6
Keep holding the release buttons
on both sides of the AC adapter
connector (1) and unplug it
horizontally (2)
When the charge alert is not heard or when the
charging LED does not illuminate, check that
the FOMA terminal is placed securely on the
desktop holder (except when the handset is
turned off, the manner mode is set or Charge
alert is [OFF]).
When placing the FOMA terminal on the
desktop holder, be careful not to let a strap etc.
caught.
Charging by using AC adapter
Read the user's guide of FOMA AC Adapter 01/
02 (sold separately).
1
Open the external connector
terminal cover, turn the arrow side
of the AC adapter connector up
and insert it horizontally into the
external connector terminal (1)
28
Basic Operation
Release buttons
Charging LED
External
connector
terminal
External connector terminal cover
Connector (with the arrow side up)
2
When inserting the AC adapter
power plug into an outlet, the
charge alert is heard, the charging
LED illuminates and charging starts
3
When charging is complete, the
charge alert is heard and the
charging LED turns off
4
Remove the AC adapter power
plug from the outlet
100V AC
outlet
