDfury4 first receives an HDMI signal the logo will quickly turn on, then off, and then on permanently to indicate that the 4-letters handshake has been completed.
  • Page 6: Rgb Shift (Image Centering)

    HDfury 4 – User Manual RGB Shift (Image Centering in RGB mode) The HDfury4 perfectly centers the image automatically when Component (and/or Digital) video output is used. If RGB video output is needed, some fine tuning of the image centering may be required. The “L/R”...
  • Page 7: 3D Mode Button

    3D Mode Button The HDfury 4 automatically switches to 3D mode if the correct information is sent from the source. If for some reason the HDfury4 does not correctly switch to the correct mode the user can cycle though 3 modes via a push button that switches between "3D Side-by-side ->...
  • Page 8: Stream Select Button

    Right stream. By default they come shipped with the button in the center position for single projector use. Please see above picture to aid in setting the HDfury 4 correctly for dual projector setup. Disclaimer: This product does not process HDCP input. When receiving content that has HDCP encryption there will be no video output.
  • Page 9: Frame Rate Button

    HDfury 4 – User Manual Frame Rate Button The HDfury4 comes with a unique feature that will convert film based 24hz content into 1080p 48hz and 72hz. It also allows 3D to be output at 720p 60hz, 72hz, 96hz,120hz, and 144hz.
  • Page 10: Dip Switch Settings

    HDfury 4 – User Manual DIP Switch Settings To customize your HDfury4, a bank of ten (10) DIP switches are provided. Remove the small cover on the back of the HDfury4 to access the DIP switches: The HDfury4 ships with the following factory default DIP switch settings: Disclaimer: This product does not process HDCP input.
  • Page 11 DIP 1: OFF = Component output DIP 2: ON = Sync passed DIP 3: OFF = Sync not forced positive (passthrough) DIP 4: ON = RGB color depth 0-255 DIP 5: OFF = RGB shift disabled DIP 6: ON = Power LED ON...
  • Page 12: Rgb/Component Output

    HDfury 4 – User Manual RGB, VGA, RGBHV-Output or YUV, COMPONENT, YPbPr-Output RGB-, VGA-, RGBHV-Output If your Display accepts only RGB, VGA or RGBHV set the Dip-Switch #1 to ON. YUV-, COMPONENT, YPbPr-Output If your Display accepts only YUV, COMPONENT or YPbPr set the Dip-Switch #1 to OFF.
  • Page 13: Rgb Sync

    HDfury 4 – User Manual RGB Sync When the HDfury4 is set to RGB output mode the sync signals may be passed through as is, forced positive, forced negative, or inverted. Check your owner’s manual to see if your RGB display has any special sync requirements.
  • Page 14: Enchanced Colour Output

    Some users may choose to disable this feature. To use enhanced colour depth (0-255), set DIP switch #4 to ON: To disable this feature and use normal colour depth (16-235), set DIP switch #4 to OFF: Disclaimer: This product does not process HDCP input. When receiving content that has HDCP encryption there will be no video output.
  • Page 15: Rgb Shift

    HDfury 4 – User Manual RGB Shift (RGB center adjustment) Some users may choose to disable the RGB Shift button if they choose to shift the image in a video processor or in the display. To disable the RGB Shift button, set DIP switch #5 to OFF:...
  • Page 16: Power Status Led

    HDfury 4 – User Manual Power/Status LED Some users may choose to disable the blue power/status LED on the front of the HDfury4. When powered, the HDfury4 logo will glow blue. For troubleshooting purposes we recommend that you leave the power/status LED enabled.
  • Page 17: High Frame Rate

    HDfury 4 – User Manual High Frame Rate When the switch is in the off position the framerate is limited to a maximum of 60Hz. When the switch is in the on position then higher than 60Hz modes are available for 2D film, 720p/60Hz and 3D sources.
  • Page 18: 3D Scaling

    HDfury 4 – User Manual 3D Scaling 3D sources are either scaled to 720p or 1080p depending on the position of DIP switch #8. To set 3D output to 1080p set DIP switch #8 to OFF: To set 3D output to 720p set DIP switch #8 to ON: Disclaimer: This product does not process HDCP input.
  • Page 19: Audio Edid

    HDfury 4 – User Manual Audio EDID Audio EDID can either be read from the sink device or forced to 2 channel stereo PCM depending on DIP switch #9 setting. *For the Sony PS3 and some other devices you will need to redo the “audio settings “ if you change the position DIP switch #9.
  • Page 20: Video Edid

    HDfury 4 – User Manual Video EDID Video EDID can either be read from the sink device or forced to fixed full 3d HD EDID depending on DIP switch #9 setting. *For the Sony PS3 and some other devices you will need to redo the “video settings “ if you change the position DIP switch #0.
  • Page 21: Frequently Asked Questions (Faq)

    HDfury 4 – User Manual Frequently Asked Questions (FAQ) Can the HDfury4 be used for 3D Games? Yes. The HDfury4 supports the 3D frame-packing standard used by 3D games as well as all other 3D formats. Can the HDfury4 be used for 3D Blu-ray movies? Yes.
  • Page 22 HDfury 4 – User Manual What output resolution does the HDfury4 support with 3D content? ■ 720p60, 720p72, 720p96, 720p120, 720p144 Frame Sequential ■ 720p and/or 1080p for 60Hz display ■ 1080p60, 1080p72 How do I know if my display supports 50/60Hz or 100/120Hz? All displays support 50/60Hz.
  • Page 23 HDfury 4 – User Manual What about long HDMI cable runs? Can I expect issues? The HDfury4 acts as an HDMI repeater device. So having a HDfury4 in the path will amplify and recover the signal. You should not need any passive (or active) HDMI amplifiers, especially if you put HDfury4 in the middle of your cable run.
  • Page 24 HDfury 4 – User Manual The HDfury4 glasses and emitter are fully customizable glasses that allow you define duty_cycle, delay, offset, invert sync, presets, etc… Can I use third party glasses that include an emitter? Yes. Any external 3rd party glasses that include an emitter will work with the HDfury4 as long as the emitter has the 3-pin standard mini-din connector.
  • Page 25: Simulview Tm

    PS3 hdmi output and the outputs from the hdmi splitter to the 2 HDfury4’s. Then the output from the two HDFurys would go to the two displays or projectors. One Hdfury 4 needs to be set for left stream and the other for right stream output (please refer to Stream Control section for additional details).
  • Page 26: General

    HDfury 4 – User Manual General Why do I need HD (720p) or Full HD (1080p)? Blu-ray players, HDMI graphic cards, PS3, Xbox 360 Elite are all able to unleash their true potential (720p/1080p mode) only through the HDMI output. If you want a valid ticket to the Full HD world you either need a compatible display (with HDMI input) or an HDfury4 for your existing display.
  • Page 27 HDfury4 makes this more convenient. The choice is up to you! Typically there is no need to use the audio features of the HDfury4 with a home theater setup. The HDfury 4 will also pass though the audio from the source over hdmi or can be forced to 2 channel pcm stereo over hdmi as well.
  • Page 28: Inputs

    How many inputs does the HDfury 4 have? It has a single 3d HDMI 1.4 compliant with HDCP with support for Deep Color(TM). The HDfury 4 is the first product we offered that can convert 3d to work with any tv and also offers a hdmi output for both sound and video.
  • Page 29 HDfury 4 – User Manual My picture is all green! What's going on? You likely have a display that only accepts RGB and you have the HDfury4 set to component output (Y/Pb/Pr). Switch it to RGB. I want to use the component input on my display. How do I set the HDfury4 to output component (Y/Pb/Pr) video? Lift the little panel found on the back of the HDfury4 and set DIP switch 1 to OFF.
  • Page 30 Blu-ray playback settings and adjust the DVD upscale feature because by default it will also be 1080p. Another hint: When you first connect an HDfury device to the PS3 the PS3 will ask: "A new HDMI device has been detected, do you want to use it?" Answer 'YES' only if your TV is 1080p capable.
  • Page 31: Image Shifting

    HDfury 4 – User Manual Image Shifting Will the HDfury4 shift the image to the left or cropped (cut off) in any way like some other converters? No. The HDfury4 includes advanced features to ensure that the image stays perfectly centered when component (Y/Pb/Pr) output mode is used.
  • Page 32: Rgb Image Sync

    The HDfury4 allows you to force the output sync to either positive or negative, or invert it. Previous HDfury models did not alter the sync signal in any way requiring extra hardware if your display has special sync requirements.. To set sync lift the little panel found on the back of the HDfury4 and set DIP...
  • Page 33: Colour Depth Upscaling

    Yes. Like the HDfury2, the HDfury4 expands the regular 16-235 image range to 0-255 for greater contrast ratio. Some people may want to turn off this feature. To turn colour depth upscaling off, lift the little panel found on the back of the HDfury4 and set DIP switch 4 to OFF. Power Do I need to use the HDfury4 power supply? Yes.
  • Page 34: Miscellaneous

    HDfury 4 – User Manual Miscellaneous The blue LED power light on the HDfury4 is too bright in my light controlled Home Theater! Can I turn it off? The easiest way to turn off the blue LED power light on the HDfury4 is to simply place a piece of tape over it.
  • Page 35 Up to 720p240 in dual projectors setup!  7.1 Dolby® True HD & DTS Master Audio  Input: HDMI 1.4 (HDCP compliant) input with 3D and Deep Color support  Output: Digital HDMI / DVI-D and/or Component (YPbPr/YCbCr) and VGA (RGBHV) video output ...
  • Page 36 HDfury 4 – User Manual Input/Output mode: HDfury4 Input/Output mode:  2D VIDEO MODE COMPATIBILITY: NTSC 480i/p, PAL 576i/p, HDTV 720p/1080i/1080p  2D OUTPUT: 2D movies: 1080p24, 1080p48, 1080p72 (HDfury4 can double and triple frame from 24hz material) 720p60, 720p120 Pass-through any resolution ...
  • Page 37: Specifications

    Integrated RGB Color Space Converter for both RGB-to-YCbCr and YCbCr-to-RGB (both 601 and 709) with true 12-bit accurate data using 14-bit processing  4:2:2 <> 4:4:4 converter with 12-bit accurate data using 14-bit processing  Digital Audio Output HDMI audio pass-through...
  • Page 38 HDfury 4 – User Manual Team HDfury thanks you for your support For help visit: http://www.HDfury.com Disclaimer: This product does not process HDCP input. When receiving content that has HDCP encryption there will be no video output. In some countries a 3...
